  • Page 1 Comia Combine Harvester Instruction Book Sampo Rosenlew Ltd P. O. Box 50 FIN-28101 PORI FINLAND 0814374 04/2015 Englanti...
  • Page 3: This Book

    One combine does not have all the described features. The actual structure and number kept in mind when reading the manual. as well as the service and maintenance instructions without further notice. SAMPO ROSENLEW LTD – 1 –...
  • Page 4: Table Of Contents

    CONTENTS This book Safety Precautions Marking the danger points Type Marking Technica Speci cations Conformity to EU Regulations Acceptance Inspection and Getting Started Opening the Guards Structure and Functions of the Combine 20 and 22 Cut-away Picture of the Combine 21 and 23 Operator Controls and Instruments Key to the Symbols...
  • Page 5: Safety Precautions

    SAFETY PRECAUTIONS Read carefully these instructions on safety and use before starting to operate the combine. Time spent in becom- ing familiar with the instructions now, will save you money or may even spare you from injury. Before accepting the delivery of the combine, make sure it conforms to the delivery contract. Do not t the combine with any accessories not approved of by the Manufacturer.
  • Page 6 Never use the combine for anything but threshing. Manual feeding of crops onto the cutting table is pro- hibited. Before starting, particularly reversing, make sure that everybody nearby is aware of your intentions. Test the brakes as soon as you start, and stop immedi- ately if the brakes or steering operate defectively.
  • Page 7 In Case of an Accident If there is an accident despite all precautions, keep calm and consider carefully what to do. First try to re- verse the combine away from the power line. If there are other people near, ask them to check that the com- bine is not stuck in the line.
  • Page 8 4. REPAIR AND SERVICE Always keep the combine in good condition. Check the condition of fast moving parts daily. Pay special attention to the transmission mechanism and the rotating chopper knives. Replace defective parts before they become dangerous. Clean, repair and service the combine with the trans- mission and engine off, the ignition key off the ignition switch and the master switch in its off position.
  • Page 9 caution shall be practised. 6. FIRE SAFETY Two factors are needed to start a re ammable material and ignition; oxygen is always available. Threshing generates a lot of light and highly ammable dust. Therefore it is important to clean the combine on a regular basis, and the engine compartment daily.
  • Page 10: Marking The Danger Points

    MARKING THE DANGER POINTS Although an effort has been made to build the combine as safe to use as possible, there are certain risks involved in its use. These are to be kept in mind when operating the combine. The danger points have been marked on the combine using hazard pictorials. On the following page you will nd the locations of and the key to these symbols.
  • Page 11 HAZARD PICTORIALS Danger How to avoid it Subject to danger due to Read the manual before starting the com- insuf cient information bine A raised part may fall down Support raised parts before going under them Gap in belt drive Stop the engine and remove the ignition key before removing any guards Getting entangled in mov-...
  • Page 12: Type Marking

    TYPE MARKING When ordering spare parts or service, always quote the type marking and number shown on he machine plate of the combine. When ordering parts for the cutting table, also quote the type marking and number shown on the cutting table.
  • Page 13: Technica Speci Cations

    TECHNICAL SPECIFICATION COMIA (ISO 6689 standard has been used in measuring) Cutting table Cutting width (m) 3,45 Cutting height (m) -0,20…+1,20 Knife, Number of Strokes 1020 cycles/min Reel Diameter (m) 1,05 Speed range (rpm) 16...51 WobbleBox (WB) 15...49 Crank-driven knife (CK) Threshing Cylinder Width (m) 1,11...
  • Page 14 Driving speed (km/h)* Final drive Hydrostatic Traction Drive DANA 0... 4,7 0... 4,1 0... 7,0 0... 5,6 0... 18,4 0… 6,4 0... 5,6 0… 9,5 0... 7,6 0… 25 * Speeds may vary depending on the size of the tyres Turning radius (m) (6,2 C8) Tyres / Air pressure (bar)
  • Page 15 Volumes (See manual, LUBRICATION) Fuel tank (litres) 200 / 350 Cooling system (litres) (4 cyl.= 29) (6 cyl =33 ) Urea (litres) Weight (kg) Without cutting table and chopper 7700 7950 8740 Cutting table (m) 3,45 Weight (kg) 790 CK 1005 1055 1110 1160 1200 890 WB Chopper weight (kg)
  • Page 16: Conformity To Eu Regulations

    – 14 –...
  • Page 17: Acceptance Inspection And Getting Started

    ACCEPTANCE INSPECTION AND GETTING STARTED The combine leaves the factory packaged in an appropriate way to ensure undamaged delivery. Before start-up the following steps shall be taken: Read the Operating Manual carefully before start-up. Remove all loose parts stored in the grain tank during transportation. Make sure the combine was not damaged in transit and that no parts are missing.
  • Page 18: Opening The Guards

    OPENING THE GUARDS To ensure safety, the movable guards in the combine have been equipped with a locking device. They can- not be opened without the appropriate tool supplied with every combine, hanging on a hook on the back wall of the cab. The guards are locked automati- cally when closed.
  • Page 19 The rear guard of the chopper straw spreader is released by levering the locking pivot to the right with the tool. The guard also gets locked in the upper position and is released correspondingly. Choppers belt guard is opened by loosening the bolt on the guard and turning the cover open.The guard is secured in the upper position with a rub- ber strip.
  • Page 20 Engine Compartment To open the cover on the engine compartment To unlock the grain tank cover, turn the lock shaft with the key. The cover can also be opened from the inside. Clean, repair and service the combine with the trans- mission and engine off, the ignition key off the ignition switch and the master switch disconnected.
  • Page 21 Windscreen cleaning and adjusting mirrors When cleaning the windscreen, climb on top of the crop elevator and hold on of the top arms of the mirrors B Figure B9. When adjusting rear view mirrors climb on the platform C and hold on of the top arms of the mirrors B. Figures B9 B10.
  • Page 22: Structure And Functions Of The Combine 20 And

    STRUCTURE AND FUNCTIONS OF THE COMBINE Standard Threshing Mechanism The cutting and feeding equipment takes the crops in for threshing. The straw dividers limit the crop to be cut and bring it within reach of the reel. The reel, together with the crop lifters, lift the laid-down crop up and take it from the cutting knife onto the table auger.
  • Page 23 – 21 –...
  • Page 24 STRUCTURE AND FUNCTIONS OF THE COMBINE The TS Threshing Mechanism The cutting and feeding equipment takes the crops in for threshing. The straw dividers limit the crop to be cut and bring it within reach of the reel. The reel, together with the crop lifters, lift the laid-down crop up and take it from the cutting knife onto the table auger.
  • Page 25: Cut-Away Picture Of The Combine 21 And

    – 23 –...
  • Page 26: Operator Controls And Instruments

    OPERATOR´S CONTROLS AND INSTRUMENTS Operator’s Platform / Cab (fig. B1c) Comvision- display Multi-function Lever Steering Wheel Brake Pedals Instrument Panel Gear Lever Traction Speed Control Lever Seat Buddy Seat Concave Clearance Indicator Handbrake Instrument Panel (fig. B2c) Thermometer Fuel Gauge Differential Lock Reversing of Cutting Table and Feeding Mech.
  • Page 27: Key To The Symbols

    SIGNALS AND SYMBOLS Cylinder Speed Ignition Switch Concave Clearance Master Switch electric Reel Fore Aft Control Ignition Signal STOP Stop Control Lever Reel Speed Control Air olume Control Oil Warning Light Alternator Warning Light Air Direction Control Lever Engine Revolutions, lever control UmkehReversing Switch of Cutting Table Engine Revolutions, electric control Four-wheel Drive...
  • Page 28: Operation And Adjustment

    OPERATION AND ADJUSTMENT STEERING WHEEL Position Can Be Adjusted (Triple Adjustment Steering Column) To adjust the steering column angle, depress pedal A and tilt the whole column forward or backward Fig. K1b . The steering column folds in the middle. Lift the lever B up and adjust the steering wheel to the desired position.
  • Page 29 OPERATOR’S SEAT Adjustments Spring Suspended Grammer Seat fig. K2a To adjust the fore and aft position, release lever A under the seat and move the seat to the required position. Adjust the height by raising the seat manually. There are three alternative heights at 20 mm intervals.
  • Page 30 BRAKES (Fig. K3a) While Driving and Turning The mechanical outer shoe brakes operate on the front wheels through the drive shafts. They may be used separately as steering brakes by releasing lock- ing pin A. When driving on the road, the brake pedals must be latched together.
  • Page 31 The combine is equipped with a safety ignition system, which prevents the combine from moving when the engine is being started. It allows the start-up to take place only with the traction speed control lever in neutral. It is advisable, however, always to start the engine with the gear in neutral.
  • Page 32 Turning the ENGINE off / Listening to the Radio Before turning the engine off, move the throttle to the idling position and disengage the threshing mechanism. To stop electrically controlled engines, turn the ignition key to the STOP position. utes to equalize the temperatures. The ignition key can only be turned left from the STOP position while pressing the key down.
  • Page 33 Ranges (Fig. K10b) Engine power is transmitted to the hydraulic pump by means of a multi-groove belt. Transmission from the pump to the hydraulic motor of the gearbox takes place by means of liquid. Pump output is adjusted steplessly moving the drive lever between position 0 and the maximum.
  • Page 34 The differential lock may only be used on the eld. It must not be used in speed range III. The differential lock considerably improves combine manoeuvrability in soft soil or on slippery ground and steep slopes. It must, however, never be used when not necessary. .
  • Page 35 Stairs (Fig. K12c) The stairs to the cab can be turned from their normal po- sition forward to the front of the wheel to reduce the width of the combine. When standing on the ground, release the locking by lifting lever A. When standing on the cab platform, release the locking by lifting knob B.
  • Page 36 MASTER SWITCH (Fig. K13) Controls Elec- There is a master switch to control the electrical equipment of the combine. It is located on the side of electric box, left side of the combine. Cabin is equipped with a backlight feature, which keeps the light on when the ignition switch is set to zero positon, but the main power is switched on.
  • Page 37 CAB (fig. K14) Fresh-air Fan Provides Good Ventilation The 4-speed fan is started using switch A. To change the airflow direction, turn nozzles 1 at the front top of the cab. Air coming into the fan is taken through detachable coarse mesh and fine filters. To keep up the fan capacity and to secure the purity of the air, the filters have to be cleaned daily and replaced often enough to prevent harmful impurities and...
  • Page 38 TOWING (Figs. K16 and K17) Allowed from The combine may be towed from designated points only. When towing forward, the towline is hooked to the link on the front axle, g. K16. When towing backward, wind the towline round the rear carrier, g.
  • Page 39 TABLE TRAILER (Figs. K20, K21 and K22) for Road Transport of Wide Cutting Tables The need for a table trailer depends on farm condi- tions. The trailer may be necessary for a 3.9m cutting table if transportation is necessary on busy, narrow roads.
  • Page 40 Drive the table above the trailer from the left-hand side so that the knife is level with the trailer marking sticks and brackets A, g K21, are between carriers B. Lower the table slowly. Make sure the table is positioned correctly: Reverse slowly so that the rear end of the table is against both the carrier limiters.
  • Page 41 SAFETY SWITCH There is safety switch on the instrument panel See pages 24 It must be in its top-most position before any mechanisms can be switched on. It will rise when the knob is turned clockwise. When the safety switch is pressed, all engaged mechanisms threshing, chopper, cutting table and unloading stop.
  • Page 42 You receive a variety of display modes from which to choose from. Mode 1, threshing display: Rounds per minute Fuel consumption L H Coolant temperature The load percentage Mode 1 Mode 2: The load percentage The battery voltage Oil pressure Ad-Blue consumption L H Mode 2 Mode 3, temperatures 1:...
  • Page 43 Mode 5: Operating Hours Total fuel consumption L Fuel Tripmeter 1 and 2 Mode 5 Mode 6, pressure display: Oil pressure Charge pressure The fuel feed pressure Mode 6 Mode 7, Service display: Passive faults list fault history: operating hours, and number of faults Mode 7 Mode 8, Service display...
  • Page 44 The self-diagnostics monitors different functions in the engine giving a fault report in case of possible disturbance. Additionally in certain cases, it limits the engine power, performing a so called delayed stopping or a so called forced stopping. The code in the display tells the cause as described on the last pages of the engine manual. Engine fault Low Ad-blue level Ad-blue tank level...
  • Page 45: Threshing Equipment

    THRESHING EQUIPMENT STRAW DIVIDERS (Fig. L3) Can be Adjusted The straw dividers are tted on both sides of the cutting table. Their height is adjusted using slide pieces D with holes. Depending on the speci cation the dividers can be of the following types: Long torpedo dividers with xed frames Short torpedo dividers with xed frames...
  • Page 46 The REEL Has Four Adjustable Settings 5c 6c and 7c) 1. Reel height is controlled by switches A, g. L5c. 2. Reel speed is controlled by switches B, g. L5c. The switches are positioned on the front of the le- ver.
  • Page 47 CUTTING KNIFE Must Be Kept in Good Condition! Actual knife adjustments cannot be made during thresh- ing. The knife must be in perfect condition to produce good threshing results. For more precise service and adjustment instructions, see under Maintenance. A spare knife is stored in the case at the top of the table.
  • Page 48 CUTTING AND FEEDING MECHANISM RE- VERSE DRIVE L10a) Eliminates Blockage on the Table Blockage in crop feed may stop the table auger and crop elevator. This is cleared by running the feed mechanism backwards. To do this, disengage the drive to the table and press reverse switch Fig L10a.
  • Page 49 Height of the CUTTING TABLE (Figs. L12c, L13c and L14c) Switches A, g. L12c, adjust the height. Table lowering speed can be adjusted steplessly by turning the knob in the control valve above the right-side front fender. Speed increases clockwise and decreases counter-clockwise.
  • Page 50 STONE TRAP (Fig. L15) Must Be Emptied The stone trap prevents stones from getting into the concave. It is located between the crop elevator and concave. The hinged bottom can be opened and locked using lever A. The stone trap must be emptied daily; the contents of it must be of soft nature.
  • Page 51 Stepless Control of THRESHING CYLINDER Speed (fig. L18b) The speed of the threshing cylinder is controlled using switch fig. L18b . . The threshing cylinder speed is displayed in Comvision- display. Settings for various crops are given in the adjustment table on the cab window. L18b –...
  • Page 52 Adjusting of the CONCAVE Clearance (figs. L20a and L22a) The clearance between the threshing cylinder and concave can be adjusted steplessly using switch L20a. Clearance is displayed in gauge on panel in the right hand side see page 24. The adjusting mechanism has been designed to maintain the ratio between the front and rear clearances.
  • Page 53 Adjusting of PRE-CONCAVE Clearance between the pre-concave and pre-cylinder is adjusted steplessly with the left-hand sided switch fig. L20b, on the instrument panel. Press the lower part of the switch for wider clearance E, fig. L22b, and the upper part for smaller clearance. In Premium Plus cabin clearance is displayed in gauge on panel in the right hand side see page 24.
  • Page 54 CONCAVE FILLER PLATES (Fig. L24) Remove the Barbs The threshing effect of the concave can be improved by tting ller plates A under the rst concave beaters. Pass the ller plates through the holes at both ends of the con- cave where the springs keep them xed.
  • Page 55 Depending on the speci cation, there may be a chain- driven ruf ing drum above the straw walkers to uff up the mass of straw to improve grain separation. The ruf er nger angle can be adjusted by changing the position of the adjustment lever on the left side of the combine.
  • Page 56 SHAKER SHOE Adjustments (Fig. L28) The shaker shoe houses two sieves; the top one is an adjustable chaffer sieve and the bottom one either an exchangeable grain sieve or an adjustable lamella sieve. Settings for various crops are given in the “Approximate Settings“...
  • Page 57 Changing and Locking of SIEVES (Figs. L29 and L30) To change the grain sieve, release pawls A on the exten- sion bottom g. L29 and fully lower the bottom. Un- screw screws B of locking arm A g. L30 and pull lock- ing pieces C out of the holes on the shaker shoe wall, to draw locking arm A and the grain sieve off the frame.
  • Page 58 CLEANING FAN (Figs. L32, L33 and L34) The air ow is adjusted steplessly by changing the varia- tor speed. On electrically adjustable combines the speed regulating switch Fig.L32 is located on the instrument panel. The cleaning fan speed is displayed in Comvision-dis- play.
  • Page 59 AUGER HOUSING (Fig. L35) Bottoms Can Be Opened from the Side From the shaker shoe, the grains fall onto the front transport auger and the returns to the rear transport auger. The bottom troughs can be opened by lifting wire A from groove B and letting locking levers C go down, which will open the doors.
  • Page 60 Safe Working in the GRAIN TANK (Figs L38b and L39b) The grain tank is lled by the grain auger, and an alarm sounds when it is full. The height of the alarm sensor can be adjusted by moving the sensor from one hole to another.
  • Page 61 Turning and Operating of the UNLOADING PIPE (Figs. L41c) Switches C on the traction lever are used to swing the unloading pipe into the unloading position. The pipe rises by pressing the higher button and lowers by pressing the lower button. The safety switch K fig B2C must be activated in its top position before swinging of the unloading pipe.
  • Page 62 Danger Zone behind the STRAW CHOPPER (Figs. L45, L46 and L47) Beware of the rotating straw chopper knife! Never make adjustments or clean the chopper while the engine is running! Never stand in the no-access danger zone behind the ro- tating chopper! The degree of chopping can be varied by turning coun- ter knife beam A, g.
  • Page 63 Straw chopper with the guide plate The straw chopper is powered directly by the engine by means of a separate belt drive. The straw chopper will always switch on as the thresh- ing mechanism is started if the two locking pins A g. L48a on the straw chopper shaft are are pushed in.
  • Page 64 ENGINE, Source of Power The engine is a water-cooled four-stroke direct-injection diesel. For a more detailed description of the engine, see the engine manual. The power is transmitted from the rear of the engine to the traction, threshing mechanism, grain tank unloading and hydraulic pump.
  • Page 65 4th generation AGCO SISU POWER motors has adopted exhaust gas treatment with SCR technology Selective Catalytic Reduction . In SCR technology a liquid called DEF Diesel Exhaust Fluid is injected into exhaust gases. Most commonly known trademarks of DEF are AdBlue, Air1 and Greenox. For the DEF requirements, see engine manual.
  • Page 66 It is of utmost importance to use correct lubricating oil, in accordance with the load placed on the engine. See Lubrication Table un- der ”Maintenance”. Check the oil level daily before starting; it shall be between the minimum and maximum marks on dipstick A, preferably near the maximum, g.
  • Page 67: Comvision

    COMVISION This section deals with the use of the COM ISION monitor. In addition to grain losses the monitor also measures the threshed area, the threshing time used, it estimates the finishing time for the section, monitors and alarms the rotation speeds of certain shafts, adjusts reel speed, controls the grain tank filling up and measures the amount and quality of the returns.
  • Page 68 Work monitor Grain loss over sieves and straw walkers as well as the amount of return material is shown in the normal work screen. Furthermore, icons indicating excessive loss, reduced working width and a raised cutter bar also appear on this screen.
  • Page 69 Fuel con- Coolant tem- The engine sumption perature load percent- Oil pressure DEF con- voltage sumption The fuel tem- The charge DEF temper- perature air tempera- ature ture Exhaust tem- The outdoor Total fuel perature temperature consumption Charge pres- The fuel feed Operating sure pressure...
  • Page 70 Increase the reel speed in relation to the speed of Shaft revolu- Back to work the combine tions monitor Press the arrow on the right Figure L62 to open a new window. Select the functions shown in the figure. Clock Start/ Working width Decrease the reel speed in relation...
  • Page 71 Settings “Settings” opens up a menu Fig. L64. “Machine” Opens a menu for adjusting alarms, or to make the calibration for different functions. The Alarms window has two tabs. Alarms page #1 contains alarms for: Chopper Thresher Grain elevator Return elevator 1 Return elevator 2 Alarms page #2 contains alarms for: Straw walker...
  • Page 72 Fig. L68 shows an example of an alarm window. For example, minimum level and alarm state can be modified. For more detailed information: Letter i on a blue background shows that there is more infromation available by pressing icon i. The calibration can be performed for functions in the Fig.
  • Page 73 Speed calibration Fig. L72 On this screen there are two alternatives: Direct encoding of a known value Automatic calibration by driving 100 meters. Header height adjustment Fig. L73 On this screen you set the height at which the hectare counting and the reel speed adjustment are interrupted.
  • Page 74 Data Data menu, Figure L75, shows different Job, Total and Engine counters. User can also view the accumulated logs of alarms and working hours. Gauge Gauge, Figure L76, used when driving on the road. Console menu Use console menu, Figure L77, to adjust and calibrate the screen and to change the language and date time.
  • Page 75 Operation / adjustment There is no separate power switch in the equipment, but it gets switched on when the engine is started. Starting up takes a while. The basic factory settings can be adjusted to suit the conditions. The loss sensors have a three-position switch by which the basic setting is made. The symbol on the switch displays three different-size rings: a small one for hayseeds and rape, a medium size one for grain and a big one for peas and beans.
  • Page 76 Service Loss sensors require regular service. Their surfaces must be kept clean. In damp conditions dirt may accumulate on the sensor surfaces. Remove the dirt while still damp. Do not use a sharp tool, as the surface is a microphone cover.
  • Page 77: Dhc

    Presetting of Cutting Height Always keep the equipment in good condition. Make sure you repair any defects as soon as they appear. Faulty equipment must not be used. Before starting the combine, make sure the DHC se- lection switch A is in its mid position. Make it a rule to Keep in mind that when the equipment is switched on, there is an automatic movement.
  • Page 78: Driving And Threshing Instructions

    DRIVING AND THRESHING INSTRUCTIONS Before Starting the Combine Check that: There are no foreign objects inside the combine. The oil levels are correct engine, hydraulic tanks . There is coolant in the cooling system. There is fuel in the tank. The threshing mechanism and unloading pipe clutches are in neutral.
  • Page 79 When Driving on the Road: The brake pedals must be latched together. Brake smoothly as the rear wheels easily rise from the ground when applying the brakes violently. Never drive downhill with the gear in neutral. In accordance with the statutory traf c regulations when driving on the road, the cutting table guards shall be mounted, the front and rear lights correctly aligned, only the headlights on and the grain tank empty.
  • Page 80 Threshing Instructions Choose the Correct Time and Conditions Before starting the harvest, make sure that the crop to be threshed is ripe and dry enough. The germinating power of most crops is easily reduced if the threshing moisture exceeds 25%. Moreover, moist crops complicate harvesting and overload the threshing mechanism.
  • Page 81 For laid-down crops, set the reel forward, reel speed higher than the combine ground speed and the reel an- gled to facilitate the gathering of the crop, the knife cut- ting below the heads, g. M3. When using crop lifters, the reel should feed the cut crop onto the table auger with the reel tines in the normal position.
  • Page 82 Causes for table loss: The reel has threshed the grain onto the eld due to too high or low revolutions and too wide a clearance. Local blockage in the knife causes a depressed and uncut section in the eld. This may be due to a damaged knife plate or nger.
  • Page 83 If the sample is not clean, the reason could be: Insuf cient fan speed Incorrect direction of fans Grain sieve holes too large for crop Chaffer sieve set too wide open Forward speed too low insuf cient load on the threshing mechanism Crop sparse in places and weedy Cylinder-concave clearance too small Too many breaks in threshing turning, etc.
  • Page 84: Approximate Settings

    APPROXIMATE SETTINGS This table only gives recommended settings. While threshing, adjust the settings according to the harvesting con- ditions. Crop Threshing Concave Settings Shaker shoe Cylinder Main Chaffer Grain sieve hole Direction Concave Concave sieve Adjustment notch front mm open mm sieve mm 950...
  • Page 85: Service And Maintenance

    SERVICE AND MAINTENANCE Installations and adjustments can only be made by a person with the required skills and quali cations and the necessary knowledge of the machine in question. Installations, adjustments and repairs must be undertak- en with the engine stopped and the ignition key off. All the moving parts must be in balance and stopped and, when necessary, locked.
  • Page 86 The Functioning of the Combine Is Based on the Condition of the KNIFE Check that each knife holder touches the knife section lightly. Adjust by striking the holder down, g. P1. Check that each knife section touches the corresponding nger. If a knife section is bent, resulting in too wide a gap between the nger and knife section, replace the section.
  • Page 87 CHANGING OF THE KNIFE Belt-driven Knife First remove the lower guard of the knife drive. Re- move xing screws A, g. P5, on the connecting lever and remove the knife. Check the Knife Fore/Aft and Up/Down Po- sitions The fore aft direction is adjusted using screw joint A, g.
  • Page 88 Replacing of a KNIFE SECTION Screw-on knife sections Screw-on knife sections can be replaced without remo- ving the knife from the cutting table. Ensure that adjacent knife sections are aligned with each other. If necessary, remove the knife and align as shown in gures P13 and P14 or replace bent knife sections.
  • Page 89 TABLE AUGER FINGERS Must Be Straight Straighten or replace a bent nger. To remove the nger, which is necessary in both cases, open the door in the ta- ble auger housing and turn the auger until locking screw A can be unscrewed, g. P15. Place reel supports before undertaking any work! A bent nger will wear the guiding bearing and crankshaft bearing quickly.
  • Page 90 Slacken the table drive belt by turning lever A, g. P18, and remove the belt off the drive pulley of the sliding coupling shaft. Disconnect the feed cable for the table reverse from the quick release. Place the table support in between the knife n- gers, in the approximate centre of the knife, as shown in g.
  • Page 91 Adjusting of the CUTTING TABLE ANGLE in Soft Conditions: Remove the cutting table. Remove the ller beam from the joint between the feed elevator and the lower end of the table, g. P21. This adjustment may be necessary in such soft harvest- ing conditions in which the front tyres of the combine sink so deep into the soil that the position of the knife in relation to the ground changes.
  • Page 92 Checking of PRE-CYLINDER Clearance, Fig. Check the clearance using R152308. First turn the pre-concave to position 20. Turn down to position 12 mm. Make sure the clearance between the pre-cylinder and the concave is 12 mm. If necessary, adjust the length of supporters A with nuts B, g.
  • Page 93 BELT TENSIONING Check the tension of all the transmission belts on a reg- ular bases in accordance with the instructions. NOTE: Check the tension of all the belts after change. THRESHING MECHANISM DRIVE BELT The belt and its tensioning device are located under the left side guard of the combine and in the engine compartment.
  • Page 94 FAN VARIATOR BELTS To tension the belts, slacken nut A on the middle shaft of the variator pulleys and regulator nut B, g. P32. Nut C is slackened to move the variator pulleys in the direction indicated by the arrow, which will tension the belts. After the adjustment, tighten the slackened nuts.
  • Page 95 COOLER UNIT DRIVE (Rotating Inlet Screen) Belt tension is correct when length A of the spring is same as length of the tube covering it. 105 2 mm. If necessary, turn nut B to tension the belt. Fig. P30. FAN DRIVE BELT (Rotating Inlet Screen) Belt tension is correct when length A of the spring is same as length of the tube covering it.
  • Page 96 THRESHING CYLINDER VARIATOR BELT Standard Threshing Mechanism To tension the belt, tighten anchor bolts A and B (on the housing) and connecting bolt C (between the variator arms), g. P33a. The connecting bolt must be turned two turns per each turn of the anchor bolts, to retain the transmission ratio of the variator.
  • Page 97 THRESHING CYLINDER VARIATOR BELT The TS Threshing Mechanism To tension the belt, tighten anchor bolts A and B (on the housing) and connecting bolt C (between the variator arms), g. P33b. The connecting bolt must be turned two turns per each turn of the anchor bolts, to retain the transmission ratio of the variator.
  • Page 98 GRAIN ELEVATOR BELT Gear Driven Top Auger Belt tension is maintained by a spring-loaded jockey pul- ley. The tension is correct when length X of the spring, g. 35b, is 76...78 mm. When necessary, turn bushing A, g. P35b, to tighten the belt. GRAIN ELEVATOR OVERLOAD CLUTCH P35b The overload clutch is of friction plate type and located...
  • Page 99 GRAIN ELEVATOR CHAIN The Standard Threshing Mechanism Check the tension of the chain through the cleaning door at the bottom of the elevator. Check the tension with one tooth on the bottom sprocket pointing downwards. The tension is correct when the chain can be moved sideways by hand on the lowest sprocket, but there is no radial play.
  • Page 100 RETURN AUGER BELT and Overload Clutch Gear Driven Return Auger Belt tension is maintained by a spring-loaded jockey pulley. The tension is correct when the length of the threaded section of the spring is 105...110 mm. When necessary, the position of idler B can be changed. The overload clutch is located by the drive pulley of the gear.
  • Page 101 DRIVE BELT IN THE HYDRAULIC TRANSMISSION The appropriate tension in maintained automatically by a spring-loaded jockey pulley. The tension is correct when spring length corresponds with the length of the exter- nal gauge (70,5mm). When necessary, the adjustment is made with the engine stopped and the ignition key re- moved.
  • Page 102 CUTTING TABLE CLUTCH BELT Check the tension with the belt drive engaged. The tension is easier to adjust with the belt drive disen- gaged, but it must be checked while engaged. Slacken lock nut A, g. P47. Rotate the piston rod B until the spring tension X is 31- 37 mm.
  • Page 103 REEL VARIATOR BELTS To tension the belts, slacken nut A, g. P49a, at the end of the middle shaft and turn screw B so that the pulleys move upward tensioning both belts evenly. P49a THE ADJUSTMENT RANGE OF THE REEL VARIATOR After replacing or tensioning of belts, check the variator adjustment range.
  • Page 104 KNIFE DRIVE BELT The WB Knife Drive Spring-loaded jockey pulleys tension the belt automati- cally. In any case, check that pre-tension measurement X, g. P50, of the spring is 7…8 mm. If necessary, slacken lock nut A and turn bushing B up to achieve the afore-mentioned pre-tension measurement.
  • Page 105 BELTS WITH FIXED TENSION To tension the drive belts in the shaker shoe and table auger, slacken middle shaft A, g. P51, of the jockey pulley and either by screwing nut B (table auger) or moving the jockey pulley using a suitable lever tension the belt as required.
  • Page 106 Changing of CHOPPER KNIVES If the rotor knives (or knife) are worn, they can be in- verted. Broken or damaged knives must be replaced. To maintain the rotor balance, it is important always to change the two opposite knives as well. To remove a knife, unscrew locknut A, g.
  • Page 107 Removing a GIB KEY with a Tool To keep a gib key in good condition for re-use, use tool set R116007 to remove it, g. P58. with an ECCENTRIC RING A Removing: Slacken the grub screw in the locking ring and open the eccentric ring by hitting the ring in the opposite direction of shaft rotation with a mandrel.
  • Page 108 Adjustment of DRIVING BRAKES The brakes shall be adjusted regularly due to wear of the brake bands. Free travel of the brake pedals shall be 20-40 mm. To adjust the brakes, adjust screw turnbuck- le A, g. P62, on both sides of the combine. To make sure that the latched brakes do not veer, it is important to have the same free travel in both pedals.
  • Page 109 CAB Ventilation, Heating and Air Condition- Regular daily cleaning of the suction air lters is the most important maintenance measure. The lter is of two-stage type. At the front there is a course mesh lter in a frame. Behind it there is a ne lter, a replaceable paper element.
  • Page 110 ENGINE (Complete service and maintenance instructions for the engine are provided in a separate engine manual) Season The oil is changed every 300 h and in connection with the winter service. The old oil is drained from the warm engine by removing plug A off the oil drain pipe, g. P70 on the left side of the combine.
  • Page 111 Air Filter The engine suction air is puri ed by a pre- lter and a double-element, dry paper lter. Perfect functioning of the lter is an essential prerequisite for long engine life. The lter housing is located in the engine compartment. A control light on the front pillar indicates lter system blockage.
  • Page 112 Cleaning of the ENGINE RADIATOR (Fig. P76) Depending on the combine speci cation, in addition to water-cooling, the combine may be equipped with oil cooling, intermediate cooling for intake air and AC cool- ing. Depending on the type of engine, the cooling fan is t- ted either to the engine water pump or in front of the cooling cells.
  • Page 113 COOLING SYSTEM The coolant shall be changed every other year in order to maintain its anti-corrosion properties. The cooling system is drained by opening the drain taps on the left side of the engine at the rear and in the lower part of the radiator as well as the cap on the radiators expansion tank, gs.
  • Page 114: Gears

    GEARS GEARBOX (Fig. R1) Change the oil every 600 h or once a year. The oil is drained by unplugging oil drain A. New oil is poured into ller B. The oil level shall be be- tween the lower end of the ller dipstick and the marker with the cap screwed on.
  • Page 115 KNIFE DRIVE UNIT (Fig. R3) Check in opening C on the drive pulley that oil is level with the rim of the opening. Change the oil every 600 h or once a year. The oil is drained by unplugging oil drain A. Turn the pulley to an appropriate position.
  • Page 116 DIFFERENTIAL LOCK (Fig. R5) The lock needs to be adjusted if it does not function per- fectly, or if, for some reason, it has been necessary to disassemble it. With the adjustment make sure the cylinder does not push the engagement fork too far and that the disen- gaged position of the lock is suf ciently far from the engaged position.
  • Page 117: Hydraulics

    HYDRAULICS General Description Traction hydraulics and working hydraulics use a joint oil tank and lter. Both systems have their own pumps. Hydrostatic steering gets its oil from working hydraulics by means of a priority valve. The valve always supplies the amount of oil needed in steering and the rest can be used in other hydraulics.
  • Page 118 Used oil and lter are problem waste, which shall be disposed of in an appropriate manner. Use an oil type in accordance with the oil table. Make sure the oil is free from any impurities. Always use a clean funnel. After oil change let the engine idle for some 15 minutes during which time no hydraulics must be used.
  • Page 119: Electrical System

    ELECTRICAL SYSTEM The engine is equipped with an alternator. The master switch or the battery cables must not be disconnected with the engine running. FUSES Fig. S1 Fuses F1-F42 are located in circuit board (fig. S1c) under the instrument panel. Fuses F100-F116 are located in fusebox of the rear switchboard (fig.
  • Page 120 Fuses Main fuse 150A Switcboard Main fuse CTA diesel Relay, hydraulic safety Main fuse Relay, ignitionswitch (concave adjustment) Main fuse, diesel 3b Relay, cabin blower Main fuse, engine Relay, option Fuse, Grid heater 250A Relay, option Fuse, vertical knife RPM guard relay, drum Fuse, vertical knife Relay, blinkers Fuses circuit board...
  • Page 121 CTA engines (COMMON RAIL) The engine control unit is attached to the grain tank side of the engine. CTA engine fuse EEM current supply CTA engine fuses fig.S3b From the ignition lock EEM Fuel transfer pump Electric fuel pump Power on off EEM K107 The main power bypass, keeps power on until the engines urea pipes are empty.
  • Page 122 Sensors of ELECTRICAL SPEEDOMETERS The sensors of electrical speedometers (driving speed as well as fan and cylinder speeds) are located in the gearbox and at the ends of the respective shafts. To guarantee the correct functioning of the sensor, make sure that distance a between the sensor and the pulse disc (or the gear) is 1+ - 0.5 mm.
  • Page 123 BATTERY The gas generated by the battery is very explosive. Avoid open re and sparks in the vicinity of the battery. When servicing any electrical equipment, disconnect the negative cable of the battery. During the harvesting period the engine recharging equipment keeps the battery charged. At other times, check the state of the battery at regular intervals and recharge if necessary.
  • Page 124 If an auxiliary battery is needed for starting, proceed as follows: Check that the voltage of the auxiliary battery is 12 . Make sure the combine battery has not frozen; a at battery freezes in -10°C. Follow carefully the connecting sequence given below: With the auxiliary starting cables connect the positive poles of the batteries (marked with red paint, a P or a + symbol).
  • Page 125: Lubrication

    LUBRICATION Do not lubricate while the engine is running. Remove the key and lock the parking brake before starting lubricat- ing. The cutting table and reel supports must be locked or lowered when lubricating. The table below gives recommended lubricants to be used in different temperatures. The table also gives different types of air conditioning liquids, although they do not normally have to be changed.
  • Page 126 LUBRICATION DIAGRAM – 124 –...
  • Page 127: Summary Of Periodical Maintenance Procedures

    SUMMARY OF PERIODICAL MAINTENANCE PROCEDURES For more detailed instructions on engine adjustments and maintenance, see the engine manual. Daily: Every 300 working hours or yearly: Check the engine oil level. Change the engine oil and lter. Clean the engine compartment Change the engine air lters.
  • Page 128: Storage When Not In Use

    STORAGE WHEN NOT IN USE To guarantee the operating reliability of the combine, proper service and storage are of great importance. The ser- vice before winter storage can be divided into three parts, in order of performance: cleaning, checking and protec- tion.
  • Page 129 Pre-storage Service of Engine: Clean the engine on the outside. Change the fuel lters. Change the engine oil. Change the engine oil lter. Drain and clean the fuel tank. Check the anti-freezing quality of the coolant. It must be a minimum of - 25°C. Run the engine min.
  • Page 130: Recommended Tools And Accessories

    RECOMMENDED TOOLS AND ACCESSORIES For do-it-yourself maintenance it is necessary to replenish the tools supplied with the combine with the special tools mentioned under Maintenance as well as with the fork, ring and socket wrench kits, observing the wrench gap table below and the wrench gaps of 16, 17.5 and 27 mm for the hose and pipe couplings. Recommended Accessories General Parts Hexagonal screws M6-M12, the most common...
  • Page 131: Discarding Of The Combine

    DISCARDING OF THE COMBINE Even the best of products will come to the end of its useful lifetime and it is time to discard it. It is important to make sure the discarded combine will not be harmful to the environment. Below you will nd a list of things to consider before discarding the combine: Do not let the discarded combine spoil the scenery.
  • Page 132: Conversion To Maize Harvesting

    CONVERSION FOR MAIZE HARVESTING For maize harvesting, the combine can be tted with a 3- or 4-row maize header. Some other modi cations are also required to make the combine suitable for maize harvesting. The instructions are based on a combine equipped with the following components: HD front axle with oil bath type nal drives Table lifting mechanism tted with hydraulic rams dia 50 mm HD table drive...
  • Page 133 Replace the pulley (39 photo M2) with the hub (8 Figure M3), install the hub onto the shaft, but DO NOT TIGH- TEN HUB YET. Attach the sprocket and a large pulley (7 and 5, Figure M3). Remove the belt-tensioning device (16 and 29 g. M1) and t the chain tensioning device (44, 47 and 49 g. M3).
  • Page 134 – 132 –...
  • Page 135 Make sure that a wide-spaced HD concave has been tted. (Wire dia 8mm and clearance 14mm.) Fit the stone trap blanking plate (36 g. M4). The plate is xed with the same bolts as the lower sealing of the feeder elevator. Fit the ller plates (37 g.
  • Page 136 – 134 –...
  • Page 137 – 135 –...
  • Page 138 Rear Weights The Standard Threshing Unit The need for rear weights depends on the combine type and what kinds of accessories and cutting table are used. The main principle is that 20% of the total weight rests on the rear axle. Use of extra weights is not recommended with cereal header Approximately 600 kg of additional weight is required on a combine with standard threshing mechanism (with the weight of the maize header 1400 kg).
  • Page 139 3 When Harvesting in Freezing Conditions Remember to clean the elevators and grain augers daily after threshing. If this is not done, they may be frozen the next morning, which will damage them. When modifying the combine back to cereal harvesting, special parts and components shall be replaced with the original ones intended for cereal harvesting.
  • Page 140: Threshing Equipment To Be Used With Sunflower

    THRESHING EQUIPMENT TO BE USED WITH SUNFLOWER No special threshing equipment is necessary when harvesting sun ower. The basic cutting table can, however, not be used with sun ower. The seeds fall off easily and the whole ower heads may fall onto the ground in front of the knife.
  • Page 141 The center trays are tted using the quick coupling next to each clamp. Adjust the tightness of the quick coupling when doing the installation. The outer trays are tted at their ends to the side guide with screw D, g. 22. The rear end is xed with screws A, g.
