- Page 1 INSTALLATION MANUAL IGLU Aleut Series...
-
Page 2: Table Of Contents
Technical data of IGLU Aleut fixed capacity heat pumps ............18 Technical data of IGLU Aleut WT fixed capacity heat pump with water heater ....19 Technical data of IGLU Aleut 18 WTI variable capacity heat pump with integrated water heater .............................. - Page 3 Technical data of IGLU Aleut 13 fixed capacity heat pump ..........25 Technical data of IGLU Aleut 5 WT fixed capacity heat pump with boiler ......26 Technical data of IGLU Aleut 7 WT fixed capacity heat pump with boiler ......27 Technical data of IGLU Aleut 9 WT fixed capacity heat pump with boiler ......
-
Page 4: Introduction
INTRODUCTION This installation manual provides information on the installation of the IGLU heat pump. It is an integral part of the product and must be easily accessible to the installer. The manual must be available throughout the life of the device. In the event of a change in the owners of the device, the manual must be passed on to the new owners or users. -
Page 5: Safety
SAFETY The device is safe to use as intended. The construction and design of the device comply with all safety regulations. Prior to starting work, any person involved must read and understand the operating instructions. This also applies if the person concerned has already worked on such or similar equipment or has been trained by the manufacturer. -
Page 6: Selection Of The Installation Place
SELECTION OF THE INSTALLATION PLACE When choosing the installation place of the heat pump, keep in mind that the heat pump produces a certain level of noise (see table “Heat pump technical data”). The device must be mounted on a flat and stationary surface with a permissible load of at least 500 kstr. -
Page 7: Automatic Air Release Valves
Automatic air release valves In order to ensure that no air clogs occur in the outdoor circuit system and that the heat pump does not signal an alarm as a result, it is necessary to install automatic air release valves on the outdoor circuit. -
Page 8: Flow Through The Heating System
Flow through the heating system A bypass is required in the mixing circuit, if an adjustable circulation pump is used, which is controlled by differential pressure. Bypass is not included with the heat pump. If a buffer tank bypass is installed in parallel with the heating system, no bypass is required. Heating system filter and valves The heat pump does not include a filter and a safety valve. -
Page 9: Thermal Insulation
- regular maintenance and prevention. It is recommended that a system log be kept containing the relevant maintenance data. Damage that may occur due to a malfunctioning system Component failures (e.str., pumps, valves) Internal and external leaks (e.str., from heat exchangers) ... -
Page 10: Temperature Sensors
Temperature sensors The temperature sensors for the outdoor and water heater are connected to the terminal blocks, which are shown in the layout diagram of the control elements (see, Section: “Heat pump electrical connection diagram”). A two-core 0.5 ÷ 1mm cable must be routed from the heat pump to the outdoor temperature installation location. -
Page 11: Control Panel
Input voltage Power source Relay output WARNING! Do not connect anything to the terminals that are dark grey The phase sequence relay also responds to voltage that is too low or too high. If the voltage is too low or too high, the compressor operation will stop. When the voltage is within tolerance again, the compressor operation is resumed. - Page 12 Heat pump inlet Šilumos siurblio įvadas from separate automatic switch Atsiurbimo temperatūra, NTC-10K iš atskiro automatinio jungiklio MCX061V Suction temperature, NTC-10K Incoming glycol temperature, NTC-10K Įeinančio glikolio temperatūra, NTC-10K N PE Outgoing glycol temperature, NTC-10K MŠ1 Išeinančio glikolio temperatūra, NTC-10K 230VAC Outdoor temperature, NTC-10K Lauko temperatūra, NTC-10K...
-
Page 13: Arrangement Of Controls
ARRANGEMENT OF CONTROLS Compressor thermal Kompresoriaus šiluminė apsauga protection Valdymo grandinių automatinis Automatic circuit breaker for control Šilumos siurblio įvadas Heat pump inlet from a išjungiklis circuits iš atskiro automatinio separate circuit breaker jungiklio Lauko temp. daviklio gnybtų rinklės Neutral terminal Outdoor temperature sensor terminal Neutralės gnybtynas Kambario temp. -
Page 14: Heat Pump Classic Connection Diagram
HEAT PUMP CLASSIC CONNECTION DIAGRAM The most popular heating system connection diagram, which is the most cost-effective in terms of cost and installation. When the hot water is heated to the set temperature, a three-way valve inside the heat pump switches to home heating, where the heat is transferred to the home in a low-temperature medium. -
Page 15: Connection Diagram For Heat Pump With Passive Cooling
CONNECTION DIAGRAM FOR HEAT PUMP WITH PASSIVE COOLING This diagram shows the hydraulic diagram of the heating system when passive cooling is used. This connection method ensures comfort all year round. The heating system is similar to the classic one, but in this case it is necessary to lay the pipes to the fan radiators (fan coils). In addition, a three-way valve is installed on the outdoor circuit, which regulates the direction of glycol flowing from the outdoor circuit during the warm season. -
Page 16: Heating System With Buffer Capacity
HEATING SYSTEM WITH BUFFER CAPACITY This diagram provides a hydraulic diagram of the heating system, when the temperature control of individual room circuits by actuators is provided in the object. It is recommended to install a buffer tank for fixed capacity heat pumps when planning to regulate the temperature for individual rooms. -
Page 17: Heating System With Passive Cooling And Buffer Capacity
HEATING SYSTEM WITH PASSIVE COOLING AND BUFFER CAPACITY This connection method allows to take full advantage of the heating and cooling functions. The diagram shows the hydraulic diagram of the heating system, when the temperature control of individual room circuits by actuators and cooling function using fan radiators is provided in the object. -
Page 18: Technical Data Of Iglu Aleut Fixed Capacity Heat Pumps
Technical data of IGLU Aleut fixed capacity heat pumps Units 5 kW 7 kW 9 kW 11 kW 13 kW Brine/water used Thermal power (B0/W35) 5.24 7.25 9.22 10.95 13.07 Thermal power (B0/W45) 4.89 6.85 8.67 9.98 12.30 COP (B0/W35) 4.37... -
Page 19: Technical Data Of Iglu Aleut Wt Fixed Capacity Heat Pump With Water Heater
Technical data of IGLU Aleut WT fixed capacity heat pump with water heater Units 5 kW 7 kW 9 kW 11 kW 13 kW Brine/water used Thermal power (B0/W35) 5.24 7.25 9.22 10.95 13.07 Thermal power (B0/W45) 4.89 6.85 8.67 9.98... -
Page 20: Technical Data Of Iglu Aleut 18 Wti Variable Capacity Heat Pump With Integrated Water Heater
Technical data of IGLU Aleut 18 WTI variable capacity heat pump with integrated water heater Units Power network connection values Electrical connections 400 V 3 N~50 Hz Inertial fuse; with electric heater 3 kW 16-20-25 Compressor rated power consumption 2.84 (B0/W35) @ 60 rps Max. -
Page 21: Annex No 1
Annex No 1 Annex to the technical characteristics according to European Commission Regulation No 813/2013 Technical data of IGLU Aleut 5 fixed capacity heat pump Model IGLU Aleut 5 Air-to-water heat pump Water-to-water heat pump Ground-to-water heat pump Low temperature heat pump... -
Page 22: Technical Data Of Iglu Aleut 7 Fixed Capacity Heat Pump
Technical data of IGLU Aleut 7 fixed capacity heat pump Model IGLU Aleut 7 Air-to-water heat pump Water-to-water heat pump Ground-to-water heat pump Low temperature heat pump Equipped with supplementary heater Supplementary heater is used Parameters applied using average temperature are declared. Parameters are declared under average climatic conditions. -
Page 23: Technical Data Of Iglu Aleut 9 Fixed Capacity Heat Pump
Technical data of IGLU Aleut 9 fixed capacity heat pump Model IGLU Aleut 9 Air-to-water heat pump Water-to-water heat pump Ground-to-water heat pump Low temperature heat pump Equipped with supplementary heater Supplementary heater is used Parameters applied using average temperature are declared. Parameters are declared under average climatic conditions. -
Page 24: Technical Data Of Iglu Aleut 11 Fixed Capacity Heat Pump
Technical data of IGLU Aleut 11 fixed capacity heat pump Model IGLU Aleut 11 Air-to-water heat pump Water-to-water heat pump Ground-to-water heat pump Low temperature heat pump Equipped with supplementary heater Supplementary heater is used Parameters applied using average temperature are declared. Parameters are declared under average climatic conditions. -
Page 25: Technical Data Of Iglu Aleut 13 Fixed Capacity Heat Pump
Technical data of IGLU Aleut 13 fixed capacity heat pump Model IGLU Aleut 13 Air-to-water heat pump Water-to-water heat pump Ground-to-water heat pump Low temperature heat pump Equipped with supplementary heater Supplementary heater is used Parameters applied using average temperature are declared. Parameters are declared under average climatic conditions. -
Page 26: Technical Data Of Iglu Aleut 5 Wt Fixed Capacity Heat Pump With Boiler
Technical data of IGLU Aleut 5 WT fixed capacity heat pump with boiler Model IGLU Aleut 5 WT Air-to-water heat pump Water-to-water heat pump Ground-to-water heat pump Low temperature heat pump Equipped with supplementary heater Supplementary heater is used Parameters applied using average temperature are declared. Parameters are declared under average climatic conditions. -
Page 27: Technical Data Of Iglu Aleut 7 Wt Fixed Capacity Heat Pump With Boiler
Technical data of IGLU Aleut 7 WT fixed capacity heat pump with boiler Model IGLU Aleut 7 WT Air-to-water heat pump Water-to-water heat pump Ground-to-water heat pump Low temperature heat pump Equipped with supplementary heater Supplementary heater is used Parameters applied using average temperature are declared. Parameters are declared under average climatic conditions. -
Page 28: Technical Data Of Iglu Aleut 9 Wt Fixed Capacity Heat Pump With Boiler
Technical data of IGLU Aleut 9 WT fixed capacity heat pump with boiler Model IGLU Aleut 9 WT Air-to-water heat pump Water-to-water heat pump Ground-to-water heat pump Low temperature heat pump Equipped with supplementary heater Supplementary heater is used Parameters applied using average temperature are declared. Parameters are declared under average climatic conditions. -
Page 29: Technical Data Of Iglu Aleut 11 Wt Fixed Capacity Heat Pump With Boiler
Technical data of IGLU Aleut 11 WT fixed capacity heat pump with boiler Model IGLU Aleut 11 WT Air-to-water heat pump Water-to-water heat pump Ground-to-water heat pump Low temperature heat pump Equipped with supplementary heater Supplementary heater is used Parameters applied using average temperature are declared. Parameters are declared under average climatic conditions. -
Page 30: Technical Data Of Iglu Aleut 13 Wt Fixed Capacity Heat Pump With Boiler
Technical data of IGLU Aleut 13 WT fixed capacity heat pump with boiler Model IGLU Aleut 13 WT Air-to-water heat pump Water-to-water heat pump Ground-to-water heat pump Low temperature heat pump Equipped with supplementary heater Supplementary heater is used Parameters applied using average temperature are declared. Parameters are declared under average climatic conditions. -
Page 31: Technical Data Of Iglu Aleut 18 Wti Heat Pump With Integrated Boiler
Technical data of IGLU Aleut 18 WTI heat pump with integrated boiler Model IGLU Aleut 18 WTI Air-to-water heat pump Water-to-water heat pump Ground-to-water heat pump Low temperature heat pump Equipped with supplementary heater Supplementary heater is used Parameters applied using average temperature are declared. Parameters are declared under average climatic conditions. -
Page 32: Annex No 2
Variable power heat pumps with integrated water heater (200 l) Thermal Model Outdoor circuit pump Internal circuit pump capacity IGLU Aleut 18 WTI 5-18KW UPMXL 25-125 180 PWM UPMXL 25-125 180 PWM Fixed power heat pumps with integrated water heater (200 l) Thermal... -
Page 33: Annex No 3
Annex No 3 UPM3 K FLEX AS 25-75 180 characteristic UPM3 K FLEX AS 25-75 180 electrical parameters, 1 x 230 V, 50/60 Hz Speed Min. 0.04 Max. 0.58 Dimensions of the UPM3 circulation pump... -
Page 34: Annex No 4
Annex No 4 UPMXL GEO 25-125 180 PWM, 1 x 230 V, 50/60 Hz characteristics UPMXL GEO 25-125 180 PWM electrical parameters, 1 x 230 V, 50/60 Hz Speed Min. 0.06 Max. Dimensions of the UPMXL circulation pump... -
Page 35: Annex No 5
Annex No 5 Heat pump dimensions and connection nozzles Front view Side view Rear view 62cm 62cm 62cm Čia: Where: A - paduodamo termofikato pajungimo atvamzdis; A – supply heating water connection nozzle; B - paduodamo termofikato į boilerį atvamzdis; C - grįžtančio termofikato pajungimo atvamzdis;... -
Page 36: Annex No 6
Annex No 6 Design dimensions of the heat pump from the front >5cm 62cm 62cm >5cm >5cm Design dimensions of the heat pump from the top >5cm 62cm 62cm 62cm... - Page 37 Notes _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________...
