- Page 1 CUBICNM 03.17 SANICUBIC ® SANICUBIC ® SANICUBIC 1 WP ® SANICUBIC 2 Classic ® SANICUBIC 2 Pro ® SANICUBIC 2 XL ® Notice de service / montage • Operating / installation manual • Bedienungs- / Installationsanleitung • Manuale per l’uso e l’installazione •...
-
Page 2: Table Of Contents
CONTENTS Glossary .......................19 1. - Page 3 All rights reserved. The contents of this document must not be reproduced, modified or disclosed to third parties except upon written consent from the manufacturer. This document may be subject to change without notice. SFA – 41 Bis Avenue Bosquet – 75007 PARIS 03.2017...
-
Page 4: Glossary
GLOSSARY Ventilation pipe Pumping station for blackwater Ventilation duct limiting pressure variations Facilities for the automatic collection and inside the blackwater pumping station. The pumping of wastewater and blackwater pumping station must be ventilated above above the back-flow level. the roof. ND (Nominal Diameter) Dual station Parameter used to characterise parts that are... -
Page 5: Safety
• Pumping stations discharging fluids that may be harmful to health must be SAFETY decontaminated. Before restarting the pumping station, follow the commis- sioning instructions. (c section 5.1, page 7) This device may be used by children who are at least 8 •... -
Page 6: Description
Frequency above the back-flow level to flow into the discharge line. Protection index - SANICUBIC® 1/SANICUBIC 1® WP contains one pump equipped with a high- performance shredding system. Date of production - SANICUBIC® 2 Classic/SANICUBIC® 2 Pro contains two independent pumps. -
Page 7: Technical Data
Waste pipe Ø ext. 50 mm Inlet Ø ext. 40, 50, 100, 110 mm 3 .5 Technical data Ventilation Ø ext. 50 mm Pumping station for blackwater (submersible for the SANICUBIC® 1 WP, SANICUBIC® 2 Classic, SANICUBIC® 2 Pro, SANICUBIC® 2 XL versions). SANICUBIC®... -
Page 8: Control Box
3 .7 Alarm unit Protection Station: IP68 Control box: IPX4 3 .7 .1 Technical characteristics of the alarm device Max. recommended height 14.5 m (DN80) 13 m (DN100) SANICUBIC® alarm unit: SANICUBIC® 1; SANICUBIC® 1 WP; SANICUBIC® 2 Classic; SANICUBIC® 2 XL: Max. -
Page 9: Installation / Fitting
The electrical power supply must be protected with a high Fit a shutoff valve behind the check valve . sensitivity circuit breaker set to 10 Mini Amps for SANICUBIC 1/ SANICUBIC 1 The check valves are equipped with a lever for emptying WP and 20 Mini Amps for SANICUBIC 2 Classic/SANICUBIC 2 Pro/SANICUBIC the discharge pipe into the tank . -
Page 10: Cellar Drying
4 .5 Cellar drying Operations required for commissioning Automatic drying: 1. Perform a functional and sealing test of the pumping station: Once the For automatic drainage of the installation room (in case a sump is installed, hydraulic and electrical connections are made, check the connections for for example), especially in case of risk of water infiltration or flooding, a leaks by running water successively through each inlet used. - Page 11 Figure 2: Ventilation of the SANICUBIC® control box 6 .2 .1 Operation of the SANICUBIC® 1 / SANICUBIC® 1 WP SANICUBIC® 2 Classic /SANICUBIC® 2 XL wired alarm unit The SANICUBIC® alarm unit does not require a separate power supply. The power is supplied through the SANICUBIC®.
- Page 12 Warning: The incoming feed for inlets must be minimised while performing ANOMALY DETECTED CAUSES PROBLEMS SOLUTIONS maintenance • Water level detection • Consult SFA after-sales Flashing red alarm LED 2. Turn off the power supply. system faulty service 7 .5 Checking the hydraulics of each motor •...
- Page 13 3. If necessary unclog the compression chambers. 7 .5 .4 Reassembly of the level sensors For any problem not described in the table below, contact SFA after-sales Warning: Do not grease the level sensors’ O-rings before reassembly. service.
- Page 14 APPENDICES SANICUBIC 1 - SANICUBIC 1 WP sizing diagram SANICUBIC® 2 Classic – SANICUBIC® 2 Pro sizing diagram Dimensional drawing SANICUBIC® 2 XL...
- Page 15 PRESNIV ON CUBIC CONTROL BOX • 1 : brown • 2 : black • 3 : grey...
