1. SAFETY ..............pg.4 1.1 Labelling of instructions in the operating instructions ...pg.4 1.2 Qualification and training of staff ........pg.5 1.3 Hazards caused by non-observance of the safety instructions pg.5 1.4 Safety-conscious work .............pg.5 1.5 Safety instructions for user / operator ......pg.5 1.6 Safety instructions for maintenance, inspection and installation work .pg.5 1.7 Unauthorised modification and spare parts production ..pg.6 1.8 Impermissible operating modes ........pg.6...
1. SAFETY WARNING This device can be used by children who are at least 8 years old and by people with reduced physical, sensory or mental capacities or those without knowledge or experience, if they are properly supervised or if they have been given instructions on safely using the device and the associated risks have been understood.
rotational direction arrow, sign for fluid connections) and must be kept fully legible. 1.2 Personnel qualifications and training The staff for operation, maintenance, inspection and installation must have the corresponding qualification for this work. For this reason, the area of responsibility, the competency and the supervision of the staff has to be precisely defined by the company.
1.7 Unauthorised modification and spare parts production Modifications or changes to the machine shall be permissible only after consultation with the manufacturer. Original spare parts and accessories authorised by the manufacturer serve to ensure safety. The use of other parts may results in the loss of liability for the consequences that may occur.
Operating Limits : • The lifting unit is not designed for continuous operation! The conveying data stated on the factory plate apply only for intermittent periodic duty (S3 25 %). • The maximum permissible feed flow must always be smaller than the feed volume of a pump (see type plate).
- The installation location should be a well-ventilated, dry and frost-free room. - The installation site must be amply dimensioned. The room height should be approx. 2 to 2.5 m. According to DIN 1986, Part 3, the following applies: “All plant components... (and)... all operating elements...
pump. For installations in bathrooms and showers, the corresponding regulations of DIN VDE 0100 Part 701 have to be observed. • Please observe the regulations of EN 12 056-4. • For AC power connection, external protection has to be carried out with circuit breakers of characteristic K, generally 3-pole mechanically locked.
7.2 Maintenance work All power supplies must be disconnected ! 7.2.1 Collecting tank Open the inspection cover and flush the tank by means of using a hose in order to loosen dirt deposits on the tank walls. 7.2.2 Non-return valve Open the inspection cover and clean the interior of the non-return valve. 7.2.3 Miscellaneous All further maintenance works must be carried out by qualified service personnel.
Malfunction Cause Troubleshooting 2. Motor rotates, but - Impeller clogged or worn - Clean/replace does not convey - Check valve clogged - Clean - Shut-off valve clogged or closed - Clean/open - Pressure line clogged - Clean - Intake socket clogged - Clean - Direction of rotation incorrect - Correction...
Page 18
SOUTH AFRICA ITALIA POLSKA Saniflo Africa (PTY) Ltd SFA ITALIA spa SFA POLAND Sp. z O.O. Unit A6 , Spearhead Business Park Via del Benessere, 9 ul. Białołęcka 168 Cnr. Freedom Way & Montague Drive 27010 Siziano (PV) 03-253 Warszawa Montague Gardens, 7441 Tel.
