How to Troubleshoot Wireless Access (Wi-Fi) on the Qwest® Premium Networking
Use this document if:
You want to change one or more of the following settings to troubleshoot your Qwest Premium
Networking Modem: Motorola 3347 for wireless issues:
1. Reset your modem to factory defaults (Step 1)
2. Reprogram your modem (Step 5)
3. Change your SSID or Network Name (Step 11)
4. Change your Security Key (Step 12)
5. Change the Wireless Channel (Step 16)
This document assumes:
That you have your PPP username and password that was provided by your Internet
Service Provider (ISP).
Your computer is directly connected to the modem using an Ethernet cable.
The Qwest Premium Networking Modem: Motorola 3347 is powered on.
© 2008 Qwest Communications International Inc.
Modem: Motorola® 3347
Internet Service Provider (ISP):
All
to look up your ISP's contact information.
Click here
Advertisement
Related Manuals for Motorola 3347
Summary of Contents for Motorola 3347
- Page 1 ISP’s contact information. Service Provider (ISP). Click here Your computer is directly connected to the modem using an Ethernet cable. The Qwest Premium Networking Modem: Motorola 3347 is powered on. © 2008 Qwest Communications International Inc.
- Page 2 1. Open a web browser, type 192.168.0.1, and press enter. 2. Select Advanced Setup from the left column. © 2008 Qwest Communications International Inc.
- Page 3 3. Select Reset Router from the left column. 4. Select Yes, reset to factory settings. © 2008 Qwest Communications International Inc.
- Page 4 5. After your modem has rebooted, select Quick Setup from the left column. 6. Select PPP over Ethernet LLC/SNAP. 7. Enter the PPP username and password that was provided to you by your Internet Service Provider (ISP). © 2008 Qwest Communications International Inc.
- Page 5 8. Complete the next steps according to your ISP’s instructions, then select Save Changes. Listed below are the most common settings. 9. After your modem has rebooted, select Wireless from the left column. © 2008 Qwest Communications International Inc.
- Page 6 10. Check the Enable Wireless box. 11. Your default SSID is already selected and will show next to ‘Wireless ID (SSID)’. This is the name of the wireless network. You can change it (remember: SSID’s are cAsE sEnSiTiVe.) or leave it the same. 12.
- Page 7 13. Next to ‘Encryption Key #1’ is your default WEP Security Key. This is the security key that will need to be entered when connecting to the wireless network. You can either use the Default WEP Security Key, or if you would like to use your own customized WEP security key, delete the default key and type in 26 characters.
- Page 8 15. These are the steps for changing the wireless channel your modem transmits on. Select Wireless from the left column. 16. Select the Advanced Configuration Options arrow. 17. Select OFF-Use default from the ‘AutoChannel Setting’ dropdown. © 2008 Qwest Communications International Inc.
- Page 9 19. Select Yes when prompted to restart your router. The modem will then take a few minutes to reboot. 20. You can now attempt to connect to the wireless signal being transmitted by your Qwest Premium Networking Modem: Motorola 3347. © 2008 Qwest Communications International Inc.
