Page 1: Quick Start
Quick Start 24x8 Cable Modem Plus AC1900 Router Plus 2 Phone Lines MT7711... - Page 2 Packaged with your MT7711 modem/voice/router Power Cube Coax Wrench Ethernet Cable Velcro ® Cable Organizer Para una Guía de Inicio Rápido en español, por favor vaya a www.motorolanetwork.com/MT7711IR...
-
Page 3: Let's Get Started
If you don’t have cable Internet service, please order that from your cable service provider. Now connect your MT7711 as shown on the next panel. Connecting to a Coax Cable Soon you’ll need to connect your MT7711 to a “live”... -
Page 4: Wps Button
ON/OFF button POWER Connect the supplied power cube between the power jack and an electrical outlet. PHONE (TEL1-2) You can connect a telephone to either of these 2 telephone jacks. ETHERNET (LAN 1-4) You can connect a computer, HDTV, game station, or other Ethernet- capable device to any of these 4 LAN ports. - Page 5 By now you should have: Subscribed to cable Internet service. Connected your MT7711. Powered up your MT7711. To do this, the On/Off button needs to be On. Wait for the green online connection light to stop flashing and remain solidly lit.
- Page 6 1 (877) 692 2253 1 (888) 556-1193 1 (866) 832-4726 Once your MT7711 is activated either online or by phone, your service provider will provision your MT7711 service. Typically this takes less than 5 minutes, but in some cases this may take 30 minutes or longer to complete.
-
Page 7: Configuration Manager
You want to set up parental controls including white lists and/or black lists for certain users and times. You want to get performance information about the MT7711 modem and/or built-in router. This can be helpful in optimizing wireless performance. -
Page 8: Front Panel Lights
Note that wireless performance depends on a number of factors. Please keep these things in mind: Where possible, put the MT7711 in a central place so that it’s not too far away from your other wireless devices. Try to avoid interference from other wireless devices such as Bluetooth headsets and stereos, and 2.4 GHz cordless phones and... - Page 9 fail Power Green Blinking: Scanning for DS channel Green Connected on 1 downstream channel Green ON: † Downstrea Blue Blinking: Negotiating bonded channel(s) Blue Blue ON: Bonded with 2 or more channels Green Blinking: Ranging in progress Connected on 1 channel Green ON: Green †...
-
Page 10: Troubleshooting Tips
Troubleshooting Tips What if I can’t make an Internet connection right after installation? First turn your MT7711 off for at least 8 seconds, then on, to see if that fixes the problem. Check the connections you’ve made to your MT7711. Power and coax connections are required, and up to 4 Ethernet connections are optional. - Page 11 This lets you see whether your home’s cabling is a problem. If you’re using a splitter with your MT7711, try the MT7711 without the splitter to see if that helps. If it does, you may need to get a better splitter.
- Page 12 Bluetooth transmitters and neighbors’ Wi-Fi routers. To try to pick a less used wireless channel for your MT7711, first go in to your MT7711’s Configuration Manager. Click the Advanced button at the top of the page, then click the Wireless and Scan/Bridge menu items at the top of the page.
-
Page 13: Limited Warranty
We like to help. Please visit our support Website or call our support specialists. Our Website has our Motorola Mentor information, and also provides returns and warranty information. www.motorolanetwork.com/support Email: support@motorolanetwork.com Phone: 800-753-0797 Limited Warranty MTRLC LLC warrants this product against defects in material and workmanship for a warranty period of 2 years. -
Page 14: Safety Precautions
Your MT7711 should be operated in an environment that’s between 32 and 104° Fahrenheit (0 to 40° Centigrade). Your MT7711 should not be in a confined space. There should be room for air flow around the top, front, and sides of the MT7711.
