O P E R A T I N G I N S T R U C T I O N S
Ranger3
3D machine vision

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ranger3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SICK Ranger3

Summary of Contents for SICK Ranger3

  • Page 1 O P E R A T I N G I N S T R U C T I O N S Ranger3 3D machine vision...
  • Page 2 Original document This document is an original document of SICK AG. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 3: Table Of Contents

    Prerequisites for safe operation of the device........Connecting the camera................Electrical connections................8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...
  • Page 4 Using the interface................... 9.2.1 Connecting and getting a 2D image........O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...
  • Page 5 13.7 Dimensional drawings................Accessories..................85 Glossary....................86 15.1 Terms and abbreviations................8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...
  • Page 6 16.5 EU declaration of conformity / Certificates..........114 16.6 Scheimpflug adapters................114 O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 7: About This Document

    … highlights useful tips and recommendations as well as information for efficient and trouble-free operation. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 8: Safety Information

    SICK AG. This applies in particular to opening the housing, even as part of mounting and electrical installation. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...

  • Page 9: Cybersecurity

    Knowledge of the software and hardware environment for the ■ particular application 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 10: Operational Safety And Particular Hazards

    EN/IEC 60825–1 and 21 CFR 1040.10/11 must be fulfilled. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...

  • Page 11: Getting Started

    Power supply 24 V DC Connection module CDB650-204 Encoder 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...
  • Page 12 "Using the interface", page O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 13: Product Description

    8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...
  • Page 14 Before the camera can be used in a machine vision system, the following needs to be done: O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...

  • Page 15: Hardware Description

    Booting (slow flashing) or firmware Ö upgrade (fast flashing) 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 16: Interface And Communication Standards

    For information about installation, see "Software installation", page O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...
  • Page 17 The most basic C++ code to grab an image: 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 18: Transport And Storage

    Do not expose to any aggressive substances. • Protect from sunlight. • Avoid mechanical shocks. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...
  • Page 19 For storage periods of longer than 3 months, check the general condition of all components and packaging on a regular basis. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 20: Mounting

    It is recommended to use an optical band-pass filter to reduce ambient light. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...

  • Page 21: Mounting An Optical Filter Or A Scheimpflug Adapter

    Without a filter, the focusing of the lens may not work properly. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 22: Electrical Installation

    O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...

  • Page 23: Prerequisites For Safe Operation Of The Device

    Closed current loop with equalizing currents via cable shield 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...
  • Page 24 Within the islands, a stable equipotential bonding prevents equalizing currents on the cable shields. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...

  • Page 25: Connecting The Camera

    Never connect a powered Power-I/O terminal or powered I/O signals to a camera. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 26: Electrical Connections

    There are two connectors and four LEDs on the back plate of Ranger3. Figure 10: Back plate of the Ranger3 device O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...

  • Page 27: Power I/O Connector

    When using a single-channel encoder, connect it to Encoder Input A+/A- (pin 5 and Encoder types Ranger3 supports the following encoder types: 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 28: Gige Connector

    GETH L2- GETH L4+ GETH L4- GETH L3- GETH L3+ O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 29: Connecting A Cdb650-204

    I/O 1 24 V input I/O 2 24 V input 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...
  • Page 30 5/24 V input ß Power supply 24 V input à O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 31: Configuration

    RegionSelector decides which region that is manipulated. This means that Width[Region1] is the width of the region named Region1. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 32: Configuring Ranger3

    "Selectors", page According to GenICam™ SFNC version 2.4. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 33: Sensor Regions

    3D linescan output data. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 34: Device Scan Type

    RegionMode[Region0] = On RegionMode[Region1] = Off RegionMode[Scan3dExtraction] = Off O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 35: Maximum Buffer Size

    8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 36: Range (3D) Measurements

    Figure 19: The impact position of the laser in one column Intensity Sensor row ROI end O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 37: Measurement Method

    Rapid On-Chip Calculation 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 38: Detection Threshold

    ROI end ROI start Detected peak Not detected peaks O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 39: Image Format

    It also allows a higher scan rate when having a large number of rows in ROI, but then resolution will be sacrificed. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 40: Additional Components

    O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...
  • Page 41 The Scatter offset and Scatter width are denoted in the figure. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...
  • Page 42 Figure 28: Example of FrontSideBand scatter sampling. The sampling window is shown in gray. Laser peak position WAM window O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 43: High Dynamic Range (Hdr) Imaging

    Figure 31: Resulting profile, linear (non-HDR) mode HDR mode profiles 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...
  • Page 44 Linear (non-HDR) mode Soft pre-set Medium pre-set Aggressive pre-set O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 45: Triggering

    8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 46: Triggering Using An Encoder

    2D image is triggered and the camera resets the triggering condition counter. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...
  • Page 47 35. The trigger point depends on the type of encoder used: 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 48: Frame Triggering

    To avoid unnecessary CPU load, set the Height[Scan3dExtraction1] parameter to no less than 100 pixels. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...

  • Page 49: Profile Meta Data

    To enable profile meta data, select the Profile meta data checkbox. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 50: Operation

    The Help menu includes options to get further help with and knowledge about the application, for example, the application version. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...

  • Page 51: Parameter Editor

    Click a locked input field to unlock it and stop the image acquisition. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 52: Workflow Steps

    110. Then you have to reconfigure the camera to the same subnet, before you can connect to it. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...
  • Page 53 Here you view the 3D image that is the result of using the laser triangulation (linescan3D) mode. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 54: Image Handling Controls

    • Press Home to restore the original viewing position. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 55: Image View Options

    The system assigns each log message a level, either SEVERE, WARNING, INFO or FINE. Figure 49: Log tab 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 56: General Information

    When the device is connected, the Image workflow step is displayed and the Parameter editor opens. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...

  • Page 57: Adjusting Focus

    Restart the camera to apply the updated parameters. 9.2.2 Adjusting focus Workflow step: Image 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 58: Recording Images

    300.000 bytes. A stored User File can be downloaded from the device to a PC. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...

  • Page 59: Booting The Device Using A User Set

    User Set is only valid for the firmware version that was used when creating the User Set. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 60: Editing Parameters

    Figure 52: Too short exposure time: Laser line hardly visible. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...
  • Page 61 "Extraction regions", page 33), follow the steps below. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...
  • Page 62 Set ComponentSelector to Range. Select or deselect the Component Enable checkbox. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...
  • Page 63 View list. see "View modes", page 68 for details. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...
  • Page 64 Edit the relevant scatter parameters, which all have the prefix "Scatter". For more information about each parameter, see "Scatter", page O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...
  • Page 65 Set the TriggerMode parameter to Off to acquire profiles with a regular time interval. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 66: Visualizing 2D Data

    2D image data. The Settings section is located to the right of the image viewer in the GUI. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...

  • Page 67: Collecting 3D Data

    The Evaluation view window opens and shows a 3D view of the image. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 68: Visualizing 3D Data

    Suitable to show the surface details of an object, such as a print. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...
  • Page 69 If your object is small, or if you want to 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...
  • Page 70 To view the data as a point cloud, select Points and use the slider to set the size of the points. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...
  • Page 71 Use the Shininess slider to adjust the shining effect. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 72: Loading And Saving Image Buffers

    ✓ The Evaluation view window opens and the image data is displayed. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 73: Handling Log Messages

    Click the Send to camera button corresponding to UserCalibration and select the file to process. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 74: Updating Firmware

    ✓ The Firmware updater window opens and the firmware update starts automatically. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...
  • Page 75 Reconnect to the device, see "Connecting and getting a 2D image", page 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 76: Maintenance

    Please note the accompanying production documenta‐ tion. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 77: Troubleshooting

    SICK AG. Interruptions or modifications to the device by the customer will invalid‐ ate any warranty claims against SICK AG. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 78: Returns

    Description of the application ■ Description of the fault that occurred ■ O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 79: Decommissioning

    Separate the recyclable materials by type and place them in recycling containers. ■ 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 80: Technical Data

    Shutter type Global Spectral range 400 nm ... 950 nm O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 81: Signal Dynamic Range

    The maximum line rate as a function of the number of used sensor rows for the Ranger3 variants is shown in figure 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 82: Interfaces

    Ambient storage tempera‐ –20 °C ... +70 °C ture Non-condensing O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 83: Mechanics And Electronics

    To be ordered separately as accessory (see "Accessories", page 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 84: Dimensional Drawings

    TECHNICAL DATA 13.7 Dimensional drawings Figure 77: Ranger3 dimensions O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 85: Accessories

    Accessories and where applicable mounting information can be found online at: • www.sick.com/Ranger3 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 86: Glossary

    Standard Features Naming Convention System on Chip Window Around Maximum O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 87: Annex

    – that is, the axis through the center of the lens. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 88: Occlusion

    Adjusting the angles of the camera and the laser can reduce the effects of occlusion. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...

  • Page 89: Width Resolution And Resolution In The Motion Direction

    Reversed ordinary setup, all range values in a profile correspond to the same y-coordinate. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...
  • Page 90 ΔZ ≈ ΔX / tan(β) Reversed ordinary ΔZ ≈ ΔX / sin(α) O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 91: Sensor Coordinate System

    8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 92: Features

    SensorBoard MainBoard ZpmSoc Zpm1 Zpm2 Zpm3 Zpm4 Filter Laser O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...
  • Page 93 Returns true if the current register set is valid and con‐ Expert sistent. Updated after the DeviceRegistersStreamingEnd com‐ mand. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...
  • Page 94 After this command DeviceRegistersValid is updated to reflect the status of the device settings. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...

  • Page 95: Image Format Control

    Vertical offset from the origin to the region of interest Beginner R(W) (in pixels). 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 96: Scan 3D Control

    (if multiple ones are present). Value: Scan3dExtraction1 Scan3dExtraction2 Scan3dExtraction3 Scan3dExtraction4 Scan3dExtraction5 O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...
  • Page 97 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...
  • Page 98 Values 0-255. In Hi3D Set to ~240 for default Global‐ Max. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...
  • Page 99 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 100: Acquisition Control

    TriggerMode set to On. Values: Encoder FrameTriggerInput LineStart LineTriggerInput O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 101: Digital I/O Control

    Returns the current status of the selected input or out‐ Expert put line. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 102: Counter And Timer Control

    Timer. The maximum value depends on Acquisi‐ tionFrameRate and AquisitionLineRate. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 103: Encoder Control

    Selects the Activation mode of the Encoder Reset Expert Source signal. (RW) Value: RisingEdge 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 104: Event Control

    Values: Default UserSet1 UserSet2 UserSet3 UserSet4 UserSet5 O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...

  • Page 105: File Access Control

    For Read or Write operations, the number of success‐ fully read/written bytes is returned. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 106: Root

    Expert ceSelector Values: RotationX RotationY RotationZ TranslationX TranslationY TranslationZ O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...
  • Page 107 Value 0 (for low) or 1 (for high) at encoder channel B. Expert 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 108: Test Control

    GVSP transmitter must send data stream or the port fromwhich a GVSP receiver may receive data stream. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...
  • Page 109 Manual Enable/Disable of multipart-configuration bit Guru (25) in SCCFGx register for testing. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 110: Laser Control

    When using Jumbo frames the camera can support up to 4096 bytes of image data in each data package, which corresponds to 4200 bytes per Ethernet frame. O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...

  • Page 111: Connecting Multiple Cameras

    NIC. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 112: Connecting Encoders

    Figure 83: Wiring example Camera #1 SICK Stegmann encoder (RS-422) Camera #2 O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK Subject to change without notice...
  • Page 113 ANNEX Phase2 RS-422- Phase1 RS-422+ Phase1 RS-422- Phase2 RS-422+ 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...

  • Page 114: Eu Declaration Of Conformity / Certificates

    O P E R A T I N G I N S T R U C T I O N S | Ranger3 8020774/1D7Q/2022-03 | SICK...
  • Page 115 γ is the angle between the lens plane and the plane of focus. 8020774/1D7Q/2022-03 | SICK O P E R A T I N G I N S T R U C T I O N S | Ranger3 Subject to change without notice...
  • Page 116 Phone +36 1 371 2680 Phone +386 591 78849 E-Mail ertekesites@sick.hu E-Mail office@sick.si India South Africa Phone +91-22-6119 8900 Phone +27 (0)11 472 3733 Further locations at www.sick.com E-Mail info@sick-india.com E-Mail info@sickautomation.co.za SICK AG | Waldkirch | Germany | www.sick.com...

Table of Contents
