2.4G Rainbow Remote (RGB+CCT)
Product Features
This product adopt world-wide used 2.4GHz frequency, GFSK
control method, with features of low power consumption, long
distance transmitting, strong anti-interference and fast
comunication rate. It can control color, color temperature,
saturation and brightness of Mi-Light / MiBoxer 2.4G smart light.
Product Parameters
Model No.: S2-B / S2-W / S2-G
Working Voltage: 3V(AAA battery*2PCS)
Transmitting Power: 6dBm
Standby Power: 20uA
RF: 2.4GHz
Modulation Method: GFSK
Control Distance: 30m
Button Diagram
Turn on lights /
Dynamic mode /
Link / Unlink
Brightness /
Saturation
Touch ring:
brightness, saturation, color temperature, RGB use together.
(It turns to adjust brightness by default if remote is not operated
for 3 seconds)
Install Battery
Note: 2*AAA Battery need to buy seperately
1. Open battery cover
behind remote.
Model No.: S2-B / S2-W / S2-G
2. Install battery correctly and
close battery cover.
70mm
24mm
RGB / Color temp.
Turn off lights
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Miboxer Mi-LIght S2-B
Summary of Contents for Miboxer Mi-LIght S2-B
- Page 1 This product adopt world-wide used 2.4GHz frequency, GFSK control method, with features of low power consumption, long distance transmitting, strong anti-interference and fast comunication rate. It can control color, color temperature, saturation and brightness of Mi-Light / MiBoxer 2.4G smart light. Product Parameters 70mm 24mm Model No.: S2-B / S2-W / S2-G...
- Page 2 Function Description Adjust RGB Short press key twice in succession, and then touch to adjust RGB. Adjust saturation Press key twice in succession, and then touch adjust color saturation of lighting. (Note: only in RGB mode) Adjust color temperature Short press key once, then touch to adjust color temp.
