Pulsar Green Power HPSB 2548C Manual

Buffer, switch mode power supply unit

Advertisement

Quick Links

HPSB 2548C
v.1.0
HPSB 48V/2,5A/2x17Ah
Buffer, switch mode power supply unit.
EN**
Edition: 1 from 05.01.2016
Supersedes edition: ------------

Advertisement

loading
Need help?

Need help?

Do you have a question about the Green Power HPSB 2548C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pulsar Green Power HPSB 2548C

  • Page 1 HPSB 2548C v.1.0 HPSB 48V/2,5A/2x17Ah Buffer, switch mode power supply unit. EN** Edition: 1 from 05.01.2016 Supersedes edition: ------------...
  • Page 2: Green Power

    GREEN POWER www.pulsar.pl HPSB2548C Features:   DC 48V/2,5A uninterruptible power supply* battery output full protection against short-circuit  and reverse polarity connection fitting battery: 2x17Ah/12V   wide range of mains supply: 176÷264V LED indication   protections: high efficiency 80% ...
  • Page 3 GREEN POWER www.pulsar.pl HPSB2548C 1.2 Block diagram Fig.1 Fig.1. The block diagram of the PSU. 1.3 Description of PSU components and connectors (tab.1, tab.2, fig.2). Part no. Description [Fig. 2] The module of the switch mode PSU L-N power-supply connector 230V AC,...
  • Page 4 GREEN POWER www.pulsar.pl HPSB2548C Fig.2. The view of the PSU. 1.4 Technical parameters: - electrical parameters (tab.2) - mechanical parameters (tab.3) - operation safety (tab.4) - operation parameters (tab.5) Electrical parameters (tab. 2) PSU type A (EPS - External Power Source) 176÷264V AC...
  • Page 5 GREEN POWER www.pulsar.pl HPSB2548C - green, normal status – on, failure: off - AUX diode indicating DC 27,6V power status at the switch mode PSU output Mechanical parameters (tab. 3) Enclosure dimensions 400 x 350 x 90 x8 [mm] (WxHxD)
  • Page 6 GREEN POWER www.pulsar.pl HPSB2548C 2. Installation. 2.1 Requirements. The buffer PSU shall be mounted by a qualified installer with appropriate permissions and qualifications for 230V/AC installations and low-voltage installations (required and necessary for a given country). The device shall be mounted in confined spaces, according to the environment class II, with normal air humidity (RH=90% max.
  • Page 7: Green Led

    GREEN POWER www.pulsar.pl HPSB2548C 3. Operating status indication. 3.1 LED indication of operating status. The is equipped with two diodes on the front panel: RED LED:  on – the PSU is supplied with 230V AC  off – no 230V AC supply GREEN LED: ...
  • Page 8: General Warranty Conditions

    GENERAL WARRANTY CONDITIONS 1. Pulsar (the manufacturer) grants a - two-years warranty for the equipment, counted from the device’s production date. 2. The warranty includes free-of-charge repair or replacement with an appropriate equivalent (the selection is at the manufacturer’s discretion) if the malfunction is due to the manufacturer, includes manufacturing or material defects,...
