- Page 1 PSBS 2512B v.1.0 PSBS 13,8V/2A/7Ah Buffer, switch mode power supply unit. Edition: 2 from 16.09.2013 Supercedes the edition: 1 from 17.11.2011...
- Page 2 - PSBS 2512B + RN250 (13,8V/12V) + LB2 2x1A (AWZ585, AWZ586) + 7Ah 5. Buffer power supply unit PSBS 13,8V/12V/4x0,5A/7Ah - PSBS 2512B + RN250 (13,8V/12V) + LB4 4x0,5A (AWZ574 or AWZ576) + 7Ah 6. Buffer power supply unit PSBS 13,8V/2x5V÷7,4V/2x2A/7Ah...
- Page 3 PSBS2512B 1.2 Block diagram (fig.1) Fig.1. Block diagram of the power-supply unit. 1.3. Description of elements and connection links of the PSU. Table 1. Parts of the power supply - pcb (refer to chart 2). Part no. Description ; pins - configuration of UVP battery protection function ...
- Page 4 PSBS2512B Fig.2. View of the power supply pcb. Table 2. Parts of the power supply (refer to chart 3). Part no. Description Isolation transformer Power upply unit board (tab. 1, fig. 2) TAMPER; microswitches (contacts) for sabotage protection (NC)
- Page 5 PSBS2512B 1.4 Specifications: - electrical parameters (tab.3) - mechanical parameters (tab.4) - operation safety (tab.5) - operating parameters (tab.6) Electrical parameters (tab. 3) Mains supply 230V/AC (-15%/+10%) Current up to 0,3 A Power frequency 50Hz Supply power 34 W...
- Page 6 PSBS2512B Operating parameters (tab.6). Operating temperature -10ºC...+40ºC Storage temperature -20ºC...+60ºC Relative humidity 20%...90%, without condensation Vibrations during operation unacceptable Impulse waves during operation unacceptable Direct insolation unacceptable Vibrations and impulse waves during transport According to PN-83/T-42106 2. Installation. 2.1 Requirements.
- Page 7 PSBS2512B 3. Indications. 3.1 LED indication. The PSU is equipped with two diodes on the front panel: RED LED: on – the PSU is supplied with 230V AC off – no 230V AC supply GREEN LED: on – DC voltage in the AUX output of the PSU ...
- Page 8 GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a five-years warranty for the equipment, counted from the device’s production date. 2. The warranty includes free-of-charge repair or replacement with an appropriate equivalent (the selection is at the manufacturer’s discretion) if the malfunction is due to the manufacturer, includes manufacturing or material defects,...
