Summary of Contents for Pulsar Green Power HPSB 2524B
- Page 1 HPSB 2524B v.1.0 HPSB 27,6V/2,2A/2x7Ah Buffer, switch mode power supply unit. Edition: 1 from 30.09.2014 Supersedes the edition: -------------------...
- Page 2 GREEN POWER www.pulsar.pl HPSB2524B Features: LED indication DC 27,6V/2,2A uninterruptible power supply protections: fitting battery: 2x7Ah/12V SCP short-circuit protection wide range of mains supply: 176÷264V OVP overvoltage protection high efficiency 80% ...
- Page 3 GREEN POWER www.pulsar.pl HPSB2524B 1.2 Block diagram Fig.1 Fig.1. The block diagram of the PSU. 1.3 Description of PSU components and connectors ( tab.1, tab.2, fig.2). Element no. Description [Fig. 2] PSU module connectors (see: tab.2) green LED indicates AC power...
- Page 4 GREEN POWER www.pulsar.pl HPSB2524B Fig.2. The view of the PSU. 1.4 Specifications - electrical parameters (tab.3) - mechanical parameters (tab.4) - operation safety (tab.5) - operating parameters (tab.6) Electrical parameters (tab. 3) PSU type A (EPS - External Power Source) 176÷264V AC...
- Page 5 GREEN POWER www.pulsar.pl HPSB2524B LED indication: - red, normal status – on, failure: off - AC diode indicating AC power status - green, normal status – on, failure: off - AUX diode indicating DC power status at the PSU output Mechanical parameters (tab.
- Page 6 GREEN POWER www.pulsar.pl HPSB2524B 2. Installation. 2.1 Requirements. The buffer PSU shall be mounted by a qualified installer with appropriate permissions and qualifications for 230V/AC installations and low-voltage installations (required and necessary for a given country). The device shall be mounted in confined spaces, according to the environment class II, with normal air humidity (RH=90% max.
- Page 7 GREEN POWER www.pulsar.pl HPSB2524B 3. Operating status indication. 3.1 LED indication of operating status. The PSU is equipped with two diodes on the front panel: RED LED: on – the PSU is supplied with 230V AC off – no 230V AC supply GREEN LED: ...
- Page 8 GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a two-years warranty for the equipment, counted from the device’s production date. 2. The warranty includes free-of-charge repair or replacement with an appropriate equivalent (the selection is at the manufacturer’s discretion) if the malfunction is due to the manufacturer, includes manufacturing or material defects,...
