Grange CONTARB Quick Start Manual

CONTARB (A5 4page instructions) 12/2/16
Assembly
(cont.)
w
STEP 3
FITTING THE
ARBOUR SEAT
Add the Seat Sections. Your
Seat [D] should be A
positioned approximately
45cm from the bottom.
Mark this position and join
the seat to the posts of the
two Side Sections [A] with
sixteen screws [x], four into
each post, front and back
through the wooden beams
underneath the seat.
Raise your Arbour into an
Upright position.
Finally fit the Seat Back [E]
by positioning it on the rear
slat of the seat section [D]
and using four screws [x],
two per side, top and
bottom to fit it to the Side
Section posts.
Your Arbour is now ready
for use.
CONTEMPORARY
ARBOUR
A
SIDE PANELS
B
ROOF BEAMS
C
ROOF SLATS
D
ARBOUR SEAT
E
SEAT BACK

AFTERCARE

To ensure longevity of your structure it is recommended that it is treated with a wood preservative on a yearly basis.
