  • Page 1 OWNER'S MANUAL 189143 RCD-2 Index A...

  • Page 3: Table Of Contents

    5 ....................... Introduction 9 ..................Technical specifications 13 ..............Design categories and displacement 17 ..................Stability and buoyancy 21 ....................Manoeuvrability 25 .................... Rigging and sails 45 ......................Safety 59 ........Information relating to fire risks and risks of explosion CONTENTS 65 .....................Electrical system 73 ....................Water systems 81 ......................Engine 11 11 87 ....................

  • Page 5: Introduction

    A BENETEAU is made to last, in order to bring you all the pleasure you expect from a vessel over a period of many years. Each boat is subject to the utmost attention to detail from the design stage right through to launching.
  • Page 6 This manual has been produced to help you enjoy using your boat in all safety. It contains the details of the boat and of all the equipment provided and installed on your boat, as well as the instructions for their use. Read it carefully and really get to know your boat before using it. This owner's manual is not in any way a navigation or mariner's training manual.
  • Page 7 Notes on reading this manual The various symbols used throughout the manual for crucial safety information are as follows: DANGER Indicates the existence of a serious inherent danger with a high risk of death or serious injury if the appropriate precautions are not taken. WARNING Indicates the existence of a danger which could lead to injury or death if the appropriate precautions are not taken.

  • Page 9: Technical Specifications

    TECHNICAL SPECIFICATIONS Construction ..................10 General dimensions ................. 10 Engine....................10 Electricity ..................10 Capacities..................11 Sails ....................11...
  • Page 10 CONSTRUCTION Model................................................FIRST TWENTY Architect .................................................. Finot - Conq Builder ..................................................SPBI S.A Principal means of propulsion ............................................... Sail Hull construction material ..................................Single skin laminated fibreglass / Polyester Deck construction material ................................ Laminated sandwich glass / Polyester / Balsa wood Application - Deck ................................................injection Application - Hull ..............................................
  • Page 11 CAPACITIES Total mass of the liquid content of fixed tanks when they are full ..................................35 kg Fresh water capacity: ................................................35 L It may not be possible to use these capacities fully depending on the trim and load of the boat. It is recommended to keep a reserve of 20% in the fuel tanks. SAILS I: Distance between deck and highest genoa halyard sheave ...........................

  • Page 13: Design Categories And Displacement

    DESIGN CATEGORIES AND DISPLACEMENT Design categories................16...
  • Page 14 - Some of the data is shown on the manufacturer's plate fixed to the boat. The explanation of the data is given in the appropriate chapters of this manual. - The recommended maximum load includes the weight of all the people onboard, of provisions, personal belongings, of all equipment not included in the weight of the boat in ballast, of the cargo (if relevant) and of all liquids contained in fixed tanks when full (fuel, water, grey water, black water).
  • Page 15 If some of those onboard are children, the total number of people allowed onboard may be increased, provided that: - The total weight of the children does not exceed 37,5 kg; - Do not exceed the recommended maximum number of people onboard. However many and that people are onboard, the total, combined load of people and any gear or equipment must never...
  • Page 16 DESIGN CATEGORIES Category A: A yacht of design category A is considered to be designed for wind that may exceed force 8 (on the Beaufort scale) and waves that can exceed a significant height of 4 metres, but excluding exceptional conditions such as storms, severe storms, tornadoes and extreme sea conditions or huge waves. Category B: A yacht of design category B is considered to be designed for wind that may go up to force 8 inclusive and waves that can reach a significant height up to 4 metres inclusive.

  • Page 17: Stability And Buoyancy

    STABILITY AND BUOYANCY Stability data ..................18 Access to the boat................19...
  • Page 18 STABILITY DATA - Fully laden displacement was used to evaluate the stability and buoyancy of the boat. The value of this displacement - Always adjust the speed and heading of can be found in paragraph "Technical specifications" at the beginning of this manual. your boat according to the sea conditions.
  • Page 19 ACCESS TO THE BOAT - When at sea close the guardrail side- Access to companionway opening or openings. - Slamming an access hatch may cause injury : always close the hatch gently and carefully. - Do not allow children to open or close the hatches unsupervised.

  • Page 21: Manoeuvrability

    MANOEUVRABILITY Visibility from the steering station..........23...
  • Page 22 - This boat is liable to capsize or to become flooded if carrying too much sail. In these circumstances it could sink. It is important to reduce the sail area if the wind exceeds force 3 on the scale of Beaufort. It is important to be especially vigilant - If carrying too much sail, the boat could in strong gusts of wind or in a squall.
  • Page 23 VISIBILITY FROM THE STEERING STATION The vision of the helmsman from the steering station can be obstructed when under sail caused by one or several variable - Manoeuvrability is reduced at excessive conditions: speeds. 1) Load and load distribution; - There is a risk of loss of control during tight turns.
  • Page 25 RIGGING AND SAILS Rigging diagram ................26 Standing rigging ................27 Running rigging................36 Sails ....................37 Setting the sails ................38 Deck fitting ..................42 Winches..................... 42 Genoa furler ..................43 Dolphin nose..................44...

  • Page 26: Rigging And Sails

    RIGGING DIAGRAM Reference Designation Genoa furling gear stopper Main halyard Reef 1 Reef 2 Spinnaker halyard Asymmetric spinnaker tack Rigging and sails 189143 RCD-2 Index A...

  • Page 27: Standing Rigging

    STANDING RIGGING - The initial commissioning of your boat will require a lot of skill and care. The proper working of all your boat's equipment is the result of the quality of the commissioning operations. For this reason the stepping of the mast must be carried out under the responsibility of your dealer the first time the mast is stepped.
  • Page 28 MAST - FIXED Mast adjustment The recommended values should be respected (at minimum), since with these tensions the rigging is tight and the minimum cable flexibility (extension) when sailing to prevent mast movement. The load on the wires can only be measured by using a tensiometer. Necessary material: - Tensiometer gauge from Loos &...
  • Page 29 IVOTING MAST 1. Preparation - Mast Prepare the mast and fittings in the mast kit (ref. 148248). - Mast diamond protection; - Re-shaped mast foot; - Mast ring. 2. Preparation - Deck Replace the standard tabernacle with stainless steel tabernacle (ref.
  • Page 30 3. Installation - Mount Place the support on the transom beam. 4. Fitting - Mast Slide the mast towards the stern of the boat until the rotation pin can be engaged. Always check that the mast is correctly held in the stainless steel tabernacle. Rigging and sails 189143 RCD-2 Index A...
  • Page 31 5. Fitting - Shrouds - Longitudinal Place the spinnaker boom perpendicular to the mast. It is held: - on one side by the spinnaker halyard (Make up the halyard on the cleat); - on the other side by the spinnaker boom downhaul which will go to the forestay chainplate then to the cockpit winch.
  • Page 32 6. Fitting - Shrouds - Side Place the centre ring into the spinnaker boom jaw. Place the hooks in the holes made in the mast. Attach the intermediate rungs with the aid of the jib sheets. Position the intermediate rings with the aid of the jib sheets and adjusting the cars so that the rings and the mast pivot pin are on the same axis.
  • Page 33 7. Fitting - Standing rigging Attach the shrounds to the chainplates after opening the bottlescrews. Prepare the forestay furler so that it can be put into place quickly. 189143 RCD-2 Index A...
  • Page 34 8. Stepping the mast Raise the mast by pulling on the downhaul. Rigging and sails 189143 RCD-2 Index A...
  • Page 35 9. Retention & Mast adjustment Fix the forestay furler to the chainplate then secure the mast with the locking pin included in the mast kit. Dismantle the fittings used for stepping the mast. Adjust the tension of the standing rigging following the recommended tension settings.

  • Page 36: Running Rigging

    RUNNING RIGGING - Inspect the halyards for wear and condition. - Regularly check the condition of the jam cleat jaws. - Regularly clean the backstay blocks with fresh water. - Avoid aggressive gybing in order to reduce premature wear on the sheets, attachment points and the gooseneck. - If halyard tension (mainsail/genoa) is too great, this can lead to problems when hoisting/furling.

  • Page 37: Sails

    SAILS General points When the sailing season is over and, if possible, before winter, take the suit of sails to a - The working life of a sail mainly depends on its being regularly maintained. professional for an overhaul and effective - When sailing, trim the sails properly in accordance with the stresses in order to reduce the harmful strains on the fabric.

  • Page 38: Setting The Sails

    SETTING THE SAILS Mainsheet tackle Stowage - Mainsail For easier stowing of the mainsail under the boom cover it is recommended to remove the headboard batten. This operation is enabled by the double Velcro system on the batten pocket. Rigging and sails 189143 RCD-2 Index A...
  • Page 39 Genoa halyard The halyard comprises 2 parts; one On the ground, pass the halyard through Once the sail is hoisted, disconnect the Once the sail is hoisted, disconnect the uncovered (which remains in position) and the upper sheave of the swivel. covered halyard and connect the covered halyard and connect the one part covered (pulled when the sail is...
  • Page 40 Putting the jib onto the forestay The jib luff must be passed around the forestay and closed with the zip (Tie the sail safety cord). The jib halyard is designed to pass inside the luff. The halyard comprises 2 parts: - An uncovered part that remains on the jib and a covered part that will be removed once the jib is in place.
  • Page 41 Make sure that the spinnaker halyard does not become wrapped round the forestay whilst doing to remove the covered part of the halyard and stow it (it will be this. To haul down, reverse the operations useful when lowering the jib). described above.

  • Page 42: Deck Fitting

    DECK FITTING General points - Inspect each piece of deck gear regularly (blocks, shackles, swivels, jam cleats, etc): Check that there are no cracks, corrosion or deformation. - When replacing a piece of deck gear, make sure that you use a type with the same strength specifications. - If careful, regular inspections are not carried out and damaged parts and/or worn ropes are not replaced, a block or tackle may suddenly break and cause an accident or serious injury and damage the boat.

  • Page 43: Genoa Furler

    GENOA FURLER Operation Refer to the manufacturer's instructions for use and maintenance. - Leave several turns of the furling line around the drum. - Furl/unfurl the genoa slowly so that the furling line is always under light tension thus avoiding any riding turns in the drum.

  • Page 44: Dolphin Nose

    DOLPHIN NOSE Positioning the dolphin nose Pass the other end of the bobstay through the fairlead in Attach the end of the bobstay with a lark's head. Pass the eye inside the ring. the dolphin nose. Wind the eye around the ring to form a lark's head Finished! ! Rigging and sails 189143 RCD-2...
  • Page 45 SAFETY Preventing man overboard situations and the means of getting someone back onboard ..............46 Storing the life-raft ................49 Securing moveable items ..............50 Deck Layout ..................51 Information about the risks of flooding and about the boat's stability 52 Instructions in the event of steering gear failure ......

  • Page 46: Safety

    PREVENTING MAN OVERBOARD SITUATIONS AND THE MEANS OF GETTING SOMEONE BACK ONBOARD 6.1.1 Prevention of man overboard - The off-limits areas of the working deck when the boat is under way are cross-hatched below - The "working deck" means those areas outside where people stand or walk during normal use of the boat. Ref 1 &...
  • Page 47 6.1.2 Getting back onboard The means for getting back onboard must be able to be deployed by one person alone in the water, with no other help. - Some types of equipment for getting back onboard have a locking device when folded up: Installation of means to get back on board when Installation of means to get back on board in the event It is important to keep the means for getting back...
  • Page 48 Assembling the ladder L2200 mm: - To make the link between the swivel plates, use 2 stainless steel lyre shackles of 6 mm with special wrench for fitting. - Adjust the length of the cord to reach the water level and check that the ladder is properly released. It is important to ensure that the ladder extends smoothly into the water.

  • Page 49: Storing The Life-Raft

    STORING THE LIFE-RAFT Location: Under the companionway The life-raft(not supplied) must be stored in the space provided for it (Ref 1). A pictogram helps to locate it easily. Before putting to sea, carefully read the launching instructions shown on the liferaft. When at sea, never padlock or lock the stowage locker for the life-raft.

  • Page 50: Securing Moveable Items

    SECURING MOVEABLE ITEMS The technical areas are identified in the boat by the pictogram below: Technical areas may not be used as storage compartments. - Ensure that movable items are firmly secured when the boat is under way. - Don't store anything below the floorboards. The electrical technical areas are identified in the boat by the pictogram below: Safety 189143 RCD-2...

  • Page 51: Deck Layout

    DECK LAYOUT Outboard engine (the outboard engine is not supplied). Maximum engine weight: 30 kg. The outboard engine must have a built-in fuel tank. No space is designed for the stowage of a separate fuel tank. 189143 RCD-2 Index A...

  • Page 52: Information About The Risks Of Flooding And About The Boat's Stability

    INFORMATION ABOUT THE RISKS OF FLOODING AND ABOUT THE BOAT'S STABILITY 6.5.1 Openings in hull The valves, through-hull and other brass accossories last for about 5 years. Have all valves, hull orifices and other brass accessories of the vessel professionally checked every 5 years and replace them as necessary.
  • Page 53 6.5.2 Drainage system General points - The inner moulding of the hull has channelling: the drainage channels. The drainage channels allow the water to drain down to the lowest point in the boat, where it can be discharged. So it is important to allow the water to flow freely down to this lowest point of the boat, which includes. - Regularly cleaning the lowest point of the boat and the drainage channels.
  • Page 54 Manual bilge pump (Outside) The compartment housing the manual bilge The manual bilge pump is in the cockpit (Ref 1). pump must not be locked. The bilge pump lever is located close to it (Ref 2). Operation: I- Put the lever on the manual bilge pump. II- Repeatedly work the lever up and down to its fullest extent.
  • Page 55 Bilge pump maintenance Please refer to the manufacturer's notes on the instructions for checking and maintaining the bilge pumps. - The drainage system is not designed to control water coming from breaches in the hull. - Keep the water level in the bilges to the minimum.
  • Page 56 DIAGRAM OF THE LAYOUT - DRYING OUT THE BILGE Reference Designation Manual bilge pump (interior) Manual bilge pump (Outside) Intake - Bilge pump Intake - Bilge pumpt Draining of manual bilge pump (interior) Draining of manual bilge pump (Outside) Safety 189143 RCD-2 Index A...

  • Page 57: Instructions In The Event Of Steering Gear Failure

    INSTRUCTIONS IN THE EVENT OF STEERING GEAR FAILURE 1. Drop anchor to avoid drifting. 2. Find out if you can solve the problem yourself by looking at the engine manual. 3. Request help. 189143 RCD-2 Index A...
  • Page 59 INFORMATION RELATING TO FIRE RISKS AND RISKS OF EXPLOSION Propulsion engines and other fuel-burning equipment....60 Electrical system ................60 Fire-prevention and fire-fighting equipment........61 Emergency exits in case of fire............63...

  • Page 60: Information Relating To Fire Risks And Risks Of Explosion

    PROPULSION ENGINES AND OTHER FUEL-BURNING EQUIPMENT The risks associated with motorisation are described in the ENGINE chapter. - Boats equipped with a 25kW or larger outboard engine must have onboard one or more portable fire extinguishers with a total combined capacity of at least 8A / 68B. The risks associated with other fuel-burning equipment are described in the EQUIPMENT OTHER THAN FOR PROPULSION, WHITH BURNS FUEL chapter.

  • Page 61: Fire-Prevention And Fire-Fighting Equipment

    FIRE-PREVENTION AND FIRE-FIGHTING EQUIPMENT 7.3.1 Fire-fighting equipment Portable fire-extinguishers and fire blanket (not supplied) - When in use, this boat must be equipped with portable fire extinguishers of the following extinguishing capacity and located in the following places: Minimum extinguishing Reference Designation Location...
  • Page 62 Maintenance of the fire-fighting equipment The owner/person operating the boat must: - Get the fire-fighting equipment checked at the frequency shown on the equipment; - Replace portable fire extinguishers, if outdated or discharged, by extinguishing apparatus of equal capacity; - Provide at least one fire bucket with a lanyard, in a readily accessible place, for protection on deck; - Get the fixed fire extinguishing systems filled or replaced if they are discharged or have expired.

  • Page 63: Emergency Exits In Case Of Fire

    EMERGENCY EXITS IN CASE OF FIRE NEVER: - Obstruct the passages leading to the emergency exits and the hatches; - Obstruct or block safety controls, for instance fuel shut off valves, gas taps, electrical system circuit-breakers; - Obstruct the access to the portable extinguishers stored in lockers;...
  • Page 65 ELECTRICAL SYSTEM General information about the electrical system ......66 DC installation (12 V)................ 67 Protection against electrolysis / Earth plate........71...
  • Page 66 GENERAL INFORMATION ABOUT THE ELECTRICAL SYSTEM - The risks of fire or explosion may result from careless use of the DC and AC systems. - The risks of electrocution may result from careless use of the AC system. NEVER: - work on a live electrical system; - modify the elecrical system of the vessel or the relevant diagrams: It is important that the installation, maintenance and any modifications...
  • Page 67 DC INSTALLATION (12 V) 8.2.1 Battery use and distribution General points The boat is equipped with a direct current electrical system. The service batteries serve as the power supply for all the boat's electrical components. the batteries are charged either by a load distributor or: - by the alternator linked to the engine when the engine is running, - by the battery charger (if the boat has one).
  • Page 68 Maintenance - Avoid charging batteries to a voltage greater than 14,6 V. - All work carried out on a battery must only be carried out by someone qualified to do so. - Keep the batteries clean and dry. Whenever working on a battery, wear safety - Regularly check that the terminals and connection cables are clean.
  • Page 69 LAYOUT DIAGRAM - BATTERY CABLES Reference Designation Navigation light Mooring light Electronic Interior lighting Available Available 189143 RCD-2 Index A...
  • Page 70 8.2.3 Electrical panel Location: Saloon 1. Navigation light 2. Mooring light 3. Electronic 4. Interior lighting 8.2.4 Fuse When replacing fuses/circuit-breakers, always - A fuse protects an electrical circuit from a power surge. If it blows, you must replace it with another fuse of the same rating.
  • Page 71 PROTECTION AGAINST ELECTROLYSIS / EARTH PLATE - Never cover the anodes in antifoul. 8.3.1 Anodes - During the first few weeks that the boat is in General points the water, check the anodes and if necessary replace them: they erode very rapidly during this - The sacrificial anodes protect the boat's metal components from electrolysis.

  • Page 73: Water Systems

    WATER SYSTEMS General points .................. 74 Using a valve..................75 Fresh water filling system ............... 76 Black water system (WC)..............77 Waste water system ................. 79...

  • Page 74: General Points

    GENERAL POINTS - It is essential to rinse the entire on-board water system the first time the boat is used (The water system is protected in - Regularly check water-tightness of joints in the factory by a dietary anti-freeze). the water system installations. Check that screws and bolts are well tightened and replace - The water tanks may have had an anti-algae treatment using a copper sulphate based product.

  • Page 75: Using A Valve

    USING A VALVE The valve is shut when the valve handle is at right angles to the pipe, the valve is open when the valve handle is in line Valves have a lifespan of approximately 5 with the pipe. years. It is essential to have all valves on board checked by a professional every 5 years and possibly replace them.

  • Page 76: Fresh Water Filling System

    FRESH WATER FILLING SYSTEM Reference Designation Water tank - 35 litre Hand pump "WATER" deck filler Vent hole Galley sink Water tank Water systems 189143 RCD-2 Index A...

  • Page 77: Black Water System (Wc)

    BLACK WATER SYSTEM (WC) General points - Black water is human waste including the flushing water from the toilets. - Close the valves after each use and above all when the boat is unattended. - Regularly check the valves and thru-hull seacocks for proper operation and watertightness. - Regularly check the tightness of the flexible pipe clamps and connections.
  • Page 78 Chemical toilet - Refer to the manufacturer's instructions for Location: Forward cabin use and maintenance. - Do not use detergents (chlorine,solvent). - Respect local regulations regarding the emptying of black water tanks. Reference Designation Fresh water tank (Upper) Pump Fresh water tank cap Black water tank (Lower) Gauge Evacuation pipe...

  • Page 79: Waste Water System

    WASTE WATER SYSTEM General points - Observe local regulations regarding the emptying of grey water tanks. - Close the valves after each use and above all when the boat is unattended. - Regularly check the valves and thru-hull seacocks for proper operation and watertightness. - Regularly check the tightness of the flexible pipe clamps and connections.

  • Page 81: Engine

    ENGINE Information about the risks of fire and of explosion of engines..82 Danger from moving mechanical parts..........83 General points .................. 83 Starting the engine ................84 Engine installation................85 Access to the engine................ 85...

  • Page 82: Information About The Risks Of Fire And Of Explosion Of Engines

    10.1 INFORMATION ABOUT THE RISKS OF FIRE AND OF EXPLOSION OF ENGINES - Make sure that the coolant is circulating properly. The outboard engine must have a built-in fuel tank. No space is designed for the stowage of a - Ensure that ventilation openings in the compartment fuel tank are not obstructed. separate fuel tank.

  • Page 83: Danger From Moving Mechanical Parts

    10.2 DANGER FROM MOVING MECHANICAL PARTS - Keep away from the moving parts of the engine (belts and moving parts or hot components) and the drive shafts etc.. - Regularly check that the O ring on the filler cap is in good condition, to prevent any water - Be careful if you have long hair, bulky clothing, rings etc (at risk of being caught).

  • Page 84: Starting The Engine

    10.4 STARTING THE ENGINE Before starting the engine, it is imperative: - Before using the engine, make sure you carefully read the handbook provided by the - to put the control lever in neutral; engine manufacturer. - to attach the circuit-breaker to the pilot. Make a habit of looking to see if sea water is pumped out with the exhaust gases as soon as you start the engine.

  • Page 85: Engine Installation

    10.5 ENGINE INSTALLATION 10.6 ACCESS TO THE ENGINE The access to the engine is via: - The cockpit. All access hatches to the engine absolutely must be kept shut when at sea. 189143 RCD-2 Index A...

  • Page 87: Steering System

    11 11 STEERING SYSTEM General points .................. 88 Centreboard ..................88 Layout diagram................. 90...
  • Page 88 11.1 GENERAL POINTS - The steering system is an important safety feature. For this reason, the annual inspection of the whole system must be carried out by a professional engineer. 11.2 CENTREBOARD Operation: To raise the centreboard operate the mechanism in a clockwise direction. To lower the centreboard operate the mechanism in an anti-clockwise direction.
  • Page 89 Layout of components Centreboard Mechanism 11 11 189143 RCD-2 Index A...
  • Page 90 11.3 LAYOUT DIAGRAM Reference Designation Tiller + For extension Tiller head Connecting rod Rudder Rudder sleeve Steering system 189143 RCD-2 Index A...

  • Page 91: Deck Fittings

    DECK FITTINGS General points .................. 92 Berthing, anchoring, towing............95 Main elements of the chain locker ..........96...
  • Page 92 12.1 GENERAL POINTS 12.1.1 Polyester - Regularly brush the deck using a gentle de-greasing agent then rinse the deck with fresh water. - Use as few cleaning agents as possible. - Don't use solvents or aggressive detergent agents. - Don't discharge cleaning agents into the water: Consult the harbourmaster's office to find out the conditions of water use and the maintenance area for cleaning your vessel.
  • Page 93 12.1.4 Solid wood on exterior wooden panelling - Wood exposed to harsh conditions, such as salty air and UV rays tends to become whiter and to lose its natural colour. Never use detergents, acetone or other harsh This phenomenon has no effect on the intrinsic qualities of the wood, but can spoil its aesthetic appeal. products on the wood.
  • Page 94 12.1.6 Synthetic wood composite decking (imitation teak) The product is UV resistant with no need for sanding or special cleaning products. Do not pour acetone on the decking. Normal cleaning: - Rinse in fresh water, using a sponge or a soft brush. - Clean with soap or a household product if necessary, then rinse in fresh water.
  • Page 95 12.2 BERTHING, ANCHORING, TOWING The anchoring points or those showing visible 12.2.1 Anchor points signs of deterioration must be replaced. Responsibility It is the responsibility of the owner/user of the boat to ensure that the berthing lines, towing cables, chains and mooring lines and the anchors are adequate for the intended use of the boat, i.e.
  • Page 96 12.2.2 Towing Responsibility: It is important that the owner thinks through the actions required when securing a towing cable onboard. - Generally the breaking strength of lines/ chains must not exceed 80% of the breaking Location of attachment points strength of the anchor points. - Always tow or be towed at low speed.

  • Page 97: Hull Fittings

    HULL FITTINGS Upholstery..................98 Interior woodwork ................100 Interior maintenance ..............100 Saloon table ..................100...
  • Page 98 13.1 UPHOLSTERY ALCANTARA (microfibre) Stain removal The fabric must be free from dust before removing. To do so, use a vacuum cleaner to achieve optimal cleanness. Rub with a duster soaked in a solution containing ammonia diluted by 10%. Dilute to the strength appropriate for this fabric. Try it out first on a hidden corner, the hem for instance, if the appearance of the fabric changes, dilute accordingly.
  • Page 99 COATED FABRIC (PVC) Maintenance - The PVC must be regularly cleaned with soapy water to maintain its appearance and avoid accumulation of debris. Try to avoid using the following products: lacqeurs, aggressive cleaning products, detergents, xylene or acetone-based products which can cause permanent damage or make the fabric deteriorate. The use of such products is at the owner's risk.
  • Page 100 13.2 INTERIOR WOODWORK - Clean the interior varnish using a de-greasing shampoo on a damp cloth. If the stains persist or if in doubt, consult a cleaning specialist. - Polish the interior varnishing with a chamois leather. When winterising the boat, make sure the - If there are any stains or light scratches, it is possible to polish the varnish.

  • Page 101: Handling, Transport

    HANDLING, TRANSPORT Lifting plan ..................102 Lifting....................103 Keel ....................104 Upper limit of antifoul ..............104 Launch/Lift out................105 Stepping/unstepping the mast ............105 Winter Storage ................107 Transport..................108...

  • Page 102: Lifting Plan

    14.1 LIFTING PLAN Location - lifting slings Note: Measurements are expressed in mm. The position of the lifting slings is shown in the pictogram below: Arrangement for beaching leg fittings Handling, transport 189143 RCD-2 Index A...

  • Page 103: Lifting

    14.2 LIFTING The wet surface area of the boat is about: 11 m². - Follow the manufacturer's recommendations - Before the first application of antifouling to the hull, you can lightly the hull using 400 µm or more wet and dry sandpaper. scrupulously when applying antifouling.

  • Page 104: Keel

    14.3 KEEL General points The ballast is the appendix located under a sailing yacht. It is an essential component of stability, essential for the operation of the boat. The ballast is fixed to the bottom of the hull by bolts or pins and nuts with the corresponding tightening torque. Maintenance The ballast is a part of the hull under the waterline.

  • Page 105: Launch/Lift Out

    14.5 LAUNCH/LIFT OUT The initial commissioning of your boat will require a lot of skill and care. The proper working of all your boat's equipment Do not remain onboard or beneath the boat is the result of the quality of the commissioning operations. This is why the initial launch must be overseen by your dealer. during the handling operations.
  • Page 106 Prepare the mast ashore by fitting the various wires. Leave enough play in the diamond cap to allow the wire to slide. Fit the upper swivel of the furling gear to the mast with its halyard (the halyard is outside and parallel to the forestay). Adjustment method: - Step the mast and tighten the wires by hand using the bottlescrews setting them up equally as you do so.

  • Page 107: Winter Storage

    14.7 WINTER STORAGE - Take advantage of laying up the boat to carry out a full inventory of the equipment. - The winterisation of the engine requires the skills of a professional engineer: please consult - Check the expiry dates of the safety equipment. your dealer.

  • Page 108: Transport

    14.8 TRANSPORT Load (dry): 1 185 kg. - If the boat can be transported by trailer be careful to use a trailer that is appropriate for the Light displacement: 1 300 kg. boat and its weight. Items of equipment included in the weight of the boat during transportation or when towed: - the weight of liquids is calculated on the basis of full tanks.

  • Page 109: Environment

    ENVIRONMENT Waste management................ 110...
  • Page 110 Waste management: - Throw all packaging in the recycling containers provided for this. - Make sure you know the local enviromental regulations and follow the codes of best - Once a piece of equipment has completely stopped working, find out about the relevant recycling regulations from your practice.

  • Page 111: Appendixes

    APPENDIXE Meaning of the labels ..............112...
  • Page 112 MEANING OF THE LABELS General electrical Engine group Plumbing group Colour - WC group Comfort group Drainage group equipment Valve location label Closed valve Open valve Meaning of the symbols Motor Shower Electric pump Port engine Washbasin Manual pump Starboard engine Icemaker Toilet Propeller shaft...
  • Page 113 Shore power socket Fuel tank Fuel filter Service Holding tank Inverter Generator Battery stock Heating Breaker Thruster Air conditioning 157559 Label code (Element) ATTERY Each label is defined by: (Function) ENERATOR - a functional group (specific colour); example: - a component. (Colour: ENERAL ELECTRICAL EQUIPMENT Yellow)
