User manual
HDMI Network extender

Product introduction

This Network Extender is a product extends HDMI 2.0 4K@60Hz
signal for 60 meters over Cat6 cable instead of HDMI cable. The
purpose of the extender is to achieve long-distance signal
transmission with low-cost wires.

Product features

1. Support high resolutions up to 4K@60Hz
2. Long distance transmission up to 60 meters
3. HDMI V2.0,HDCP V2.2 compatible.
4. HDMI Transmitter and Receiver 2 in 1. Function can be
switched by pressing the "switch" button.
5. Low power consumption, high safety.
6. IR receiver and sender cable are built 2 in 1, easy and
convenient for installation

Package Content

1.HDMI Network extender
2.IR receiver & extender cable
3.Power supply
4.User manual
x2
x2
x1
x1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDTVHYRJ2022-A20 and is the answer not in the manual?

Questions and answers

Summary of Contents for WolfPack HDTVHYRJ2022-A20

  • Page 1 Product introduction This Network Extender is a product extends HDMI 2.0 4K@60Hz signal for 60 meters over Cat6 cable instead of HDMI cable. The purpose of the extender is to achieve long-distance signal transmission with low-cost wires. User manual Product features 1.
  • Page 2 Physical interface Product specifications Max length of CAT-6 cable ........up to 60 meters HDMI & HDCP Version......HDMI V2.0, HDCP V2.2 Switch HDMI input....4K/2K/1080p/720p/576p/576i/480p/480i Support audio formt Power Spdif Out Audio Out RJ Out RJ In .......DTS Digital Dolby Digital DTS-Hp Dolby TrueHD HDMI output.....4K/2K/1080p/720p/576p/576i/480p/480i Max bandwidth..............600MHz Max baud rate................18Gbps...
  • Page 3 Connection diagram 5. Use one cat6 cable max 60m to connect “RJ45 out”of TX and “RJ45 in” of RX. 6. If you want to connect audio receivers, use one optical cable to plug in “Spdif out” or a 3.5mm audio cable to plug in “Audio out”of TX or RX, and the other end to connect audio receiver.
  • Page 4 Possible problems and solutions The problem The solution 1. Check whether the power adapter is connected properly. No electricity 2. Check if the power switch is on. 1. Check whether the display screen is on. 2. Check if the input source is on. No image or video 3.Check all cables and make sure they are fully plugged into blurred image...
