High-Capacity Battery Installation
1
Press On/Off switch at back
of unit to power off the unit.
Unplug power adapter socket
from the back of the unit.
2
Remove both screws with
a Philips screw driver.
Slide out back cover.
3
Remove the existing battery
power pack.
Please do not dispose of battery
in municipal waste.
#9003BAT
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ADC e-sphyg 3
Summary of Contents for ADC e-sphyg 3
- Page 1 High-Capacity Battery Installation #9003BAT Press On/Off switch at back of unit to power off the unit. Unplug power adapter socket from the back of the unit. Remove both screws with a Philips screw driver. Slide out back cover. Remove the existing battery power pack.
- Page 2 Charge battery until re- charge indicator on main unit turns green. Download full manual at www.adctoday.com/esphyg3 American Diagnostic Corporation 55 Commerce Drive Hauppauge, NY 11788 USA 1-800-ADC-2670 www.adctoday.com IFU p/n: 93-9003BAT-00 rev 0 (09/23/2021)
