- Page 1 INSTRUCTION MANUAL SADS, SAPS, SAMS, SHTS, SATS, SDSS, SDRS, SALS, SDNS, SNHS, STES, SJTS, SSFS, SWSBT Tool Holders for Stands...
- Page 2 This manual corresponds to the following references*: 0015450 0016267 SADS for ADS & HDS SAPS for APS 0016268 0016269 SAMS for AMS SHTS for HTS & HDTS 0028036 0016272 SATS for ATS SDSS for DSS 0016273 0016275 SDRS for DRS...
- Page 3 w w w.jbctools.com Changing the Tool Holder max.10 mm Remove the locking knob (1). Separate the tool holder Locking Knob from the stand and remove the holder screw (2). Holder Screw Cable Carefully move tool holder sidewards until the cable* comes out (3). Place the new tool holder Tool following the disassembling...
- Page 4 Specifications SADS / SAPS / SAMS / SHTS / SATS / SDSS / SDRS / SALS / SDNS / SNHS / STES / SJTS / SSFS / SWSBT Tool Holders for Stands Ref.: see page 2 - Package Dimensions: 111 x 81 x 41 mm (L x W x H) 4.37 x 3.19 x 1.61 in...
