Patent No. US 8,856,780 CA 2759622
Automotive Data Solutions Inc. © 2022
PRODUCT GUIDE
VWX
DOCUMENT NUMBER
REVISION DATE
20220113
TERMS OF USE
Automotive Data Solutions Inc. ("ADS") products are strictly intended for installation by Certified Technicians who are
employed by a registered business specialized in the installation of automotive aftermarket electronics products. Prior
to beginning installation of an ADS product in a vehicle, it is the Certified Technician's responsibility to review the most
current Product Guide, Install Guide and vehicle-specific notes available in Weblink®. ADS is not responsible for any
damages whatsoever, including but not limited to any consequential damages, incidental damages, damages for loss
of time, loss of earnings, loss of profit, commercial loss, loss of economic opportunity and the like that may or may not
have resulted from the use, misuse, improper installation or operation of its products. ADS reserves itself the right to
suspend any Weblink® account without notice and decline to offer technical support to non-Certified Technicians, non-
compliant Certified Technicians or end users.
www.idatalink.com
Advertisement
Table of Contents
Related Manuals for ADS FlashLogic VWX
Summary of Contents for ADS FlashLogic VWX
- Page 1 Prior to beginning installation of an ADS product in a vehicle, it is the Certified Technician’s responsibility to review the most current Product Guide, Install Guide and vehicle-specific notes available in Weblink®. ADS is not responsible for any...
-
Page 2: Table Of Contents
PAGE 2 OF 15 GETTING STARTED - 1 OF 1 • 20220113 WELCOME TABLE OF CONTENTS VWX Product Guide Congratulations on the purchase of your VWX solution. You are now a few simple steps away Module Layout from enjoying your new remote starter unit with enhanced features. -
Page 3: Vwx Product Guide
PAGE 3 OF 15 MODULE LAYOUT - 1 OF 1 • 20220113 MODULE CONNECTORS CONNECTOR PINOUT 01 GREEN•BLACK DOT - LOCK (-) OUTPUT 01 GREEN•BLACK DOT - LOCK (-) OUTPUT 02 BLUE•BLACK DOT - UNLOCK (-) OUTPUT 02 BLUE•BLACK DOT - UNLOCK (-) OUTPUT MODULE 03 RED/WHITE•BLACK DOT - TRUNK RELEASE (-) OUTPUT 03 RED/WHITE•BLACK DOT - TRUNK RELEASE (-) OUTPUT... -
Page 4: Tach Programming Procedure
PAGE 4 OF 15 TACH PROGRAMMING PROCEDURE - 1 OF 1 • 20220113 START vehicle for 15 seconds. ON START START START ENGINE START STOP Press and hold the brake pedal. Press and release the module’s programming button. (OR if the remotes are already programmed to the vehicle, press and hold the start button of the remote for 2.5 seconds.) Wait, LED 2 will fl... - Page 5 PAGE 5 OF 15 MODULE DIAGNOSTICS - 1 OF 2 • 20220113 LED 2* LED 1** LED STATUS DIAGNOSTIC • Missing/wrong information from fi rmware or vehicle. Flashing RED See fi rmware specifi c diagnostics, or contact technical support. • Solid RED Module waiting for more vehicle information.
-
Page 6: Module Diagnostics
PAGE 6 OF 15 MODULE DIAGNOSTICS - 2 OF 2 • 20220113 LED 2* LED 1** LED STATUS DIAGNOSTIC • Flashing rapid RED Remote start shutdown sequence. • Flashing slow RED Remote start shutdown error code. Contact technical support. • Solid RED Remote start crank delay. -
Page 7: Remote Starter Error Codes
PAGE 7 OF 15 REMOTE STARTER ERROR CODES - 1 OF 1 • 20220113 REMOTE STARTER ERROR CODES: NOTES PARKING LIGHT FLASHES DIAGNOSTIC 3 + 1 Tach is not programmed OR engine is already running. I WARNING: The following applies only when the parking lights are connected and supported by the system. - Page 8 PAGE 8 OF 15 ALARM ERROR CODES - 1 OF 1 • 20220113 ALARM ERROR CODES: NOTES PARKING LIGHT FLASHES ANTENNA LED FLASHES DIAGNOSTIC 5 + 1 Shock sensor triggered I WARNING: The following applies only when the parking lights are connected and supported by the system.
-
Page 9: Module Reset Procedure
PAGE 9 OF 15 MODULE RESET PROCEDURE - 1 OF 1 • 20220113 >> The following procedure resets the module Module RESET completed. programming to the vehicle. It does not reset any settings confi gured online. Disconnect all connectors from module except Reconnect all connectors. -
Page 10: Installation Checklist
PAGE 10 OF 15 INSTALLATION CHECKLIST - 1 OF 2 • 20220113 CHECKLIST - WITH AFTERMARKET KEYFOB WARNING: Vehicle engine will start many times. Test in a well ventilated area. Press the START/STOP button once [1x] on the aftermarket keyfob to shut down vehicle. Question 7: Does the vehicle shut down? Close all vehicle doors, hood and trunk. - Page 11 PAGE 11 OF 15 INSTALLATION CHECKLIST - 2 OF 2 • 20220113 CHECKLIST - WITH OEM KEYFOB WARNING: Vehicle engine will start many times. Test in a well ventilated area. Close all vehicle doors, hood and trunk. Press LOCK button three times [3x] rapidly on the OEM keyfob to remote start vehicle. Question 1: Does the vehicle remote start? YES: Go to next step.
-
Page 12: Compatible Accessories
PAGE 12 OF 15 COMPATIBLE ACCESSORIES - 1 OF 2 • 20220113 WEBLINK CABLE (required accessory sold separately) WEBLINK CABLE MODULE COMPUTER WEBLINK PORT USB PORT 4 PIN BLACK CABLE WEBLINK MOBILE (accessory sold separately) OBDII CONNECTOR 4 PIN BLACK CABLE MODULE WEBLINK PORT MOBILE DEVICE... - Page 13 PAGE 13 OF 15 COMPATIBLE ACCESSORIES - 2 OF 2 • 20220113 TELEMATIC KIT SOLD SEPARATELY (NC) MODULE TELEMATIC PORT SMARTSTART TELEMATIC KIT SOLD SEPARATELY DIRECTED SMARTSTART (NC) BLACK WHITE (NC) 4 PIN 4 PIN MODULE SMARTSTART PORT RED 4 PIN (NC) (NC) (NC)
-
Page 14: Remote Programming Procedure
PAGE 14 OF 15 REMOTE PROGRAMMING PROCEDURE - 1 OF 1 • 20220113 WARNING: Complete the module Release the antenna button. The antenna’s [4x] programming procedure and tach leds will turn OFF. programming procedure before programming the remotes. A maximum of four [4x] remotes per system. -
Page 15: Valet Mode Programming Procedure
PAGE 15 OF 15 VALET MODE PROGRAMMING PROCEDURE - 1 OF 1 • 20220113 >> NOTE: In Valet Mode, the Remote starter is not Valet Mode Programming Procedure functional. Keyless entry, Lock and Unlock will completed. remain functional. See RF kit user manual for alternate valet mode programming.
