COM-GM(RS)-GM7-[FT-GM7-DC]-EN
TERMS OF USE: Automotive Data Solutions Inc. ("ADS") products are strictly intended for installation by
Certified Technicians who are employed by a registered business specialized in the installation of auto-
motive aftermarket electronics products. Prior to beginning installation of an ADS product in a vehicle,
it is the Certified Technician's responsibility to review the most current Product Guide, Install Guide
and vehicle-specific notes available in Weblink®. ADS is not responsible for any damages whatsoever,
including but not limited to any consequential damages, incidental damages, damages for loss of time,
loss of earnings, loss of profit, commercial loss, loss of economic opportunity and the like that may or
may not have resulted from the use, misuse, improper installation or operation of its products. ADS
reserves itself the right to suspend any Weblink® account without notice and decline to offer technical
support to non-Certified Technicians, non-compliant Certified Technicians or end users.
Patent No. US 8,856,780 CA 2759622
Automotive Data Solutions Inc. © 2019
INSTALL GUIDE
DOCUMENT NUMBER
68188
REVISION DATE
20191206
FIRMWARE
COM-GM(RS)-GM7-[FT-GM7-DC]
HARDWARE
FT-GM7-DC
ACCESSORIES
ADS-USB (REQUIRED)
COMPATIBLE RF-KIT (OPTIONAL)
DRONE MOBILE DR-2000 (OPTIONAL)
BEFORE INSTALLATION
1- Connect module to computer
2- Login to Weblink account
3- Flash firmware to module (module is not preloaded with firmware)
4- Use accessories accordingly (accessories are sold separately)
compustar.idatalink.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Firstech FT-GM7-DC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ADS Firstech FT-GM7-DC

  • Page 1 ADS reserves itself the right to suspend any Weblink® account without notice and decline to offer technical support to non-Certified Technicians, non-compliant Certified Technicians or end users.
  • Page 2 PAGE 2 OF 26 VEHICLE LIST - 1 OF 2 • 20191206 DOC.: #68188 FEATURES Encore Flip-Key AT 13-16 1 • • • • • • • • • • • • • • LaCrosse Flip-Key AT 10-16 1 • •...
  • Page 3 PAGE 3 OF 26 VEHICLE LIST - 2 OF 2 • 20191206 DOC.: #68188 FEATURES Canyon STD Key with OnStar AT 15-16 1 • • • • • • • • • • • • • • • Canyon STD Key without OnStar AT 15-16 4 •...
  • Page 4 BLACK TELEMATIC PORT AFTERMARKET HOOD SWITCH AND CABLE BLACK T-HARNESS 2 THE ADS-HRN(RS)-GMC07-2 CABLE IS INCLUDED IN KITS MANUFACTURED AFTER 07/01/2015. BLACK CONTACT YOUR AUTHORIZED DEALER, IF THIS CABLE IS NOT INCLUDED. WHITE WARNING STICKER WEBLINK CABLE (required accessory sold separately)
  • Page 5 PAGE 5 OF 26 COMPATIBLE ACCESSORIES - 1 OF 1 • 20191206 DOC.: #68188 RF KIT (Visit our website to see if this accessory is included with your product) RF KIT FLASH RF DECODER BEFORE INSTALLATION (NC) RED (NC) BLACK BLUE MODULE BLACK...
  • Page 6 PAGE 6 OF 26 TYPE 1 - WIRE CHART - 1 OF 2 • 20191206 DOC.: #68188 16 pin 01 Green (DATA) OBDII Encore Flip-Key AT 13-16 Parking Light White 26 pin 22 Green/Gray BCM, left side of steering column 16 pin 01 Green (DATA)
  • Page 7 PAGE 7 OF 26 TYPE 1 - WIRE CHART - 2 OF 2 • 20191206 DOC.: #68188 16 pin 01 Green (DATA) OBDII Canyon STD Key 15-16 with OnStar AT Parking Light White 26 pin 22 Green/Gray BCM, left side of steering column 16 pin 01 Green (DATA)
  • Page 8 PAGE 8 OF 26 TYPE 1 - WIRING DIAGRAM - 1 OF 1 • 20191206 DOC.: #68188 VEHICLE IGNITION SWITCH RF PORT/WEBLINK PORT TELEMATIC PORT A1: PK3 CONNECTOR A2: PK3 HARNESS B1: IGNITION CONNECTOR B2: IGNITION HARNESS OBDII CONNECTOR SWC (DATA) - 01 GREEN/WHITE - SWC (DATA) OUTPUT 01 BROWN/BLACK - PARKING LIGHT (-) OUTPUT 02 GRAY (NC)
  • Page 9 PAGE 9 OF 26 TYPE 2 - WIRE CHART - 1 OF 2 • 20191206 DOC.: #68188 Parking Light White 26 pin 22 LtGreen/Gray BCM, left side of steering column Silverado 16 pin 01 Green (DATA) OBDII connector 1500 Ignition Green 06 pin 02 Purple/Black...
  • Page 10 PAGE 10 OF 26 TYPE 2 - WIRE CHART - 2 OF 2 • 20191206 DOC.: #68188 Parking Light White 26 pin 22 LtGreen/Gray BCM, left side of steering column 16 pin 01 Green (DATA) OBDII connector Yukon Ignition Green 06 pin 02 Purple/Black Ignition connector...
  • Page 11 • 20191206 DOC.: #68188 VEHICLE IGNITION SWITCH A1: PK3 CONNECTOR RF PORT/WEBLINK PORT TELEMATIC PORT A2: PK3 HARNESS WITH ADS-THR-GM7-2 WITH ADS-THR-GM7-2 B1: IGNITION CONNECTOR B2: IGNITION HARNESS WITHOUT ADS-THR-GM7-2 WITHOUT ADS-THR-GM7-2 B1: IGNITION CONNECTOR CUT VS4 CONNECTOR FROM HARNESS...
  • Page 12 PAGE 12 OF 26 TYPE 3 - WIRE CHART - 1 OF 2 • 20191206 DOC.: #68188 Parking Light White 26 pin 22 LtGreen/Gray BCM, left side of steering column 16 pin 01 Green (DATA) OBDII connector Silverado Ignition Green 06 pin 02 Purple/Black Ignition connector...
  • Page 13 PAGE 13 OF 26 TYPE 3 - WIRE CHART - 2 OF 2 • 20191206 DOC.: #68188 Parking Light White 26 pin 22 LtGreen/Gray BCM, left side of steering column 16 pin 01 Green (DATA) OBDII connector Sierra Ignition Green 06 pin 02 Purple/Black Ignition connector...
  • Page 14 • 20191206 DOC.: #68188 VEHICLE IGNITION SWITCH A1: PK3 CONNECTOR RF PORT/WEBLINK PORT TELEMATIC PORT A2: PK3 HARNESS WITH ADS-THR-GM7-2 WITH ADS-THR-GM7-2 B1: IGNITION CONNECTOR B2: IGNITION HARNESS WITHOUT ADS-THR-GM7-2 WITHOUT ADS-THR-GM7-2 B1: IGNITION CONNECTOR CUT VS4 CONNECTOR FROM HARNESS...
  • Page 15 PAGE 15 OF 26 TYPE 4 - WIRE CHART - 1 OF 1 • 20191206 DOC.: #68188 Parking Light White 26 pin 22 Green/Gray BCM, left side of steering column Colorado STD Key 16 pin 01 Green (DATA) OBDII connector with OnStar 15-16 Lock...
  • Page 16 PAGE 16 OF 26 TYPE 4 - WIRING DIAGRAM - 1 OF 1 • 20191206 DOC.: #68188 VEHICLE IGNITION SWITCH RF PORT/WEBLINK PORT TELEMATIC PORT A1: PK3 CONNECTOR A2: PK3 HARNESS B1: IGNITION CONNECTOR B2: IGNITION HARNESS OBDII CONNECTOR SWC (DATA) - 01 GREEN/WHITE - SWC (DATA) OUTPUT X2 : BLUE 01 BROWN/BLACK - PARKING LIGHT (-) OUTPUT...
  • Page 17 PAGE 17 OF 26 MODULE PROGRAMMING PROCEDURE - 1 OF 1 • 20191206 DOC.: #68188 Insert key into ignition. Insert key into ignition. Turn key to ON position. START START START Turn key to ON position. Turn key to ON position. Wait, LED will turn solid GREEN for 2 seconds.
  • Page 18 PAGE 18 OF 26 VALET MODE PROGRAMMING PROCEDURE - 1 OF 1 • 20191206 DOC.: #68188 >> >> NOTE: In Valet Mode, the Remote starter is not To exit valet mode: repeat steps 1 to 5. functional. Keyless entry, Lock and Unlock will remain functional.
  • Page 19 PAGE 19 OF 26 AFTERMARKET REMOTE PROGRAMMING PROCEDURE - 1 OF 1 • 20191206 DOC.: #68188 >> WARNING: Program aftermarket remotes LED 1 will fl ash GREEN once [1x]. before usage. A maximum of four [4x] aftermarket remotes per system. Time restriction.
  • Page 20 PAGE 20 OF 26 MODULE NAVIGATION PROCEDURE - 1 OF 1 • 20191206 DOC.: #68188 >> It is mandatory to exit the Module Navigation TO ACCESS THE OPTIONS: Press and hold To save and return to the OPTIONS: Press and at the end of this procedure.
  • Page 21 PAGE 21 OF 26 MODULE NAVIGATION CHART - 1 OF 2 • 20191206 DOC.: #68188 MODULE NAVIGATION CHART: NOTES I Default settings are listed in bold. DISARM/UNLOCK BEFORE START II Make sure the option is covered on the vehicle before attempting to change the setting.
  • Page 22 PAGE 22 OF 26 MODULE NAVIGATION CHART - 2 OF 2 • 20191206 DOC.: #68188 MODULE NAVIGATION CHART: NOTES DOUBLE LOCK LOCK + UNLOCK HORN EVENT TRIGGER LOCK + UNLOCK + START CONFIGURATION DOUBLE LOCK + START 30 mSEC HORN CHIRPS WIDTH 15 mSec 60 mSec 02-07 Technical Support only...
  • Page 23 PAGE 23 OF 26 REMOTE STARTER ERROR CODES - 1 OF 1 • 20191206 DOC.: #68188 REMOTE STARTER ERROR CODES: NOTES Engine running. I WARNING: The following applies only when the parking lights are connected and supported by the system. Key in ignition at ON position.
  • Page 24 PAGE 24 OF 26 MODULE DIAGNOSTICS - 1 OF 1 • 20191206 DOC.: #68188 TEST MODULE Flashing RED Missing/wrong information from fi rmware or vehicle. Solid RED Module waiting for more vehicle information. Flashing GREEN Additional steps required to complete module programming. DURING PROGRAMMING Solid GREEN then OFF Module correctly programmed.
  • Page 25 PAGE 25 OF 26 MODULE RESET PROCEDURE - 1 OF 1 • 20191206 DOC.: #68188 Disconnect all connectors from module except Reconnect all connectors. the BLACK 20-PIN connector. Disconnect the BLACK 20-PIN connector. Repeat programming procedure. >> PRESS AND HOLD the module’s programming Failure to follow procedure may result with a button while connecting the BLACK 20-PIN DTC or a CHECK ENGINE error message.
  • Page 26 PAGE 26 OF 26 INSTALLATION CHECKLIST - 1 OF 1 • 20191206 DOC.: #68188 CHECKLIST WARNING: Vehicle engine will start many times. Test in a well ventilated area. Press the START/STOP button once [1x] on the aftermarket keyfob to shut down vehicle. Question 7: Does the vehicle shut down? Close all vehicle doors, hood and trunk.
