LUMIS Key Light
Desktop Bi-Color LED Panel
Anleitung auf Deutsch
Manual in English
www.rollei.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LUMIS Key Light and is the answer not in the manual?

Questions and answers

Summary of Contents for Rollei LUMIS Key Light

  • Page 1 LUMIS Key Light Desktop Bi-Color LED Panel Anleitung auf Deutsch Manual in English www.rollei.de...
  • Page 2: Table Of Contents

    Bestandteile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Aufbau des Rollei LUMIS Key Light . . . . . . . . . . . . . . . 8 Bedienung .
  • Page 3 Rollei LUMIS Key Light...
  • Page 4: Vor Dem Ersten Gebrauch

    Zwecken und insbesondere nicht zur häuslichen Raumbeleuchtung verwendet werden . Zeichenerklärung Die folgenden Symbole werden in dieser Bedienungsanleitung, auf dem Rollei LUMIS Key Light oder auf der Verpackung verwendet . Mit diesem Symbol gekennzeichnete Produkte erfüllen alle maßgeblichen Gemeinschaftsvorschriften des Europäischen Wirtschaftsraumes .
  • Page 5: Sicherheitshinweise

    Sicherheitshinweise 1 . Schließen Sie das Produkt nur dann an, wenn die Netzspannung des USB-Eingangs am Computer oder USB-Netzteil mit den Angaben auf dem Typenschild auf der Rückseite des Produkts übereinstimmt . 2 . Verwenden Sie das Produkt nicht, wenn es sichtbar beschädigt ist oder wenn das Kabel defekt ist .
  • Page 6 Sicherheitshinweise 9 . Nutzen oder lagern Sie das Gerät nicht bei hohen oder niedrigen Temperaturen oder in geschlossenen Räumen mit direkter Sonnen- einstrahlung . Bei Umgebungstemperaturen von mehr als 50° C oder unter -10° C sollte das Produkt nicht mehr genutzt werden . 10 .
  • Page 7: Bestandteile

    Bestandteile Lichtpanel Kugelkopf Stativbein Inbusschlüssel Schraube Stativfuß Fernbedienung Helligkeitsregulierung Betriebs-LED An- / Ausschalter Modusschalter...
  • Page 8: Aufbau Des Rollei Lumis Key Light

    (4) in das Gewinde unterhalb des Stativfußes (6) fest . – Montieren Sie das Lichtpanel (1) auf den Kugel- kopf (2) des Stativbeins (3) . – Justieren Sie im Anschluss das Rollei LUMIS Key Light auf die gewünschte Höhe, indem Sie die Beinsegmente des Stativbeins (3) auseinanderziehen .
  • Page 9: Technische Daten

    3200 K, 4500 K und 5500 K Farbwiedergabeindex (CRI) Leistungsregelung Über Fernbedienung in 8 Stufen Beleuchtungsstärke 630 lx (0,5 m bei 5500 K) Fernsteuerung Fernsteuerung an Kabel des Rollei LUMIS Key Light Stromversorgung DC 5V / 2A Anschlüsse Lichtpanel: ¼“-Gewinde, Kugelkopf am Stativbein: ¼“-Schraube Maße I Gewicht...
  • Page 10 Technische Daten Einbeinstativ mit Stativfuß Material Eisen und ABS-Kunststoff Gewicht 808 g Max . Höhe I Min . Höhe 780 mm I 285 mm Beinsegmente Stativbeindurchmesser 25 mm, 20 mm, 16 mm, 14 mm Durchmesser Stativfuß 168 mm Lieferumfang Lichtpanel, Kabel mit Fernbedienung, Stativbein mit Kugelkopf, Stativfuß, Inbusschlüssel und Schraube Änderungen von Design und technischen Daten bleiben vorbehalten und bedürfen keiner Ankündigung .
  • Page 11: Entsorgung

    . Informationen zu Sammelstellen, die Altgeräte kostenlos entgegennehmen, erhalten Sie bei Ihrer Gemein- de- oder Stadtverwaltung . Konformität Hiermit erklärt die Rollei GmbH & Co . KG, dass dieses Gerät „Rollei LUMIS Key Light“ den folgenden Richtlinien entspricht: 2011/65/EU RoHS-Richtlinie 2014/30/EU EMV-Richtlinie Der vollständige Text der EU-Konformitätserklärung ist unter der fol-...
  • Page 12: Before The First Use

    . Explanation of Symbols The following symbols are used in this manual, on the flash, Rollei LUMIS Key Light unit or on the packaging . Products marked with this symbol comply with all relevant community regulations of the European Economic Area .
  • Page 13: Safety Instructions

    Safety Instructions 1 . Only connect the product if the mains voltage of the USB input on the computer or USB power supply matches the information on the type plate on the back of the product . 2 . Do not use the product if it is visibly damaged or if the cable is defective .
  • Page 14 Safety Instructions 11 . Do not point the switched on product at drivers of cars, buses, bicycles, motorcyclists, or train drivers while driving . The driver can be blinded and cause an accident . This also applies to persons or groups not listed if an accident could be caused by possible glare .
  • Page 15: Components

    Components Light panel Ball head Monopod Hex wrench Screw Base plate Remote Control Brightness control Operation LED On / Off switch Mode button...
  • Page 16: Setting Up The Rollei Lumis Key Light

    DC 5 V / 2 A) . Operation – After having set up the Rollei LUMIS Key Light, you can switch the light on and off using the on / off switch (9) of the remote control on the cable of the Rollei LUMIS Key Light .
  • Page 17: Technical Data

    Via remote control in 8 steps Illuminance 630 lx (0 .5 m at 5500 K) Remote control Via the remote control in the cable of the Rollei LUMIS Key Light Power supply DC 5 V = 2A Connections Light panel: ¼“ screw thread, ball head on monopod: ¼“...
  • Page 18 Technical Data Monopod with base plate Material Iron and ABS Weight 808 g Max . height I Min . height 780 mm I 285 mm Monopod segments Diameter segments 25 mm, 20 mm, 16 mm, 14 mm Diameter base plate 168 mm Box content Light panel, cable with remote...
  • Page 19: Disposal

    . Conformity Rollei GmbH & Co . KG hereby declares that the device ”Rollei LUMIS Key Light“ complies with the following directives: 2011/65/EU RoHS Directive...
  • Page 20 Rollei GmbH & Co. KG In de Tarpen 42 D-22848 Norderstedt Service Hotline: +49 40 270750277 /rollei.foto.de @rollei_de www.rollei.com...
