CDA PC85SC Operation Manual

Domestic refrigerator/freezer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Table of Contents

Table of Contents
Before Use
Features ................................................1
Names of Parts ..................................... 2
Safety Alert Symbols ..........................3-5
Safety Precautions.................................6
Installation..............................................7
Removing & Replacing Door..............8~9
Preparation.....................................10~13
Initial Use..............................................14
Operation Instructions
Functions........................................15~18
Refrigerator Compartment..............19~21
Compartment........................................22
Useful Tips............................................23
Freezer Compartment....................24~25
Care and Maintenance
Defrosting • Cleaning............................27
Vacation..........................................28~29
Troubleshooting • After-S ales Services
Troubleshooting..............................30~31
After-Sales Services.......................32~33
Technical Data• / Packing List
Technical Data• Circuit Diagram...........34
Packing List..........................................35
After-Sale Information
• Please read this User Manual carefully before use.
• Please keep this User Manual in a safe place.
• Your refrigerator could be slightly different from that
illustrated herein with respect to appearance, or
colour.
