Furuno VR-3000 Installation Manual

Hide thumbs Also See for VR-3000:
Table of Contents

Advertisement

Quick Links

SIMPLIFIED VOYAGE DATA RECORDER
SAFETY INSTRUCTIONS ............................................................................................... i
EQUIPMENT LISTS........................................................................................................ ii
SYSTEM CONFIGURATION ......................................................................................... iv
RECORD OF PUB REV., PROG. NO.............................................................................. v
1. MOUNTING ............................................................................................................... 1
1.1 System Overview .....................................................................................................................1
1.2 Data Collecting Unit .................................................................................................................2
1.3 Data Recording Unit.................................................................................................................5
1.4 Junction Box ............................................................................................................................6
1.5 Remote Alarm Panel ................................................................................................................7
1.6 Microphone ..............................................................................................................................8
1.7 VHF Interface Unit IF-5200 (option) ....................................................................................... 12
2. WIRING.................................................................................................................... 13
2.1 System Wiring........................................................................................................................ 13
2.2 Data Collecting Unit ............................................................................................................... 14
2.3 Data Recording Unit (connecting IEEE1394 cable) ............................................................... 30
2.4 Junction Box .......................................................................................................................... 35
2.5 Remote Alarm Panel .............................................................................................................. 37
2.6 Microphone ............................................................................................................................ 38
2.7 Sensor Data ........................................................................................................................... 40
2.8 VHF Interface Unit ................................................................................................................. 44
2.9 Installation of Interface Board for Radar ................................................................................ 45
3. SETUP ..................................................................................................................... 46
3.1 VHF Interface Unit ................................................................................................................. 46
3.2 Data Collecting Unit ............................................................................................................... 47
3.3 DIP Switches in Junction Box ................................................................................................ 48
3.4 Recording Expiration Date of Parts........................................................................................ 51
3.5 System Time Adjustment ....................................................................................................... 52
PACKING LISTS..........................................................................................................A-1
OUTLINE DRAWINGS.................................................................................................D-1
INTERCONNECTION DIAGRAMS..............................................................................S-1
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
VOYAGE DATA RECORDER
Installation Manual
www.furuno.com
VR-3000
Model
VR-3000S
Model

Advertisement

Table of Contents
loading

Related Manuals for Furuno VR-3000

Summary of Contents for Furuno VR-3000

  • Page 1: Table Of Contents

    VOYAGE DATA RECORDER VR-3000 Model SIMPLIFIED VOYAGE DATA RECORDER VR-3000S Model Installation Manual SAFETY INSTRUCTIONS ....................i EQUIPMENT LISTS......................ii SYSTEM CONFIGURATION ..................iv RECORD OF PUB REV., PROG. NO................v 1. MOUNTING ....................... 1 1.1 System Overview ........................1 1.2 Data Collecting Unit .........................2 1.3 Data Recording Unit.........................5...
  • Page 2 ・FURUNO Authorized Distributor/Dealer 9-52 Ashihara-cho, Nishinomiya, 662-8580, JAPAN A : APR 2006 Printed in Japan All rights reserved. P : JUN . 09, 2020 Pub. No. IME-44370-P (REFU ) VR-3000/3000S 0 0 0 1 7 4 7 2 2 1 3...

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS CAUTION WARNING Observe the following compass safe Turn off the power at the switchboard distances to prevent interference to a before beginning the installation. magnetic compass: Fire or electrical shock can result if the Standard Steering power is left on. compass (m) compass (m) Do not install the equipment where it...

  • Page 4: Equipment Lists

    EQUIPMENT LISTS Standard supply Name Type Code No. Remarks Data Collecting VR-3010 — Unit Data Recording 9 GB, for connection of 2-4 VR-5020-9G — Unit radars Remote Alarm VR-3016 — Includes installation materials Panel Junction Box IF-8530 — Option on VR-3000S Microphone VR-5011 —...
  • Page 5 Optional supply Name Type Code No. Remarks VHF Interface To combine mic and loudspeaker IF-5200 000-040-789 Unit lines LAN Cable Set CP03-28900 000-082-658 10 m For installation of IF-8530, w/connector CP03-28910 000-082-659 20 m MP5588-C, 30 m CP03-28920 000-082-660 FR-FTPC-CY (10 m) Removable Hard VR-3011-A 001-173-390...

  • Page 6: System Configuration

    SYSTEM CONFIGURATION Data Recording Unit (DRU) VR-5020-9G Waterproof MIC Analog (max.16ch) VR-3012W Digital (max.64ch) Bridge MIC Max. 6 ch Data Collecting VR-5011 Remote Alarm Serial (1ch) VHF I/F Unit (DCU) Panel (RAP) IF-5200 VR-3010 VR-3016 Max. 2 ch VHF Audio Junction Box (JB) IEC61162 Serial (max.8ch)

  • Page 7: Record Of Pub Rev., Prog. No

    Record of PUB REV., PROG. No. Revision No., Program No. Outline of Revision Date of Revision (software) printing. VR-3000 SYSTEM Apr. 19, 2006 2450031-01 2450026-01 A1 (For BSH) Same as above p. iv June 2, 2006 Added MIC VR-3012W to optional supply.
  • Page 8 This page is intentionally left blank.

  • Page 9: Mounting

    1. MOUNTING NOTICE Do not apply paint, anti-corrosive sealant or contact spray to coating or plastic parts of the equipment. Those items contain organic solvents that can damage coating and plastic parts, especially plastic connectors. 1.1 System Overview The basic VDR consists of •...

  • Page 10: Data Collecting Unit

    1.2 Data Collecting Unit The DCU is designed for on-deck or bulkhead installation, and should be mounted within the wheelhouse. Mount it in a place convenient for connection with relevant sensors and associated devices. For bulkhead mounting, be sure the mounting location is strong enough to support the weight of the unit under the vibration normally encountered onboard the vessel.
  • Page 11 1.2.2 Mounting dimensions, mounting procedure Fasten the unit to the chosen location with M10 bolts or ø10 coach bolts. Bend radius 150 mm Clamping point 300 mm or more Mounting dimensions of DCU...
  • Page 12 1.2.3 Attaching card holder to door A card holder for convenient storage of LAN cable, IEEE1394 cable, Error code table and Data extraction procedure on the door of the DCU is available. Remove paper from double-sided tape on the card holder and attach it to the door at the location shown below, aligning bottom edge of card holder with bottom edge of door.

  • Page 13: Data Recording Unit

    1.3 Data Recording Unit The DRU contains a protective capsule and it should be installed in the vicinity of the bridge on the open deck area of the vessel. This will maximize the probability of its survival and facilitate recovery following an incident. The DRU should be positioned clear of rigging and other potential obstructions and as near to the centerline of the ship as possible.

  • Page 14: Junction Box

    1.4 Junction Box The Junction Box, optionally available with the VR-3000S, provides for connection of digital, serial and analog equipment, and three units may be connected. The No. 1 JB has the following channels: Eight channels of IEC 61162 (two IEC 61162-2 and six IEC 61162-1), 64 channels of digital, and 16 channels of analog.

  • Page 15: Remote Alarm Panel

    1.5 Remote Alarm Panel Make sure there is a sufficient space for access to the rear cover for mounting and cabling. The Remote Alarm Panel is flush-mounted. See the outline drawing for cutout size. FIX UNIT WITH SELF-TAPPING SCREWS. SET CAPS AFTER FASTENING SCREWS. Mounting dimensions of Remote Alarm Panel Attach the IMPORTANT label (large or small one supplied in accessory) near the remote alarm panel.

  • Page 16: Microphone

    1.6 Microphone 1.6.1 Bridge microphone VR-5011 The bridge microphone comes with a flush mount plate. Fix the plate with six 4x16 self-tapping screws. The microphone covers an area about 10 m in diameter with the height of 2 m. Six microphones can cover a maximum 60 m diameter bridge area (including wings).
  • Page 17 Mounting dimensions of Microphone VR-5011...
  • Page 18 1.6.2 Waterproof microphone VR-3012W The waterproof microphone VR-3012W may be mounted on a wing, and is available in bulkhead and flush mount versions. Mounting considerations The following consideration must be taken into account to decide the location of the waterproof microphone.
  • Page 19 Flush mount 1. Prepare a cutout (120x60 mm) in the mounting location, referring to the outline drawing. 2. Dismount the microphone chassis from the case to detach MIC assy. Leave the rubber gasket attached to the MIC assy. The case may be discarded. 3.

  • Page 20: Vhf Interface Unit If-5200 (Option)

    Mounting Fix the unit using 4x20 self-tapping screws. Remove the cover to access to holes. When a non-FURUNO VHF is connected to the unit, using the terminal board, remove unused wires and connectors. Otherwise, noise problem may arise. Audio level is adjusted by DIP switches in the interface unit after installation. See paragraph 3.1.

  • Page 21: Wiring

    2. WIRING 2.1 System Wiring Data Recording Unit (DRU) VR-5020-9G IEEE1394 cable (20m, 25m or 30m, w/ armor) Analog (max.16ch) Waterproof MIC TTYCS-1 VR-3012W TTYCS-4 Digital (max.64ch) (max. 6 ch) Bridge MIC Data Collecting TTYCS-1 Remote Alarm VR-5011 TTYCS-4 VHF I/F Unit (DCU) Panel (RAP) Serial (1ch)

  • Page 22: Data Collecting Unit

    2.2 Data Collecting Unit 2.2.1 Location of connectors and terminals Radar video connectors (4) beneath this plate Side of the PCB case: J33 (KEYBOARD) J28 (VGA) Playback/CPU SW J24 (RS232C) DRU (Reserved for future use) From left: From top: J8 (DRU) TB10 (MIC5) J6 (Playback) TB11 (MIC6)
  • Page 23 Connectors, terminals, etc. inside the DCU Terminals and connectors in the DCU Connector/TB Signal/Unit to be connected TB1 (100-230 VAC IN) 100-230 VAC TB2 (24 VDC IN) 24 VDC TB3 (24 VDC OUT) 24 VDC for JB TB4 (RAP) Remote Alarm Panel TB5 (AMS) Alarm Monitoring System TB6-TB11 (MIC1-MIC6)
  • Page 24 2.2.2 Working inside the unit Snap/wire assembly for keeping door of DCU open A snap/wire assembly which keeps the door of the DCU open while working inside the DCU is provided. Use it to keep the door open and prevent deformation of the door when it is opened. Attach one snap to the hole on the door and the other snap to the hole to the right of the battery handle.
  • Page 25 Lead-fitting tool Radar, MIC, VHF, etc. are connected to the terminals and connectors in the DCU. The terminal board has WAGO connectors for leads of up to 2.5 mm or AWG 14 wires. Use the lead-fitting tool, attached inside the DCU, to fix wires to WAGO connectors, as shown in the illustration below. Lead fittting tool How to use lead-fitting tool 3) Tug on wires to confirm that they are securely...
  • Page 26 2.2.3 Cable fabrication DPYC-1.5, DPYC-2.5 (power cables) L=150 Armor Armor Sheath Sheath  11.7 mm Cut the sheath. Conductor Remove paint. S = 1.5 mm  = 1.56 mm DPYC-1.5 cross section view Armor 15 10 Sheath  12.5 mm Vinyl tape Conductor Crimp-on lug...
  • Page 27 TTYCS-1Q (Serial equipment, format IEC 61162-2) L=300 Armor Shield Remove paint by 50 mm. Sheath Cut vinyl sheath. Shield  = 11.3 mm Conductor S = 0.75 mm Expose cores, trim shield,  = 1.11 mm solder ground wire to shield, attach crimp-on lug TTYCS-1Q cross section view to ground wire.
  • Page 28 How to process armor of IEEE1394 cable Ground the armor of the IEEE1394 cable by the cable clamp at the DCU. Fabricate the cable as follows. 1. Confirm the label “DCU” at the end of the cable end. (Fabricate the cable at the DCU side.) 2.
  • Page 29 2.2.4 Power supply Connect the DCU unit as follows: • AC power: Connect the ship’s mains to “100-230 VAC IN” in the DCU with cable DPYC-1.5 (or equivalent). If AC emergency source of electrical power is provided, connect it to the AC line. •...
  • Page 30 RADAR I/F Board (optionally available with the VR-3000S) inside the DCU, with a 15-pin VGA Male to 5x BNC RGBHV cable. (Cable is supplied with VR-3000, and is available optionally with the VR-3000S.) The system supports separate sync, sync-on-green, and composite sync signals.
  • Page 31 Connection of radar video signal in DCU Cable assy. BNCX5-DSUB-L700 Bind cables with cable tie. (length: 700 mm) Fix the cable with this cable clip. Connector arrangement on RADAR I/F Board Cable assy. BNCX5-DSUB-L400 (length: 400 mm) Fix the ground wire with the screw. Tape BNC connector with vinyl insulating tape.
  • Page 32 Cable arrangement in cable clamp and coaxial cable type 3C-2V coaxial cable 5C-2V coaxial cable Five coaxial cables Five coaxial cables bound with cable tie, inside and outside the DCU.
  • Page 33 Attaching coaxial connector Washer Clamping nut Gasket Center 1) Slip clamping nut, washer and gasket onto cable. 5) Insert center pin to core and solder. 7 mm Shell 2) Strip sheath by 7 mm. 6) Screw shell into cable. 3 mm Completed 3) Strip shield and insulator by 3 mm.
  • Page 34 FAR-21x7/28x7 series radar For the connection between the VR-3000 and FAR-21x7/28x7 series radar, refer to the respective radar installation manual. FR-21x5 series radar Modify the FR-21x5 series radar as shown below to connect it to the VR-3000/VR-3000S. Parts of FR-21x5 series radar modification kit...
  • Page 35 FAR/FR-28x5 series radar Modify the FAR/FR-28x5 series radar as shown below to connect it to the VDR. Parts of FAR/FR-28x5 series radar modification kit Parts Name Type Code No. VDR I/F kit (1) OP03-177 008-528-270 1 set RGB-BUFF board 03P9229A NH-XH connector assy.
  • Page 36 ACK and remote ACK. See the figure below and the two on the next page for details. System failure VR-3000/VR-3000S notifies the AMS that an alarm has been generated. Use NC port. Contact Rating Voltage: less than 32 V NC: Normal Closed Contact Current: Less than 0.2 A...
  • Page 37 Remote ACK AMS notifies the VR-3000/VR-3000S that it has acknowledged system failure. +24 V 3.3 K 3.3 K Active > 150 ms > 150 ms > 150 ms Total impedance (contact and cable) shall be less than 500 ohms. Active interval A and B of Remote ACK NC: Normal Close Contact signal shall be more than 150 msec.

  • Page 38: Data Recording Unit (Connecting Ieee1394 Cable)

    2.3 Data Recording Unit (connecting IEEE1394 cable) Connect the DRU and DCU with the IEEE1394 cable (20 m, 25 m, or 30 m). The cable is attached the connectors at both ends. The connectors are labeled “DCU” and “DRU,” respectively; do not confuse the connectors. For the IEEE1394 cable, keep in mind the following points.
  • Page 39 3. Grease inside and outside of rubber bushing with supplied lubricant. This allows for the rubber bushing/cable and rubber bushing/DRU connections to slide easily. 4. Coat threads with lubricant to prevent scorching of threads. DO NOT coat the connector. 5. Confirm that the connector does not have a notch then connect it to receptacle on the DRU.
  • Page 40 7. Coat the surface of the teflon washer and connecting part of the cable with supplied silicone sealant. Gap: Approx. 2.6 mm Gap: Approx. 2.6 mm approx. 1 thread DO NOT OVERTIGHTEN Thread Thread screw How to tighten cap nut 8.
  • Page 41 How to fix the DRU to the mounting base - Mounting base "A" to be supplied by shipyard. - Fix the DRU on the compass deck. - Select the location where the DRU can be easily maintained. - Locate well away from other equipment. Loop : >30cm - Do not cut the cable even if it is too long.
  • Page 42 How to connect the cable to the DCU Connect the cable to the DRU port J8 in the DCU and fix it with a cable tie. Using vinyl tape, tape from tip of connector to about 8 cm. Fix the cable to the support plate with the cable tie. Optional Kit The optional kit is provided for the IEEE1394 cable run through the deck.

  • Page 43: Junction Box

    2.4 Junction Box Connect the junction box to the DCU before turning on the system. 2.4.1 Location of connectors Navigation device, etc. are connected to the terminals and connectors on the terminal board in the JB. The terminal board has WAGO spring-catch terminal blocks for leads of up to 2.5 mm AWG 14 wires.
  • Page 44 2.4.2 Cable fabrication Cable type DPYC-1.5 (power), TTYCS-1 and TTYCS-1Q (serial IEC 61162-1 and IEC 61162-2, respectively), and TTYCS-1 (analog) connect various equipment to the JB. For fabrication of those cables, see paragraph 1.1.3. 2.4.3 Ground Connect a ground wire (IV-8sq) between the ground terminal on the unit and ship’s grounding bus.

  • Page 45: Remote Alarm Panel

    2.5 Remote Alarm Panel - Clamp armor of cable. - Connect shield to shield screw on back panel. - Connect Wago connector to terminal after removing chip to avoid damage to terminal. - Spacer "A" is not necesary when space is too wide as in A above.

  • Page 46: Microphone

    2.6  Microphone A maximum of 6 microphones can be connected, to TB6 thru TB11 in the DCU. A dual twisted, balanced cable carries the following signals: +: 24 VDC (+) A: Audio signal line, balanced, 0 dBm B: Audio signal line, balanced, 0 dBm -: 24 VDC (-) MIC1 audio is mixed with MIC2 audio, MIC3 with MIC4, and MIC5 with MIC6, respectively.
  • Page 47 2.6.2 VR-3012W Bulkhead mount 1. Unfasten the cover. 2. Lead in wiring through the cable gland and connect it to the terminal board on the rear side the cover, referring to the interconnection diagram. See page 19 for how to fabricate the cable. Be sure to ground shield.

  • Page 48: Sensor Data

    2.7 Sensor Data Note: The serial channels in the Junction Box IF-8530 can receive the maximum of 82 characters in a sentence, consisting of a maximum of 79 characters between the starting delimiter "$" or “!” and the terminating delimiter <CR>, <LF> as defined by NMEA0183/IEC61162. 2.7.1 IEC 61162-1 serial data 12 channels are provided to receive IEC 61162-1 serial data, six in the DCU and six in the JB.
  • Page 49 2.7.2 IEC 61162-2 serial data 4 channels are provided to receive IEC 61162-2 serial data, two in the DCU and two in the JB. Data Collecting Unit IEC 61162-2 interface circuit in Data Collecting Unit Junction Box IEC 61162-2 interface circuit in Junction Box...
  • Page 50 2.7.3 Non-IEC 61162 signal 1) Analog 4 to 20 mA, 0 to 10 V and –10 to +10 V signals (max. 16 channels) can be connected to the ANALOG terminals in the JB. Input voltage (current) range is set by DIP switches in the junction box.
  • Page 51 +24 V 2.2 K Jumper 2.2 K Interfacing of contact-closure signal Note: Jumpers are fitted at factory between A and 24 terminals for CH1 to CH32 in order to connect contact-closure signal. To connect a voltage signal to CH1 to CH32, remove jumper by using two openers attached inside the junction box.

  • Page 52: Vhf Interface Unit

    PTT Switch signal: TTL level Output: 0 dBm±10dB, 600 ohms, balanced When a wing handset is used, the connection is made as follows. HANDSET IF-5200 FM-8700 DC24V FM10PS-6H TTYCS-1 VR-3000 DCU HANDSET CC490, 1m TB12 TTYCS-1 OUT1** FM14-7P OUT2** TB13 WING HANDSET...

  • Page 53: Installation Of Interface Board For Radar

    2.9 Installation of Interface Board for Radar When the interface board for connection of radar(s) is not installed at the factory, install it (in the DCU) as shown below. 1. Remove ten screws shown below to detach the PCB. 2. Remove the screws shown below to remove the fixing plate. Remove this screw to remove the fixing plate.

  • Page 54: Setup

    3. SETUP This chapter describes how to set up and check the system. 3.1 VHF Interface Unit 3.1.1 Audio level adjustment DS1 and DS3 are 10 dB step attenuators for channel 1 and 2 microphone lines respectively. Set the DIP switch so that the audio output level between #4 and #5 (OUT1) and between #7 and #8 (OUT2) of CN9 is 0 dBm (2.2 Vp-p).

  • Page 55: Data Collecting Unit

    3.2 Data Collecting Unit The system configuration must be updated after installation. See instruction manual for VDR Maintenance Viewer and operator’s manual for Live Player V4 for the procedure. The outline of the system configuration is; Step 1: Network setting on PC Step 2: Connection of PC Step 3: Software configuration Step 4: Making a backup copy of configuration data...

  • Page 56: Dip Switches In Junction Box

    DIP switches in the JB are provided to set up the system according to equipment connected. The default setting for all DIP switches is “OFF”. Turn off the VR-3000/S and junction box to change the DIP switch setting. After setting the DIP switches, turn on the system to apply the settings.
  • Page 57 Serial data baud rate (DIP SW S3, S4) Use for No. 1 JB (Set S5-6, S5-7, S5-8 as OFF, OFF, OFF.) Serial Baud Rate Setting (bps) Channel SW No. Label 4800 9600 19200 38400 S4-1 — — S4-2 — — S4-3 —...
  • Page 58 Junction box no. setting (DIP SW S5) JB No. JB DIP SW JB IP Address JB NW Mode S5-6: OFF 172.31.24.10 S5-5: OFF S5-7: OFF S5-1: OFF S5-8: OFF S5-2: OFF S5-3: OFF S5-4: OFF S5-6: OFF 172.31.24.11 S5-5: ON S5-7: OFF S5-1: ON S5-8: ON...

  • Page 59: Recording Expiration Date Of Parts

    3.4 Recording Expiration Date of Parts After installing and setting up the system, record the expiration date of major parts of the system, on the sheet provided. Cut out (or copy and cut) an expiration data sheet from the ones below. For interval-specific parts record date of expiration and for general consumable parts the date of replacement.

  • Page 60: System Time Adjustment

    USB connector. DCU, door opened 2. Turn on the VR-3000 while pressing and holding down the F2 key. 3. Wait for the BIOS screen to come up. (Keep the F2 key pressed.) 4. Set the system time about 10 seconds behind UTC or GPS time.
  • Page 69 Y. Hatai...
