4. Overview

5. Technical Data

6. Command buttons

The Reflow CONTROLLER has a plug housing and connection to the oven. It has
3 command buttons, 6 LED's to display status and errors, and a buzzer.
Operating voltage:
Max. connected load:
PC-Connection:
Off
Solder
Learn
230V~/50Hz
1500 W
RS232
Pin 2 = TxD, Pin 3 = RxD, Pin 5 = GND
9600 Baud, 8-bit, NO parity, 1 stop bit, no handshake
CONTROLLER switched off. Plug socket will
become switched off,
interrupted.
Start the automatic soldering cycle.
An automatic alignment and systems check are
begun. The CONTROLLER
characteristics of the oven in use.
Instruction Manual
Reflow-Controller
current programs
learns the
