Settings and Calibrations

The Reflow CONTROLLER can be adjusted to suit different solder pastes,
different temperature sensors and different oven types. The necessary settings
are entered using the computer interface.
phttemp Temperature of the preheating phase [0 to 254 degrees].
phttemp<ENTER> indicates the current value.
phttemp 120 <ENTER> adjusts the temperature to 120°C
phttime Duration of the preheating phase [0 to 254 sec].
phttime<ENTER> indicates the current value.
phttime 240 <ENTER> adjusts the duration to 240 seconds.
phtpwr Amount of heat of the preheating phase [0 to 100%]
phtpwr<ENTER> indicates the current value.
phtpwr 80 <ENTER> the oven will heat to 80% of capacity.
soaktemp Temperature of soaking phase [0 to 254 degrees]
soaktemp<ENTER> indicates the current value.
soaktemp 165<ENTER> adjusts the temperature to 165°C.
soaktime Duration of soak phase [0 to 254 seconds]
soaktime<ENTER> indicates the current value.
soaktime 240<ENTER> adjusts the duration to 240 seconds.
soakpwr Amount of heat of soak phase [0 to 100 %]
soakpwr<ENTER> indicates the current value.
soakpwr 80<ENTER> oven heats to 80% capacity
reflowtemp Reflow temperature [0 to 254 degrees]
reflowtemp <ENTER> indicates the current value.
reflowtemp 232<ENTER> the temperature adjusts to 232°C.
reflowtime Reflow time [0 to 254 seconds]:
This parameter has at present no meaning. The Reflow phase
is terminated as soon as the adjusted Reflow temperature has
been reached.
