7.5.

Computer interface

7.6.

Settings

The Reflow CONTROLLER is equipped with a RS232 interface for connection to
a PC (optional).
The CONTROLLER is connected with a standard commercial cable for serial
interfaces with the PC.
Adjust the serial interface of the attached computer to the following parameters:
9600 Baud, 8-bit, NO parity, 1 stop bit, no handshake
After the switching on of the CONTROLLER it announces itself with:
# PCBP-Reflow Controller
# Software Date : Apr 17 2006
# Software Time : 12:20:16
# start selftest
# selftest ready
Type "help" for command list.
The Reflow CONTROLLER can be operated using a terminal software such as
Miniterm (Linux) or Hyperterminal (Windows).
