E CHAPTER 1. Market QT-V5E/QT-V5H Service Manual QT-V5E/QT-V5H Audio
GENERAL DESCRIPTION

[1] Specifications

FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
QT-V5E
Power source AC 230 - 240 V, 50 Hz
DC 12 V ["D" size (UM/SUM-1, R20 or HP-2) battery
DC 3 V ["AA" size (UM/SUM-3, R6 or HP-7) battery 2 for
memory]
Power consumption 23 W
Output power RMS: 10 W (5 W + 5 W) (10 % T.H.D., 1 kHz)
Speakers Full range speaker system 8 cm 1/each
Dimensions Width: 420 mm
Height: 150 mm
Depth: 260 mm
Weight 4.6 kg
Signal system PAL/NTSC color
Supported disc types DVD (region number 2 or ALL), SVCD, VCD, audio CD,
CD-R, CD-RW, MP3
Video signal Horizontal resolution: 500 lines
S/N ratio: 70 dB
Audio signal Frequency character-
istics
S/N ratio
Dynamic range
Total harmonic distor-
tD:ion ratio
Audio output termi- Headphones: 16 - 50 ohms (recommended: 32 ohms)
nals
Optical digital output: Square type 1
Analog output: RCA type
Video output termi- SCART output: SCART terminal
nals
Video output: RCA type 1
S-video output: S-terminal 1
Frequency range FM: 87.5 - 108 MHz
AM: 522 - 1,620 kHz
8]
Linear PCM DVD:
20 Hz to 20 kHz (sampling rate:
48 kHz)
20 Hz to 20 kHz (sampling rate:
96 kHz)
CD: 20 Hz to 20 kHz
CD: 80 dB (1 kHz)
Linear PCM DVD: 70 dB
CD: 70 dB
0.01 % maximum
1 pair (L/R)
1
1 – 1
QT-V5H
Power source AC 230 - 240 V, 50 Hz
DC 12 V ["D" size (UM/SUM-1, R20 or HP-2) battery
DC 3 V ["AA" size (UM/SUM-3, R6 or HP-7) battery 2 for
memory]
Power consumption 23 W
Output power RMS: 10 W (5 W + 5 W) (10 % T.H.D., 1 kHz)
Speakers Full range speaker system 8 cm 1/each
Dimensions Width: 420 mm
Height: 150 mm
Depth: 260 mm
Weight 5.2 kg
Signal system PAL/NTSC color
Supported disc types DVD (region number 2 or ALL), SVCD, VCD, audio CD,
CD-R, CD-RW, MP3
Video signal Horizontal resolution: 500 lines
S/N ratio: 70 dB
Audio signal Frequency character-
istics
S/N ratio
Dynamic range
Total harmonic distor-
tion ratio
Audio output termi- Headphones: 16 - 50 ohms (recommended: 32 ohms)
nals
Optical digital output: Square type 1
Analog output: RCA type
Video output termi- SCART output: SCART terminal
nals
Video output: RCA type 1
S-video output: S-terminal 1
Frequency range FM: 87.5 - 108 MHz
AM: 522 - 1,620 kHz
Specifications for this model are subject to change without
prior notice.
QT-V5E/QT-V5H
8]
Linear PCM DVD:
20 Hz to 20 kHz (sampling rate:
48 kHz)
20 Hz to 20 kHz (sampling rate:
96 kHz)
CD: 20 Hz to 20 kHz
CD: 80 dB (1 kHz)
Linear PCM DVD: 70 dB
CD: 70 dB
0.01 % maximum
1 pair (L/R)
1
