Sharp QT-V5E Quick Start Manual

MODEL
QT-V5E
DVD/CD SYSTEM
This Quick Start Guide will help you to correctly install and operate your system.
If you require any advice or assistance regarding
your Sharp product, please visit our web-site
www.sharp.co.uk/customersupport.
Customers without Internet access may telephone
08705 274277 during office hours (or (01) 676 0648
if telephoning from Ireland).
1
Open the battery compartment.
2
Insert the 2 supplied "AA" size batteries (UM/SUM-3, R6, HP-7 or similar) into the
battery compartment.
3
Close the battery compartment.
Using with the AC power lead
After checking all the connections, connect the AC power lead to the AC
power input socket, then to the wall socket.
Before connecting the AC power lead, remove the cardboard from the AC
power plug.
9HX8043210003A
04F Z AO 1
Downloaded from: http://www.usersmanualguide.com/
"AA" size battery (UM/SUM-3,
R6, HP-7 or similar)
0301
Connecting to a TV
Video cable
Video
signal
(supplied)
Inserting memory batteries
1
2
3
Wall socket
(AC 230 - 240 V, 50 Hz)
Accessories
Remote control 1 AC power lead
Yellow
Video cable
2
To video input socket TV
Audio cable (supplied)
1
Battery installation for the remote control
Remove the battery cover.
Insert the 2 supplied "AAA" size batteries (UM-4, R03, HP-16 or similar)
according to the direction indicated in the battery compartment.
When inserting or removing the batteries, push them toward the
Replace the cover.
1 "AAA" size battery (UM-4,
R03, HP-16 or similar) 2
1 Audio cable 1
To audio input sockets
Audio signal
2
battery terminals.
