Summary of Contents for Flyer S533

  • Page 1 Let’s ride.
  • Page 3: Table Of Contents

    CONT EN TS Parts Included Assembly Flyer App Usage eScooter Controls Charging Instructions How To Ride Folding Specifications Cleaning, Storage, & Battery Maintenance Maintenance & Troubleshooting Safety Guidelines...
  • Page 4: Parts Included

    PAR TS I N C LU D E D FLYER™ S533 ALLEN WRENCH SCREWS HANDLEBAR CHARGER 309636 309634 Grey – 309562 309652 White – 309563 Red – 309564...
  • Page 5: Assembly

    ASSEM BLY Step 1 Ste p 2 Ste p 3 Rotate the tube to the vertical Rotate the lever up while Slide the locking sleeve down position. holding the tube in place. until it is fully seated. Warning! The lever must be completely locked in the upright position.
  • Page 6 Step 4 Ste p 5 Step 6 Align the arrows on the Slide the handlebar assembly Install four screws to the top of handlebar and tube conectors. the tube using the provided Hex into the tube. Push the handle Once arrows are aligned, push wrench.
  • Page 7 Ste p 7 Check front air tire pressure. Inflate air tire to 25 PSI. Warning! It is important to maintain proper air pressure in the front tire while riding. Do not overinflate or underinflate the tires. Overinflated tires may burst. Inflate your tires using an air source with a pressure gauge to avoid over inflation.
  • Page 8: Flyer App Usage

    Fl yer A p p C ap ab i l it i es Download the Flyer™ Power on the eScooter and ensure your The Flyer™ App allows you to App using the App device has Bluetooth turned on. Click change speed settings, turn the Store or on Google “Connect to eScooter”...
  • Page 9: Escooter Controls

    ES COOT E R CON T RO L S Powe r On Power O ff C h an g e S pe e d S e tti ng He ad l ig h t Hold down power Hold down power Tap the power button twice Tap the power button button for 1 second.
  • Page 10 DASH DI SP L AY S P EE D OM E T E R S P E E D MO D E B ATT E RY LE V E L P OW E R BU TTO N ( MU LTI F U NCT IO NAL ) C HANGE SPE E D : Tap power button twice to change speed setting.
  • Page 11: Charging Instructions

    CH AR GI N G IN ST R UC T I O NS WARNING: Do not attempt to charge if the charging port or power adapter is wet. WARNING: Only use charger specified by the manufacturer. MANUFACTURER: DONGGUAN ANGDI TECHNOLOGY CO LTD, MODEL: BC266420200 WARNING: Ambient temperature must be...
  • Page 12: How To Ride

    HOW TO R I D E STO M P BRAK E THROT TLE BR AK E K ick to St ar t B ra kin g Place one foot on the deck, and use your other to Use the stomp brake or the left thumb trigger on kick the scooter forwards.
  • Page 13: Folding 1

    FO L DIN G Ste p 1 Step 2 Ste p 3 Step 4 Slide locking sleeve up. Rotate the lever down Rotate the tube 90 Push the handlebar down while holding the tube degrees until it is until the latch engages upright to avoid sudden resting on the stomp with the slot on the top...
  • Page 14 U N F O L D I N G Step 1 Step 2 Step 3 Ste p 4 Push down the stomp Rotate the tube 90 Rotate the lever 90 Slide the locking sleeve brake to free the degrees until it is in the degrees to the upright down until it is fully handlebar latch.
  • Page 15 WARNING: Failure to follow unfolding instructions could result in unintentional folding. Ensure that the lever is upright and the sleeve is locked in place.
  • Page 16: Specifications

    SP E CIF ICAT IONS Battery 6.4 Ah (10S2P) Battery Range Up to 15.5 mil Charging 42VDC @ 2.0 Amp Charger Flyer™ App iOS and Android Firmware Updates Update Via Bluetooth Connectivity Bluetooth IP Rating Deck IP34, Battery IP67 Lights...
  • Page 17: Cleaning, Storage, & Battery Maintenance

    Do not wash your Flyer™ S533 with alcohol, gasoline, acetone, or other corrosive solvents. These substances may damage the appearance and internal structure of your Flyer™ S533. Do not wash your Flyer™ S533 with a power washer or hose.
  • Page 18: Maintenance & Troubleshooting

    Why does the battery life continue to get shorter over time? • Any changes to the Flyer™ eScooter that are not specifically approved by Radio Flyer Inc. could cause unsafe riding conditions and may void Reference maintenance information your warranty.
  • Page 19: Safety Guidelines

    IN ST RUCTIO NS AND SAFETY GUIDEL IN ES Before each use, conduct a basic safety inspection of the Flyer™ S533, including: (i) trueness of the wheels & condition of tires; (ii) safe operation of all brakes and lights; (iii) good condition of the frame; (iv) sufficient battery charge power;...
  • Page 20 • DO NOT ride or attempt to charge a vehicle that has been submerged in water or if there is risk of water intrusion into the battery compartment, even if the vehicle is no longer wet. Contact Radio Flyer for further instructions.
  • Page 21 F E DERA L COMMUNIC ATIO NS COMMISSI ON ( FCC) COM PLI A NCE STATEM ENT F OR USA This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 22 H ANDL EBA R HE ADL I G HT TUBE STO MP B R A KE LOC KI NG SL E EV E LEVER C HA RGI NG PO RT TA I L L I GH T K I C KSTA N D...
  • Page 24 Need help? We’ve got you covered. Visit flyer.radioflyer.com for product assistance and frequently asked questions. Radio Flyer Inc. 6515 West Grand Avenue Chicago, IL 60707 United States...
