CM5051-TV
ASSEMBLY RATING
Tools Required for Assembly
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Phillips Screwdriver
assembling a specific product (with 1 being
(Not Included)
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 4
Rev.14-10-14
Advertisement
Table of Contents
Related Manuals for Furniture of America CM5051-TV
Summary of Contents for Furniture of America CM5051-TV
- Page 1 Assembly Instructions CM5051-TV ASSEMBLY RATING Tools Required for Assembly The Assembly Rating is a 5-point system that shows the degree of effort needed in Phillips Screwdriver assembling a specific product (with 1 being (Not Included) easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 Page 2 of 4...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List #1 x 1 pc #A x 6 pcs TV Console Screw #2 x 1 pc Drawer Handle #3 x 2 pcs Door Handle...
- Page 4 The drawer handle (#2) is attached from the inside of the drawer as a protection against damage. Remove 2 screws (#A) to release the drawer handle (#2) and attach it to the outside of the drawer using the same screws (#A). #A x 2 pcs Turn right (clockwise) to tighten The door handles (#3) are attached from the inside of the...
