Two-Antenna Co-Locating Mount for Cisco 3802e APs
Ventev's Two-Antenna Co-Locating Mount is intended to mount a Cisco 3802e and two Strong Arm Mounts. The
Mount positions an access point (not included) horizontally in the center section of the bracket and two Strong
Arm Mounts (not included) on either side. Supports the 3802e when it is using its standard external antenna
ports along with the DART Connector/Jumper.
- Enables physical separation of the antennas for creation of Macro / Macro cell configurations in stadiums,
warehouses, and other industrial locations.
- Strong Arm Mounts (not included) hold TerraWave Directional Antennas.
- Note: Hardware to attach Co-Locating Mount to flush surface not included.
Every Ventev antenna is covered by the company's two-year TerraNet warranty program. For questions or to purchase
product, contact a Regional Sales Executive at 800-851-4965, sales@ventev.com or visit www.ventev.com/infra.
www.ventev.com/infra
SKU
Model
Dimensions (Inches)
Weight (lbs.)
Material
Opera ng Temperature
Compa ble Antenna Mounts
287936
220743
sales@ventev.com
Specifica ons
298415
TW‐BKT‐2ANT
14.75" x 9.375" x 5.125"
2 (Without AP or arms)
Powder Coated Aluminum
Nega ve 4° F to Posi ve 140° F
10" Strong Arm Mount
18" Strong Arm Mount
800-851-4965
