- Page 1 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Wood A Need help! 6P workstation Call us on 1300 527 665 Sizes: 1200, 1400, 1600, 1800 mm Tools Required: Power screwdriver; Allen key set (provided) 2 persons required for installation Page 1 of 8...
- Page 2 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Wood A Need help! 6P workstation Call us on 1300 527 665 Sizes: 1200, 1400, 1600, 1800 mm COMPONENTS Table top x6 Leg Quadro A x2 Connector frame x2 Beam x8 Plastic bracket x24 SCREWS M8x20MM CSK x12 M8x20MM Socket head x12 M6x20MM Socket head x24 M6x30MM Socket head x24...
- Page 3 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Wood A Need help! 6P workstation Call us on 1300 527 665 Sizes: 1200, 1400, 1600, 1800 mm STEP 01 STEP 02 Plastic bracket holes facing to the other side. You will notice two colored Both legs must have the colour Insert the bottom of the legs as shown in the stickers located on each leg.
- Page 4 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Wood A Need help! 6P workstation Call us on 1300 527 665 Sizes: 1200, 1400, 1600, 1800 mm STEP 04 STEP 03 Using Allen Key provided, attach 4 plastic brackets per leg (E) Using Allen Key provided, attach M8x20MM Socket head (G)- (as per picture above) using M6x20MM (H) Socket head screw.
- Page 5 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Wood A Need help! 6P workstation Call us on 1300 527 665 Sizes: 1200, 1400, 1600, 1800 mm STEP 05 Adjust extendable beam (D) to desired length using markers and secure beam at that length using screws provided 2000 1900 1800...
- Page 6 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Wood A Need help! 6P workstation Call us on 1300 527 665 Sizes: 1200, 1400, 1600, 1800 mm STEP 07 STEP 06 TOP VIEW Attach beam (D) to legs (B) and Connector frame (C) Frame looks like this. Using Allen Key, attach beam (D) with Socket (F) using nut insert in legs.
- Page 7 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Wood A Need help! 6P workstation Call us on 1300 527 665 Sizes: 1200, 1400, 1600, 1800 mm STEP 08 TABLE TOP BOTTOM VIEW Place desktops ontop of frame - with cutout at the back of the desk.
- Page 8 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Wood A Need help! 6P workstation Call us on 1300 527 665 Sizes: 1200, 1400, 1600, 1800 mm TABLE TOPS BOTTOM VIEW The following nut inserts should be used for this specific desk / workstation nut insert nut insert nut insert nut insert...
