ASSEMBLY INSTRUCTIONS
Elements Workstation
3 Person Run
Size: 1800mm
Tools Required: Power screwdriver.
Special Note: No pre-drilled holes or nut inserts are
provided. Wood screws will be required to be drilled
directly into underside of desk top.
2 persons required for installation
www.jasonl.com.au
Need help!
Call us on
1300 527 665
Page 1 of 5
