3.3 General Technical Data

MVS
SERIES
http://www.kontrolkalemi.com/forum/
Supply
Mains Supply Voltage
MVSxxxx-V02-xxx ........................................................ 3 x 2300 VAC (± 10%)
MVSxxxx-V03-xxx ........................................................ 3 x 3300 VAC (± 10%)
MVSxxxx-V04-xxx ........................................................ 3 x 4160 VAC (± 10%)
MVSxxxx-V06-xxx ........................................................ 3 x 6600 VAC (± 10%)
MVSxxxx-V07-xxx ...................................................... 3 x 7200 VAC (± 10%)
MVSxxxx-V11-xxx ..................................................... 3 x 11000 VAC (± 10%)
Control Supply Voltage
MVSxxx-xxx-C12 ................................ 110 VAC to 130 VAC (+ 10% / - 15%)
Supply Frequency .......................................................................... 45 Hz to 66 Hz
Rated Insulation Voltage
MVSxxxx-V02-xxx ........................................................................... 4200 VAC
MVSxxxx-V03-xxx ........................................................................... 4200 VAC
MVSxxxx-V04-xxx ........................................................................... 4200 VAC
MVSxxxx-V06-xxx ........................................................................... 6600 VAC
MVSxxxx-V07-xxx ........................................................................... 7200 VAC
MVSxxxx-V11-xxx ......................................................................... 11000 VAC
Rated Impulse Withstand Voltage (BIL)
MVSxxxx-V02-xxx .......................... 23300 VAC Cat III (1.2/ 50 µs at 2000 m)
MVSxxxx-V03-xxx .......................... 23300 VAC Cat III (1.2/ 50 µs at 2000 m)
MVSxxxx-V04-xxx .......................... 23300 VAC Cat III (1.2/ 50 µs at 2000 m)
MVSxxxx-V06-xxx .......................... 36700 VAC Cat III (1.2/ 50 µs at 2000 m)
MVSxxxx-V07-xxx .......................... 40000 VAC Cat III (1.2/ 50 µs at 2000 m)
MVSxxxx-V11-xxx ................................ xx VAC Cat III (1.2/ 50 µs at 2000 m)
Form Designation ......................... Bypassed semiconductor motor starter form 1
Control Inputs
Start (Terminals C23, C24) ..................................... Active 24 VDC, 8 mA approx
Stop (Terminals C31, C32) ..................................... Active 24 VDC, 8 mA approx
Reset (Terminals C41, C42) ................................... Active 24 VDC, 8 mA approx
Programmable Input A (Terminals C53, C54) ........ Active 24 VDC, 8 mA approx
Programmable Input B (Terminals C63, C64) ........ Active 24 VDC, 8 mA approx
Motor Thermistor (Terminals B4, B5)
Outputs
Relay Outputs ............................................................. 10 A @ 250 VAC / 360 VA
Main Contactor (Terminals 13, 14) ................................................ Normally Open
Bypass Contactor (Terminals 23, 24) ............................................. Normally Open
Run Output / PFC (Terminals 31, 32, 34) ............................................Changeover
Programmable Relay Output A (Terminals 43, 44) ....................... Normally Open
Programmable Relay Output B (Terminals 51, 52, 54) ...................... Changeover
Programmable Relay Output C (Terminals 61, 62, 64) ...................... Changeover
Analogue Output (Terminals B10, B11) .................................................. 4-20 mA
or 220 VAC to 240 VAC (+ 10% / - 15%)
7
SPECIFICATIONS
10 A @ 30 VDC resistive
