AuCom MVS Series Product Manual page 16

MVS
SERIES
http://www.kontrolkalemi.com/forum/
Diagram 3: Standard Power Circuit Configuration
MVS starter installation with main and bypass contactors.
K1M
CONTROL
SUPPLY
K2M
A1
L1 T1
T1B
L2 T2
T2B
L3 T3
E T3B
A2 A3
A1 C73
A2 C74
K2M
A3 13
14
23
24
34
31
RUN OUTPUT
(PFC)
32
15
POWER CIRCUITS
M
3
MOTOR
BYPASS CONTACTOR
FEEDBACK SIGNAL
K1M MAIN CONTACTOR
K2M BYPASS CONTACTOR
ITEM DESCRIPTION
A1 POWER ASSEMBLY
A2 CONTROL VOLTAGE TERMINAL BLOCK
A3 POWER INTERFACE PCB
K1M MAIN CONTACTOR
K2M BYPASS CONTACTOR
710-03261-00A
