Summary of Contents for dicodes Dani Box Micro
- Page 2 23mm and smaller. The outside dimensions of the box are about 23.2x36.7x75.6 mm. The Dani Box Micro is powered by one battery of size 18650 and can deliver a maximum power of 80Watts to the atomizer’s coil.
- Page 3 02 Feature List - 5 to 80W with one Li-Ion battery size 18650 - Atomizers with up to 23mm diameter - Adjustable battery discharge level (2.5-3V) - Up to 11V output voltage - Up to 22A output current - System source resistance determination - Temperature controlled vaping mode with various wire-types - Mechanical MOD mode (Bypass) with current limitation - 13 Power boost modes including a “dynamic”...
-
Page 4: Display Operation
03 Display Operation The mod is equipped with a graphical OLED display which provides all impor- tant information about the status during and for 4 seconds after each vape. Temperature controlled mode: Wattage setting. In Bypass mode Temperature during vape, it shows the actual power applied to the coil. - Page 5 05 Main Menu (Page 1) Switching On/Off, Key Locking and Menu-Operation The Dani Box Micro has three buttons: One bigger button as the fire and enter button below the stainless steel head-piece at the front side of the body and up/down buttons below the display-screen for navigating and changing values.
- Page 6 We therefore recommend to use other than Nickel coils, e.g. The NiFe30 (RESISTHERM) wire from dicodes. Also note, that when the device shows very high or very low temperatures the measured resistance deviates a lot from the stored calibration value.
- Page 7 The more current is drained, the higher the drop will be. The typical contact and wiring resistance of the Dani Box Micro sums up to about 6m . The Dani Box Micro always shows the voltage with and without current drained at the right corner in the bottom line of the screen (”V3.70/4.15”...
- Page 8 05 Main Menu (Page 4) Notes to Very High Power Vaping and Power Limitation When vaping at high power it is strongly recommended that only the best in class batteries are used and that all contacts are kept clean. Always keep in mind that 80W taken even from a high drain battery will create power losses in the batteries inner resistance as well as at all mechanical contacts, which finally will reduce the total vape time and lead to volt drop.
- Page 9 “TempCof”. The range for the coefficient is 050 to 650. If you use the dicodes wire (RESISTHERM) it is guaranteed that the wire will always have the same coefficient, because the wire was especially designed for temperature regulation purposes. The regulation accuracy is best then, as the combination of resistivity and high coefficient is very good.
- Page 10 Heater menu under “Bo Pwr”. Besides 12 selectable initial boost times, the Dani Box Micro has a new feature called dynamic boost: When “dyn” is selected for the boost time (”Bo Tim” in the Extended Functions /Heater menu) the selected boost power is applied to the coil, when the fire- and plus-button are pressed simultaneously.
- Page 11 The possible error messages are: 0 OvrVolt: The input voltage is too high. The Dani Box Micro operates with one battery. If the input voltage exceeds 4.5V this error message is displayed. Reduce the input voltage to the specified range.
- Page 12 (*1 ) The temperature coefficient selects the type of wire material in the range 050 to 650: When TC-mode is selected (Main menu HCtrl=1), the user must select the wire type to be NiFe30 (320, dicodes wire), Ni200 (620), Titanium (350), SS304 (105, V2A), SS316 (88), SS316L (92), NiFe48 (480) or “Other”. The value for “Other” is adjusted here.
- Page 13 “Power”. The power limitation makes sense especially in the power vaping mode to reduce the range to the used atomizer. All dicodes devices have a functionality to adjust the minimum discharge level of the battery between 2.5V and 3.0V (older models 3.5V). Almost all available batteries on the market specify the minmum discharge level of 2.5V to 2.7V.
- Page 14 Bypass mode. The Dani Box Micro can be used in 5 different modes. But in order to keep the menu as short and simple as possible, 3 of the 5 modes are only available, if the Expert-Mode is set to 1.
- Page 15 Dani Box Micro is a charge only port. The second option is to use the charging contact with the use of the CS1 charge station by dicodes. The charge current of the CS1 depends on the contact resistance between device and station is typically...
- Page 16 Use an adapter of USB-C to USB-A if your source has an USB-C output only. The second option is to use the charging contact with the use of the CS1 charge station by dicodes. The charge current of the CS1 depends on the contact resistance between device and station is typically 1A (2A maximum, limited by the CS1).
- Page 17 In case the device shows a permanent electric fail or if a software bug is detected, the user is free to send the device back to dicodes for repair without cost (shipping cost to dicodes in Germany is not covered by the warranty).
- Page 18 Friedrich der Große 70 44628 Herne Germany Phone: +49 2323 1463635 Email: info@dicodes-mods.de Web: www.dicodes-mods.de Errors excepted. Subject to technical or other changes without prior notice. c copyrights dicodes GmbH, Germany, no unauthorized reprint. Dec. 2021, dicodes DBMicro manual, ENG, revision 1...
