- Page 1 INSTALLATION AND USE MANUAL FAST FAST 01 2C ENGLISH MANUAL Installation and use manual model FAST 01 110/230 V rev. 22/08/2021 Page 1 of 20...
-
Page 2: Table Of Contents
WARNING! All UR FOG fogging systems should only be used with UR FOG-branded fluids. It is strictly forbidden to use any fluid not previously authorized in writing by UR FOG srl. SUMMARY Package contents page 2 Product presentation page 3... -
Page 3: Product Presentation
CONDITIONS OF USE AND WARNINGS The fog generated by UR Fog does not create particular problems or injuries for a human being for a short stay in a fogged room if the system is used according to the manufacturer’s recommendations. -
Page 4: Installations Tips To Install Fogging Systems
15. UR Fog continues to be effective for up to 2 hours and 30 minutes without 220V or 110V main power thanks to the insulation system which maintains the temperature in the heating system. -
Page 5: How To Activate The System
Inside it is possible to see the front part of the electronic circuit, from here on called PCB. It is recommended to install the fogging system Fast 01 2C vertically. If it is needed to install Fast 01 2C horizontally, it is necessary to order a special machine prepared for such installation and strictly follow the installation instructions. -
Page 6: Technical Specifications
TECHNICAL SPECIFICATIONS * Industrial standard as from other FAST 01 2C manufacturers Weight without tanks 22 Kg Max fog emitted in a single shot 1200 m Max fog emitted with full cylinders 2400 m Fog tanks capacity 2 x 600 ml... -
Page 7: Alcaline Batteries
- To replace them within the expiry date - to replace them every 12 months anyway - When Fast 01 2C report the signal of low battery (Paragraph 14-15) - Test the battery case during every maintenance (Paragraph 15) After inserting the batteries, it is important to check that they are in good contact with the battery case to guarantee the... -
Page 8: Description And Input And Output Connections
SHOOT shooting input Putting this input to positive, if Fast 01 2C is hot and armed, starts fog emission for the set time (see paragraph 11) In case of alarm, when opening ARM input, the fog emission stops immediately, even if the time set wasn’t reached. -
Page 9: Front Leds
When on: means that at least one cylinder is empty. See paragraph 13 ”Cylinders exchange and reset” GREEN LED When on: Fast 01 2C is hot and ready for fog emission. When flashing: means that the heating process is in progress. Fast 01 is not ready to shoot. -
Page 10: Shooting Time Setting
RECOMMENDED SHOOTING SECONDS ACCORDING TO THE VOLUME SPACE TO PROTECT (m Systems FAST 01 2C are able to produce fog for a maximum respectively 70 seconds per single shot. The maximum quantity of 10,7 ml/s allows to fill an area of about 1200 m . -
Page 11: Connection Example
Example of connection FAST 01 2C inputs with outputs of a central antitheft Example of connection of the FAST 01 2C outputs to drive LEDs and / or relays Example of connection of the FAST 01 2C outputs with inputs of an antitheft normally opened with diods needed only with some equipments. - Page 12 N.B. Ask for the PDF module writing to: support@urfog.com UR Fog S.r.l. Via Toscana 38 - 10099 San Mauro T.se (Torino) - Italy...
