Installation, Operation,
and Maintenance
ProSpace
™ ™
Packaged Terminal Air Conditioner (PTAC)
Models PTEF and PTHF
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and
air-conditioning equipment can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered
equipment by an unqualified person could result in death or serious injury. When working on the equipment, observe all precautions in the
literature and on the tags, stickers, and labels that are attached to the equipment.
November 2015
S S A A F F E E T T Y Y W W A A R R N N I I N N G G
PTAC-SVX002A-EN

Advertisement

Table of Contents
loading

Summary of Contents for Trane ProSpace PTEF

  • Page 1 Installation, Operation, and Maintenance ProSpace ™ ™ Packaged Terminal Air Conditioner (PTAC) Models PTEF and PTHF S S A A F F E E T T Y Y W W A A R R N N I I N N G G Only qualified personnel should install and service the equipment.
  • Page 2 Practices The ProSpace™ Packaged Terminal Air Conditioners and heat pumps provide a high standard of quality in Trane believes that responsible refrigerant practices are performance, workmanship, durability and appearance important to the environment, our customers, and the as they heat and cool the occupied air space year air conditioning industry.
  • Page 3 Do not insert or place fingers or objects into the air This document and the information in it are the discharge area in the unit. property of Trane, and may not be used or reproduced in whole or in part without written permission. Trane PTAC-SVX002A-EN...
  • Page 4 Trademarks reserves the right to revise this publication at any time, and to make changes to its content without obligation All trademarks referenced in this document are the to notify any person of such revision or change. trademarks of their respective owners. PTAC-SVX002A-EN...
  • Page 5: Table Of Contents

    Trane Wall Sleeve and Grille ........
  • Page 6 T T a a b b l l e e o o f f C C o o n n t t e e n n t t s s Front Panel and Case ................27 Outdoor Coil .
  • Page 7: Model Number Description

    Model Number Description Use the following to determine the correct model number. T E F 070 2 G AA Digit 1,2 Digit 3 Digit 4 Digit 5-7 Digit 8 Digit 9 Digit 10,11 • D D i i g g i i t t 1 1 , , 2 2 ; ; P P r r o o d d u u c c t t F F a a m m i i l l y y –...
  • Page 8: Unit Features

    Unit Features This unit has many features that are different from those found on standard PTAC models. The owner should become familiar with these features in order to fully understand the operation and capabilities of the unit: Intelligence The unit has an on board computer which utilizes real-time diagnostics to prolong the life of the unit.
  • Page 9: Dual-8 Display And Led Display

    U U n n i i t t F F e e a a t t u u r r e e s s Dual–8 display and LED Display The ProSpace has two (2) 8-segment nixie tubes and the following 13 LED indicators: •...
  • Page 10 U U n n i i t t F F e e a a t t u u r r e e s s • Energy Management (also referred to as Front Desk Control); an input is provided so that the unit can be manually disabled from a different location.
  • Page 11: Electrical

    Electrical W W A A R R N N I I N N G G L L i i v v e e E E l l e e c c t t r r i i c c a a l l C C o o m m p p o o n n e e n n t t s s ! ! F F a a i i l l u u r r e e t t o o f f o o l l l l o o w w a a l l l l e e l l e e c c t t r r i i c c a a l l s s a a f f e e t t y y p p r r e e c c a a u u t t i i o o n n s s w w h h e e n n e e x x p p o o s s e e d d t t o o l l i i v v e e e e l l e e c c t t r r i i c c a a l l c c o o m m p p o o n n e e n n t t s s c c o o u u l l d d r r e e s s u u l l t t i i n n d d e e a a t t h h o o r r s s e e r r i i o o u u s s i i n n j j u u r r y y .
  • Page 12: Voltage Supply

    E E l l e e c c t t r r i i c c a a l l Voltage Supply Check voltage supply at outlet. For satisfactory results, the voltage range must always be within the ranges specified on the data information plate. Power cord does not ship with the unit. The cord to order is determined by the unit voltage and the desired electric heat capacity.
  • Page 13: Installation

    . . In applications when the unit is a replacement, it is recommended to use a Trane sleeve. This unit can be retrofitted to other manufacturers similar sleeves if outdoor unit airflow is not restricted or recirculated.
  • Page 14 I I n n s s t t a a l l l l a a t t i i o o n n I I m m p p o o r r t t a a n n t t : : Inspect the wall sleeve thoroughly prior to installation. The manufacturer does not assume responsibility for costs or damage due to defects in the sleeve or for improper installation.
  • Page 15: Installing The Chassis Into Wall Sleeve

    I I n n s s t t a a l l l l a a t t i i o o n n Installing the Chassis Into Wall Sleeve N N O O T T I I C C E E E E q q u u i i p p m m e e n n t t D D a a m m a a g g e e ! ! U U s s e e s s p p r r e e a a d d e e r r b b a a r r s s t t o o p p r r e e v v e e n n t t s s t t r r a a p p s s f f r r o o m m d d a a m m a a g g i i n n g g t t h h e e u u n n i i t t .
  • Page 16 I I n n s s t t a a l l l l a a t t i i o o n n Lift unit level and slide unit into wall sleeve until foam seal rests firmly against front of wall sleeve. Secure with four screws (supplied) through the unit flange holes.
  • Page 17: System Configuration

    System Configuration Adjusting Air Direction- Only for Duct Installations Remove front panel. Remove louver screws that hold the louver insert in place on the back side of the front panel. Turn louver insert and rotate it 180°. Replace louver insert. Replace screws and the front panel.
  • Page 18: Dip Switches

    S S y y s s t t e e m m C C o o n n f f i i g g u u r r a a t t i i o o n n Dip Switches The auxiliary dip switch controls are located behind the front panel and through an opening below the control panel.
  • Page 19: Keypad Configuration

    Keypad Configuration The Trane ProSpace can be customized by configuring the keypad. 1. To enter the keypad configuration screen, first power up the unit. 2. Within the 30 seconds after power-up press and hold both the f f a a n n s s p p e e e e d d + + buttons for five (5) seconds.
  • Page 20 S S y y s s t t e e m m C C o o n n f f i i g g u u r r a a t t i i o o n n seconds before displaying the room temperature. 6.
  • Page 21: Auxillary Controls

    Auxillary Controls Wiring the Wall Thermostat W W A A R R N N I I N N G G L L i i v v e e E E l l e e c c t t r r i i c c a a l l C C o o m m p p o o n n e e n n t t s s ! ! F F a a i i l l u u r r e e t t o o f f o o l l l l o o w w a a l l l l e e l l e e c c t t r r i i c c a a l l s s a a f f e e t t y y p p r r e e c c a a u u t t i i o o n n s s w w h h e e n n e e x x p p o o s s e e d d t t o o l l i i v v e e e e l l e e c c t t r r i i c c a a l l c c o o m m p p o o n n e e n n t t s s c c o o u u l l d d r r e e s s u u l l t t i i n n d d e e a a t t h h o o r r s s e e r r i i o o u u s s i i n n j j u u r r y y .
  • Page 22 A A u u x x i i l l l l a a r r y y C C o o n n t t r r o o l l s s 3. Remove the terminal connector to simplify wiring. 4.
  • Page 23: Energy Management Input (Front Desk Control)

    A A u u x x i i l l l l a a r r y y C C o o n n t t r r o o l l s s Energy Management Input (Front Desk Control) The controller can handle a switch signal from remote energy management input, called an EM signal or front desk control.
  • Page 24: Operation

    The following sections describe the operation of the Trane ProSpace unit. Control Buttons and Functions The section describes the buttons and functionality of the Trane ProSpace unit. • O O N N / / O O F F F F ; turns the unit ON or OFF .
  • Page 25 O O p p e e r r a a t t i i o o n n UT O SW ING C OOL F OPER SLEEP L OC K A UT O FA N SPEED HEA T ON / OFF MODE SWING SLEEP...
  • Page 26 O O p p e e r r a a t t i i o o n n setting and the T-ON or H characters do not display. When the temperature display becomes constant, press this key again to display the remaining set time. The time values, T-ON and H, display constantly for 2 seconds.
  • Page 27: Care And Cleaning

    Care and Cleaning Periodic care and cleaning of the ProSpace unit is essential to keep it running efficiently. Front Panel and Case Turn unit off and disconnect power supply. To clean, use a soft brush, water, and a mild detergent. D D O O N N O O T T use bleach or abrasives. Some commercial cleaners may damage the plastic parts.
  • Page 28 C C a a r r e e a a n n d d C C l l e e a a n n i i n n g g Use the following checklist to ensure proper care of the ProSpace unit. Equipment operation should be checked and verified several times during each year.
  • Page 29 Troubleshooting Issue Possible Causes Resolution Unit does not • Unit may have become unplugged. • Ensure that the plug is securely in the wall start. receptacle. • Fuse may be blown. • Replace the fuse. • Circuit breaker may be tripped. •...
  • Page 30 T T r r o o u u b b l l e e s s h h o o o o t t i i n n g g Issue Possible Causes Resolution Ice or frost • Low outdoor temperature. •...
  • Page 31 N N o o t t e e s s PTAC-SVX002A-EN...
  • Page 32 HVAC systems, comprehensive building services, and parts. For more information, visit www.Trane.com. Trane has a policy of continuous product and product data improvements and reserves the right to change design and specifications without notice. ©2015 Trane All rights reserved...
