DRIVEWAY WAND SENSOR
Automatically activates gate operators "Hands-Free" when
a vehicle approaches. Designed for residential, agricultural,
and commercial applications.
Easy to install. Avoid the headaches associated with installing
exit and entry loop detector systems, installs in 1/3 the time.
Driveway Wand Sensor
Direct burial wire lengths:
(FM139) 50 ft. (15.3 m)
(FM140) 100 ft. (30.5 m)
(FM141) 150 ft. (45.7 m)
(FM141-250) 250 ft. (76.2 m)
(FM141-500) 500 ft. (152.4 m)
(FM141-1000) 1000 ft. (304.8 m)
AVAILABLE FROM:
GTO®, GTO/PRO®, Bulldog®, are registered trademarks of GTO, Inc. Professional Access Systems™ , is a trademark of GTO, Inc. and are the exclusive property of GTO, Inc. ("GTO").
PROFESSIONAL
ACCESS CONTROLS
• Electromagnetic sensor detects vehicles-in-motion.
• Relay latch time of 2 seconds.
• Compatible with all automatic gate operators, or
other systems requiring a dry contact input device.
• Potentiometer board adjusts sensitivity from 3 to 12
foot radius to accommodate many applications
and situations.
• Ideal for solar application, 1.5 mA current consumption.
• Wide input voltage range (8-32 vAC or 8-26 vDC).
• Designed to reject line noise of 50Hz or 60Hz;
improves detection capability near power lines and
avoids crosstalk frequency issues.
• Dimensions: 1.75" (44.5 mm) diameter x 16.75"
(425.4mm) long.
• May not be used as a safety device.
• No drive over loads to get damaged or fail, common
with loop detector systems.
1-800-543-GATE (4283) • www.gtopro.com
All rights are reserved by GTO, and these marks may not be used, in any for without the prior, written permission of GTO. Copyright 2007 rev-02-2007
STANDARD FEATURES
Driveway Wand Sensor
Control Board
