- Page 1 G3-MSFT3-02 & G3-MSFT4-02 Service Manual...
-
Page 3: Table Of Contents
Contents CHAPTER 1: SERIAL NUMBER LOCATION ....................4 CHAPTER 2: ASSEMBLY INSTRUCTION ....................5 CHAPTER 3: TROUBLESHOOTING 3.1 Troubleshooting-Cable Issues ......................8 3.2 Troubleshooting-Weight Stake Pin Issue ................... 9 3.2 Troubleshooting-Pull Pin issues ...................... 10 CHAPTER 4: PART REPLACEMENT GUIDE 4.1 Hand Grip Foam Replacement ...................... -
Page 4: Chapter 1: Serial Number Location
CHAPTER 1: Serial Number Location 1.1 Serial Number Location The serial number is located at the bottom of the weight stack frame. -
Page 5: Chapter 2: Assembly Instruction
2.1 G3-MSFT-02&G3-MSFT4-02 ASSEMBLY INSTRUCTION UNPACKING G3-MSFT 300lbs/400lbs Multi-Station Functional Trainer Thank you for purchasing a MATRIX Fitness product. It is inspected before it is packaged. It is shipped in multiple pieces to facilitate the compact packaging of the machine. Prior to assembly, confirm all the components by matching them withthe exploded diagrams. - Page 6 CHAPTER 2: Assembly Instruction 2.2 G3-MSFT-02&G3-MSFT4-02 ASSEMBLY INSTRUCTION CONTINUED...
- Page 7 CHAPTER 2: Assembly Instruction 2.2 G3-MSFT-02&G3-MSFT4-02 ASSEMBLY INSTRUCTION CONTINUED...
-
Page 8: Chapter 3: Troubleshooting
CHAPTER 3: Troubleshooting 3.1 TROUBLESHOOTING-CABLE ISSUES CABLE LOOSE 1) SYMPTOM: The fix bolts are loosed. 2) SOLUTION: Undo the former fixing nut , then the cable screw should be adjust fronted.(Figure A & B). b. Lock the fixing nut (Figure C). Figure A Figure B Figure C... -
Page 9: Troubleshooting-Weight Stake Pin Issue
CHAPTER 3: Troubleshooting 3.2 TROUBLESHOOTING-WEIGHT STACK PIN ISSUES WEIGHT STACK PIN ISSUES 1) SYMPTOM: The weight stack pin is bent. The cable is attached too loosely or too tightly. The weight plates are not seated correctly at the bottom of the guide rods. The top weight plate bushings are damaged. -
Page 10: Troubleshooting-Pull Pin Issues
CHAPTER 3: Troubleshooting 3.3 TROUBLESHOOTING-PULL PINS ISSUE PULL PINS ISSUE 1) SYMPTOM: The pins are rubbing on the frame creating friction. 2) SOLUTION: a. Remove the affected pin, add grease (Matrix recommends SuperLube brand grease with PTFE) and then re-install the pin... -
Page 11: Chapter 4: Part Replacement Guide
CHAPTER 4: Part Replacement Guide 4.1 HAND GRIP FOAM REPLACEMENT 1) To loose the screws of end cap of handlebar (Figure A). To take off the end cap and cut off the original foam (Figure B). Using tape to seal up the handlebar tube to avoid the oil or suds into the tube (Figure C). To bent and hold the end of foam then put oil or suds into the inside of foam (Figure D). -
Page 12: Pedal Grip Adjustment Handle Replacement
CHAPTER 4: Part Replacement Guide 4.2 PEDAL GRIP ADJUSTMENT HANDLE REPLACEMENT 1) Loose 4 bolts and take out the grip. (Figure A). 2) Replace Grip and fix the 4 bolts (Figure B). Figure A Figure B... -
Page 13: Adjustment Grip Replacement
CHAPTER 4: Part Replacement Guide 4.3 ADJUSTMENT GRIP REPLACEMENT 1) Loose the stopper bolts and take out the grip.(Figure A). Replace Grip and fix the 2 bolts (Figure B). Figure A Figure B... -
Page 14: Climbing Hold Replacement
CHAPTER 4: Part Replacement Guide 4.4 CLIMBING HOLD REPLACEMENT 1) Use a 17MM Open-Ended Wrench And 8MM L-Shaped Allen Wrench to take off the old adjustment pin set (Figure A). Install a new Climbing Hold(Figure B). Figure A Figure B...
