- Page 1 G3-MS24 G3-MS52 G3-MS20 G3-MS50 AUR A SERIES G3-MS51 G3-MS53 G3-MS40 G3-MS80...
- Page 3 4. Ensure that any person(s) making adjustments or performing maintenance or 11. Adjustable stops, where provided, must be used repair of any kind is qualified to do so. MATRIX dealers will provide service and at all times. 12. When adjusting any adjustable mechanism (stop maintenance training at our corporate facility upon request.
- Page 4 2 x 295 lbs. 4 x 295 lbs. * Ensure a minimum clearance width of 0.6 meters (24”) for access to and passage around MATRIX strength equipment. Please note, 0.91 meters (36”) is the ADA recommended clearance width for individuals in wheelchairs.
- Page 5 UNPACKING CAUTION Thank you for purchasing a MATRIX Fitness product. It is inspected before it is To avoid injury to yourself and prevent damage to the frame components, be sure packaged. It is shipped in multiple pieces to facilitate the compact packaging of the to have proper assistance removing the frame pieces from this box.
- Page 6 Overall Dimensions (L x W x H)* 68 x 70 x 240 cm / 27” x 28” x 94.5” * Ensure a minimum clearance width of 914 mm / 36” for access to and passage around MATRIX strength equipment. Adjustable...
- Page 7 G3-MS24 Item Description Screw, Oval-Hex Socket (M10x100L) Arc-flat Washer Nylon Nut (M10) K19x2 Screw, Oval-Hex Socket (M12x25L) Z12x2 Flat Washer (M12) Z11x2 Screw, Oval-Hex Socket (M6x45L) Nylon Nut (M6) Rubber Stack Cushions Z20x8 Screw, Oval-Hex Socket (M8x30L) K19x8 Sticker, Weight Stack Plate Pulley (115mm) Z21x8 Pulley (90 mm)
- Page 8 Overall Dimensions (L x W x H)* 126 x 120 x 252 cm / 50” x 47.5” x 99.5” * Ensure a minimum clearance width of 914 mm / 36” for access to and passage around MATRIX strength equipment. MS51...
- Page 9 G3-MS51 F23 F06 Item Description Screw, Round-Hex Socket (M8x30L) Screw, Round-Hex Socket (M10x100L) Flat Washer (M10) Nylon Nut (M10) Screw, Round-Hex Socket (M10x80L) Screw, Round-Hex Socket (M10x25L) Arc-flat Washer Screw, Round-Hex Socket (M12x25L) Flat Washer (M12) Lock Washer (M12) Screw, Round-Hex Socket (M6x45L) Nylon Nut (M6) Screw, Oval-Hex Socket (M10x35L) Rubber Stack Cushions...
- Page 10 Overall Dimensions (L x W x H)* 85 x 59 x 240 cm / 33.5” x 23.5” x 94.5” * Ensure a minimum clearance width of 914 mm / 36” for access to and passage around MATRIX strength equipment. Triceps...
- Page 11 G3-MS52 Z09 Z07 Item Description Screw, Oval-Hex Socket (M8x30L) Screw, Oval-Hex Socket (M10x35L) Screw, Oval-Hex Socket (M6x45L) Nylon Nut (M10) Arc-flat Washer Screw, Oval-Hex Socket (M10x90L) Nylon Nut (M10) Rubber Stack Cushions Sticker, Weight Stack Plate Pulley Cable Bolt, hex-head...
- Page 12 Overall Dimensions (L x W x H)* 230 x 71 x 240 cm / 91” x 28” x 94.5” * Ensure a minimum clearance width of 914 mm / 36” for access to and passage around MATRIX strength equipment. MS53...
- Page 13 G3-MS53 Item Description Screw, Oval-Hex Socket (M8x30L) Screw, Oval-Hex Socket (M10x35L) Screw, Oval-Hex Socket (M6x25L) Nylon Nut (M6) Hooker Screw, Oval-Hex Socket (M8x70L) Nylon Nut (M8) Nylon Nut (M10) Screw, Oval-Hex Socket (M10x25L) Flat Washer (M10) Handlebar Holder Screw, Oval-Hex Socket (M10x80L) Rubber Stack Cushions Arc-flat Washer Sticker, Weight Stack Plate...
- Page 14 4 Stack G3-MS40 Sample Configuration Lat Pull Adjustable Pulley G3-MS51 G3-MS24 Frame Detail Item Description Flat Washer (M8) Tricep G3-MS52 Screw, Round-HS(M8x30L) Low Row G3-MS53...
- Page 15 5 Stack - Step 1 of 3 G3-MS50 Sample Configuration Lat Pull Adjustable Pulley G3-MS51 G3-MS24 Frame Detail Item Description Flat Washer (M8) Tricep G3-MS52 Screw, Round-HS(M8x30L) Low Row G3-MS53...
- Page 16 5 Stack - Step 2 of 3 G3-MS50 Sample Configuration Frame Detail Item Description Flat Washer (M8) Screw, Oval-HS(M10x100L) Nylon Nut (M10) Flat Washer (M10) Screw, Round-HS(M10x80L) Screw, Round-HS(M10x25L) Screw, Oval-HS(M8x25L) Adjustabel Pulley Right Arc Washer G3-MS24...
- Page 17 5 Stack - Step 3 of 3 G3-MS50 Sample Configuration Inner shrouds present outside of North America only. Accessory Detail Item Description Rubber Tip Weight Shield Bolt 24 Rubber Shield...
- Page 18 8 Stack - Step 1 of 3 G3-MS80 Sample Configuration Lat Pull Adjustable Pulley G3-MS51 G3-MS24 Frame Detail Item Description Flat Washer (M8) Tricep G3-MS52 Screw, Round-HS(M8x30L) Low Row G3-MS53...
- Page 19 8 Stack - Step 2 of 3 G3-MS80 Sample Configuration Frame Detail Item Description Nylon Nut (M10) Flat Washer (M10) Screw, Round-HS (M10x80L) Screw, Round-HS (M10x25L) Arc-flat Washer...
- Page 20 8 Stack - Step 3 of 3 G3-MS80 Sample Configuration Inner shrouds present outside of North America only. Accessory Detail Item Description Rubber Tip Weight Shield Bolt 16 Rubber Shield...
- Page 24 G3-MS24 / G3-MS51 / G3-MS52 / G3-MS53 / G3-MS20 / G3-MS40 / G3-MS50 / G3-MS80 Part # XXXXXXXXXX © 2015 Johnson Health Tech Rev 1.3...
