Getting Started

This section provides a brief introduction of ESP32-C3-DevKitM-1, instructions on how
to do the initial hardware setup and how to flash firmware onto it.

Description of Components

Key Component
ESP32-C3-MINI-
1
5 V to 3.3 V
LDO
5 V Power On
LED
ESP32-C3-DevKitM-1 - front
ESP32-C3-MINI-1 is a general-purpose Wi-Fi and Bluetooth LE
combo module that comes with a PCB antenna. At the core of this
module is ESP32-C3FN4, a chip that has an embedded flash of 4
MB. Since flash is packaged in the ESP32-C3FN4 chip, rather than
integrated into the module, ESP32-C3-MINI-1 has a smaller package
size.
Power regulator that converts a 5 V supply into a 3.3 V output.
Turns on when the USB power is connected to the board.
Description
