5. Camera Connection:
 All cameras will be connected with the green wire. It can provide 12V/3A which is sufficient to supply
Connect RCA accordingly
*NOTE: Ground for the camera power should not be connected or noise may be seen on the display.
6. Interface DIP Settings:
DIP Down= ON
DIP ON
1 Front camera (Video1) installed
2 Left camera (Video2) installed
3 Right camera (Video3) installed
4 BSV mode
5 Reverse camera installed
(When R engaged aftermarket
camera (V4) shown)
6,7 No function
8 7"/8" screen selected e.g. SRX
power for the 3 or 4 cameras.
Power
DIP UP= OFF
Front camera (Video1) not
Left camera (Video2) not
Right camera (Video3) not
Video Mode
OE camera is installed
(When R engaged OE camera
10" screen selected e.g. CT6
OFF
DOWN(ON)
installed
DOWN(ON)
installed
DOWN(ON)
installed
UP(OFF)
DOWN(ON)
shown)
No function UP(OFF)
UP(OFF)
Default
