- Page 1 CEBORA S.p.A. POWER SPOT 5500 POWER SOURCE art. 2153 SERVICE MANUAL 3.302.164 13/05/04...
-
Page 2: Table Of Contents
CEBORA S.p.A. CONTENTS - GENERAL INFORMATION.......................... 3 - Introduction..............................3 - General service policy..........................3 - Safety information............................3 - Electromagnetic compatibility........................3 - SYSTEM DESCRIPTION ..........................4 - Introduction..............................4 - Technical specifications..........................4 - Description of power source art. 2153......................4 - MAINTENANCE............................ -
Page 3: General Information
It is forbidden to attempt to repair damaged electronic boards or modules; replace them with original Cebora spare parts. 1.3 - Safety information. The safety notes provided in this manual are an integral part of those given in the Instruction Manual. -
Page 4: System Description
2 - SYSTEM DESCRIPTION 2.1 - Introduction. The POWER SPOT 5500 is a system for welding ferrous and non-ferrous threaded stud bolts or rivets, on various types of sheet metal. It is made up of an electronic power source (art. 2153), and a set of accessories to adapt to various applications and tasks (see Sales Catalogue). - Page 5 CEBORA S.p.A. reached. Normally the programmed voltage that appears upon start-up matches the voltage used the last time welding was performed. This voltage may be changed using the keys on the control panel. If the accessory (gun) connected to the connector (H) changes, the programmed voltage becomes the standard voltage for the connected accessory.
-
Page 6: Maintenance
CEBORA S.p.A. 3 - MAINTENANCE WARNINGS ANY INTERNAL INSPECTIONS OR REPAIRS MUST BE CARRIED OUT BY QUALIFIED PERSONNEL. BEFORE BEGINNING MAINTENANCE OPERATIONS, UNPLUG THE MACHINE FROM THE MAINS AND WAIT FOR THE INTERNAL CAPACITORS TO DISCHARGE. MEASURE THE VOLTAGE ON THE DC-CAPACITORS (24) EVERY TIME YOU... -
Page 7: Starting The Power Source
CEBORA S.p.A. NOTE Operations preceded by this symbol refer to operator actions. ♦ Operations preceded by this symbol refer to machine responses that must occur following an operator action. 3.2.2 - Starting the power source. System shut off and unplugged from the mains. - Page 8 CEBORA S.p.A. Use the (A) or (B) keys to set a voltage on display (E) suitable for the welding to be done. Insert a rivet in the mandrel of the gun and press the tip of the rivet against the surface of the sheet metal to which it is to be welded;...
-
Page 9: Troubleshooting
CEBORA S.p.A. 3.3 - Troubleshooting. WARNINGS ANY INTERNAL INSPECTIONS OR REPAIRS MUST BE CARRIED OUT BY QUALIFIED PERSONNEL. BEFORE BEGINNING MAINTENANCE OPERATIONS, UNPLUG THE MACHINE FROM THE MAINS AND WAIT FOR THE INTERNAL CAPACITORS TO DISCHARGE. MEASURE THE VOLTAGE ON THE DC-CAPACITORS (24) EVERY TIME YOU... - Page 10 CEBORA S.p.A. SERVICES POWER SUPPLY TEST. Power board (12), rectifier bridge W1, negative terminal (-) and diode D2 cathode (+) = +25 Vdc, with switch (21) closed and mains voltage 230 Vac. Correct? ♦ Check the wiring between CN3 of power board (12) and transformer (31).
-
Page 11: Power Source Powered, Fan (34) Stopped
CEBORA S.p.A. 3.3.2 - Power source powered, fan (34) stopped. FAN TEST. Fast-on terminals fan (34) = 115 Vac (with mains 115 or 230 Vac). Correct? ♦ Make sure that there are no mechanical impediments blocking the fan. ♦ Replace the fan (34). -
Page 12: In Open Circuit Operation, The Voltage At The Dc-Capacitors (24) Is Not Regular
CEBORA S.p.A. 3.3.4 - In open circuit operation, the voltage at the DC-capacitors (24) is not regular. NOTE To check the open circuit operation of the power source, you must measure the output voltage directly on the DC-capacitors (24), since the output terminals (F) and (G) of the power source are connected to this potential only at the moment of welding. -
Page 13: In Resistive Load Operation, The Output Voltage Is Not Regular
CEBORA S.p.A. 3.3.5 - In resistive load operation, the output voltage is not regular. NOTE For the following test use a resistive load capable of circulating a current greater than 100 Adc, at a maximum voltage of 210 Vdc (for example 0.5 ohm). -
Page 14: In Actual Working Conditions (Thus With High Currents), The Welding Quality Is Not Satisfactory
CEBORA S.p.A. 3.3.6 - In actual working conditions (thus with high currents), the welding quality is not satisfactory. In actual working conditions, thus with high currents, the welding quality may not be satisfactory even if the “no-load operating test” par. 3.3.4 and “resistive load operating test” par. -
Page 15: Error Codes
CEBORA S.p.A. 3.4 - Error codes. 3.4.1 - E1 - Transformer (31) temperature above limits. The power source delivers no current, but the fan continues running; we therefore recommend leaving the power source powered to ensure rapid cooling. This is reset automatically when the temperature returns within the allowed limits. -
Page 16: Components List
CEBORA S.p.A. 4 - COMPONENTS LIST 4.1 - Power source art. 2153: see file ESP2153.pdf enclosed at the end of the manual. 4.2 - Components table: see file ESP2153.pdf enclosed at the end of the manual. 4.3 - List of spare parts. -
Page 17: Power Board (12) Code 5.602.169
CEBORA S.p.A. 5.3 - Power board (12) code 5.602.169. 5.3.1 - Topographical drawing. 5.3.2 - Connector table. Connector Terminals Function input earth connection. 2 - 3 mains power supply input (115 / 230 Vac). 1(+) – 2(-) scr (3) gate command output. -
Page 18: Control Board (2) Code 5.602.168
CEBORA S.p.A. 5.4 - Control board (2) code 5.602.168. 5.4.1 - Topographical drawing. 5.4.2 - Connector table. Connector Terminals Function shared input for signals from outside. temperature signal input from thermostat on transformer (31). start signal input from gun button. - Page 20 DESCRIZIONE DESCRIPTION DESCRIZIONE DESCRIPTION CORNICE FRAME 100 IMPUGNATURA HANDGRIP 102 ANELLO POSTERIORE BACK RING CIRCUITO PANNELLO PANEL CIRCUIT GRUPPO SCR SCR UNIT 103 REGOLAZIONE MOLLA SPRING ADJUSTMENT FASCIONE HOUSING 104 INDICE DI REGOLAZIONE REGULATION POINTER DIODO SKN SKN DIODE 105 MOLLA SPRING IMANICO HANDLE...
