- Page 1 USER MANUAL Multifunctional Dashcam CL586 004C1A09-EN...
-
Page 2: Table Of Contents
CONTENT 1. DISCLAIMER AND SAFETY GUIDELINES 1.1 Disclaimer 1.2 Safety Guidelines 2. ACCESSORIES AND INTERFACES 2.1 In the box 2.2 Product Diagram 2.3 Installation Guideline 2.4 Interfaces Introduction 3. FUNCTIONS AND SETTINGS 3.1 General Settings 3.2 Carlink and its settings 3.3 Recorder and its settings 3.4 FM and its settings 3.5 Playback and its settings... -
Page 3: Disclaimer And Safety Guidelines
Spedal is not responsible for all losses caused by the user's failure to use the product in accordance with this User Manual. -
Page 4: Safety Guidelines
1.2 Safety Guidelines Warnings ● Please use the original cable and power cords only; ● Do not exceed the rated voltage when using the device; ● Do not install or operate the device with wet hands; ● Do not install the device in places of high temperature, humidity; ●... -
Page 5: Accessories And Interfaces
● Quick Guide (Gift) Notice: Please use the SPEDAL original cable and accessories only. Gifts and accessories are not covered by the warranty. The content of this product package is subject to change without notice, the actual package shall prevail! -
Page 6: Product Diagram
2.2 Product Diagram AV-IN USB / Warning: When the function Carlink is activated, the projection chip and the drive recording chip will work at the same time. The surface temperature of the heat-dissipating metal sheet can reach as high as 60℃, which is within normal range of working temperature. Please do not touch the sheet surface for a long while to prevent being scalded. -
Page 7: Installation Guideline
2.3 Installation Guideline The device is in the storage state when it leaves the factory. Please follow the steps below to prepare for installation: 1. Take the device and its accessories out of the box or plastic bag; 2. Tear off the protective film on the screen and lens of the device; 3. - Page 8 TF Card Installation Install the TF card in the TF socket with the pins facing upwards. Push the Micro SD card forward, and the card can be removed after it pops out. Please use the 32GB TF card that comes with the product. A third-party TF card should meet these requirements: Class 8 or above, maximal 128GB.
- Page 9 Installation Method 1. Aim the magnetic transfer slide buckle at the mount buckle on the device. 2. Hold the device and chuck bracket with your hands, and aim the mount at the chuck bracket on the device. 3. Select a proper position (such as the center of the rearview mirror), attach the suction mound to the windshield and rotate the mount clockwise to lock.
-
Page 10: Interfaces Introduction
2.4 Interfaces Introduction Main Interface When you connect the device to the vehicle via the in-vehicle charging cable, the device powers on after the vehicle starts. If you want to connect the device to the power in any other way, press and hold the power button to turn it on. The screen after turning on the device is as follows. -
Page 11: Functions And Settings
3. FUNCTIONS AND SETTINGS 3.1 General Settings Click “Settings” on the main interface to enter “General Settings”. Screen Saver 12:00 Clock Settings 08-08 Sun. Resolution Video Duration Protect Level Click to return to the main interface. Scroll to see all subcategories. Subcategory Option Introduction... - Page 12 Subcategory Option Introduction Keyboard Off / On Default is On. Feedback sound of clicking. clicks Volume 0-10 Default is 5. Volume of the device. English, Deutsch, 简体中 Language System language. ⽂，繁体中⽂，⽇ 本語 Firmware View the firmware version. Version Flicker 50Hz / 60Hz Default is 50Hz.
-
Page 13: Carlink And Its Settings
2 Keep the WIFI option on your mobile phone “ON”; 3 Find the device WIFI “Spedal-XXXX” on your mobile; 4 Enter the WIFI password to connect to the wifi; 5 Open the “Projection” or “Screen Mirroring” on your mobile phone;... -
Page 14: Recorder And Its Settings
3.3 Recorder and its settings Click “Recorder” on the main interface to enter the dashcam interface. 1080P 2020-05-16 07:03:21 00:00:00 Note: 1. You can change resolution and time in Settings. 2. The audio recording status has two status: ON/OFF. You can switch the status by clicking on the “Audio recording”... -
Page 15: Fm And Its Settings
3.4 FM and its settings Before using this function, please ensure at first that your mobile phone has been connected to the dashcam through Carlink(refer to 3.2 Carlink and its settings) and screen and sound synchronization have begun properly. FM transmitter technology allows you to launch specific FM frequency (please make sure that this frequency is not occupied by any radio or broadcast) from the dashcam. -
Page 16: Playback And Its Settings
3.5 Playback and its settings Playback Interface 01/13 FILE200516-083422-000103F.TS FILE200516-083321-000102F.TS FILE200516-083221-000101F.TS FILE200516-083121-000100F.TS FILE200516-083021-000099F.TS FILE200516-082920-000098F.TS FILE200516-082820-000097F.TS FILE200516-082720-000096F.TS Expanded File 21/25 00:00:00 / 00:01:00 FILE200516-075517-000059F.TS 2021/05/16 07:56:13... -
Page 17: Appendix
-30℃ ~75℃ 4.2 Warranty Thank you for purchasing the Spedal multifunctional dashcam. This product can provide you with the opportunity to project your mobile phone onto the dashcam. Customers enjoy a one-year warranty and after-sales service from the date of purchase.
