ARTILLIAN ROPS MOUNTED
For use on Artillian ROPS Mounted Tool Bar (P/N: 1RMTB) (sold separately)
Comes with 15ft long x 1 inch wide E-Track Cam-buckle Strap (not shown)
The Artillian ROPS Mounted Fuel Can Holder is a convenient steel tray for
carrying fuel cans. An included cam-buckle strap with E-track fittings
securely holds a 2-1/2 gallon fuel can and a 1 gallon bar oil can in place
and allows for quick removal on the go. Many E-track locking positions and
additional bungee cord slots suit various fuel can sizes and orientations.
Provisions for carrying a maul or sledge hammer and several wedges
make this the perfect accessory for a day in the woods felling trees.
The quick release Cam Lever Latches allow for easy removal of the Fuel
Can Holder for storage or replacement with one of the many other Artillian
ROPS Mounted Tool Bar Accessories.
Approximate Set-Up Time
Experienced Dealer Technician – 15 Minutes
Average Dealer Technician – 15 Minutes
Do-It-Yourself – 15 Minutes
CAUTION
The contents of this envelope are the property of the owner. Leave with the owner when installation is complete.
FUEL CAN HOLDER
P/N: 1RMFCH
Approximate Product Specifications
Overall dimensions: 13.25" L x 17.3" W x 11.5" H
Weight: 19 lbs. (not including mounting bar)
Capacity: 45 lbs.
Do not exceed the rated capacity for the Fuel Can Holder. Doing so may result in
damage to the Fuel Can Holder and/or the Tool Bar and will void the warranty.
Rev. B, 08/10/2020
p/n: IM-1RMFCH
1 of 6
