ARTILLIAN UTV BED MOUNTED TOOL BAR
The Artillian UTV Bed Mounted Tool Bar is an innovative system for
attaching accessories to a UTV bed. It attaches to most vehicle beds in
minutes (some drilling may be required). At 42" wide, with unlimited
mounting bracket placement along the length, it adjusts to fit many
different vehicle beds. Simple, yet elegant mounting brackets included. 1"
square tube clamps provided for UTV beds that have exposed tubing.
Additional UTV Tool Rack can be purchased to convert your Tool Bar
system into a full bed rack for carrying ladders, wood, and any of the
Artillian ROPS Mounted Tool Bar Accessories.
The proprietary Cam Lever Latching feature found on the many optional
accessories allows for installation and removal of a given accessory in
seconds.
Approximate Installation Time
Experienced Dealer Technician – 15 Minutes
Average Dealer Technician – 25 Minutes
Do-It-Yourself – 45 Minutes
CAUTION
The contents of this envelope are the property of the owner. Leave with the owner when installation is complete.
All images shown are for illustration purposes only. Actual product may vary due to product enhancement.
P/N: 1UTVTB
Approximate Product Specifications
Mounting Bar Width: 42 inches
Weight: 12.2 lbs. (not including accessories)
Capacity: 100 lbs. (including accessories)
Do not exceed the rated capacity for the Tool Bar or its accessories.
Doing so may result in damage to the Tool Bar and will void the warranty.
Rev. B, 02/02/2021
p/n: IM-1UTVTB
1 of 8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1UTVTB and is the answer not in the manual?

Questions and answers

Related Manuals for Artillian 1UTVTB

Summary of Contents for Artillian 1UTVTB

  • Page 1 ARTILLIAN UTV BED MOUNTED TOOL BAR P/N: 1UTVTB The Artillian UTV Bed Mounted Tool Bar is an innovative system for attaching accessories to a UTV bed. It attaches to most vehicle beds in minutes (some drilling may be required). At 42” wide, with unlimited mounting bracket placement along the length, it adjusts to fit many different vehicle beds.

  • Page 2: Tools Required

    2 of 8 WARNINGS, TIPS, & REQUIRED TOOLS Artillian products feature an assembly of parts designed for your vehicle which require adjustment and alignment of components to accommodate vehicle variations and provide proper installation. For accurate installation, proper operation, and years of satisfaction, please read and understand the installation and owner’s manual fully prior to installing the...
  • Page 3 Mounted to Vehicle Bed Rail, Facing Inwards allow a given accessory to be quickly removed and relocated to a non-interfering location. Artillian strives to continuously improve our products. As such, the actual product may vary from the images shown throughout this manual.

  • Page 4: Kit Installation

    Flat Vehicle Bed Side 7. Test fit an Artillian Tool Bar Accessory onto the tool bar (Driver’s Side viewed From Passenger’s) to ensure that the cam lever latches can be fully locked without interference with the bed.

  • Page 5: Features And Operation

    FEATURES AND OPERATION FEATURES The Artillian UTV Bed Mounted Tool Bar allows for one or more Artillian ROPS Mounted Accessories to be attached to the vehicle ROPS. Additional Tool Bars allow for additional accessories. The innovation of the design is that any of the compatible accessories can be installed or removed from the Tool Bar in seconds, without the use of tools.

  • Page 6: Service Parts

    6 of 8 SERVICE PARTS: BACKER PLATE ASS’Y. MOUNTING BAR ASS’Y. TUBE CLAMP ASS’Y. P/N: 8SV-113-00186 (QTY.: ONE) P/N: 8SV-110-00092 (QTY.: ONE) P/N: 8SV-110-00068 (QTY.: ONE) MOUNTING BRACKET ASS’Y., LEFT MOUNTING BRACKET ASS’Y., RIGHT UTV BED RAIL CLAMP ASS’Y. P/N: 8SV-110-00090-L (QTY.: ONE) P/N: 8SV-110-00090-R (QTY.: ONE) P/N: 8SV-110-00086 (QTY.: ONE) 1/2”...

  • Page 7: Available Accessories

    7 of 8 AVAILABLE ACCESSORIES: ROPS MOUNTED TOOLBOX, X-LARGE ROPS MOUNTED TOOLBOX, LARGE ROPS MOUNTED TOOL RACK P/N: 1RMTBXS P/N: 1RMTBXL P/N: 1RMTRK ROPS MOUNTED CHAINSAW MOUNT ROPS MOUNTED FUEL CAN HOLDER ROPS MOUNTED TOOL BASKET P/N: 1RMCSM P/N: 1RMFCH P/N: 1RMTBSK (chainsaw shown for illustration purposes) ROPS MOUNTED 5-GALLON BUCKET...
  • Page 8 Artillian, LLC warrants to the original purchaser that this product will be free from defects in material and work- manship for a period of 90 days from the date possession taken by the original purchaser for use with Artillian hydraulic products and used as intended and under normal service and conditions for personal use.
