ARTILLIAN ROPS MOUNTED
For use on the Artillian ROPS Mounted Tool Bar (P/N: 1RMTB) (sold separately)
The Artillian Chainsaw Mount holds chainsaws with bar lengths over 14-inch and
widths under 4-1/2 inches (across the teeth). The "scabbard" style mount features
10GA steel with UHMW Polyethylene contact areas for added protection of the
bar and chain. A spring loaded clamping mechanism securely grips bars of
varying thicknesses and allows for installation and removal of the saw in seconds
without the use of tools. The saw's motor housing is supported by a steel bracket
with rubber pad to prevent unnatural torsional forces on the bar. An incorporated
"Scrench" holder and bungee cord attachment points complement the design.
Integrated Cam Lever Latches securely lock onto the Artillian ROPS Mounted
Tool Bar (sold separately) in seconds without the use of tools.
Approximate Installation Time
Experienced Dealer Technician – 5 Minutes
Average Dealer Technician – 5 Minutes
Do-It-Yourself – 5 Minutes
CAUTION
The contents of this envelope are the property of the owner. Leave with the owner when installation is complete.
CHAINSAW MOUNT
P/N: 1RMCSM
Approximate Product Specifications
Dimensions: 10.5" L x 9.5" W x 12" H
Weight: 18 lbs. (not including mounting bar)
Capacity: Accepts Chainsaws with 14"-24" bars
Do not exceed the rated capacity for the Chainsaw Mount. Doing so may
result in damage to the mount and/or the Tool Bar and will void the warranty.
Rev. B, 08/10/2020
p/n: IM-1RMCSM
1 of 5

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1RMCSM and is the answer not in the manual?

Questions and answers

Related Manuals for Artillian 1RMCSM

Summary of Contents for Artillian 1RMCSM

  • Page 1 CHAINSAW MOUNT P/N: 1RMCSM For use on the Artillian ROPS Mounted Tool Bar (P/N: 1RMTB) (sold separately) The Artillian Chainsaw Mount holds chainsaws with bar lengths over 14-inch and widths under 4-1/2 inches (across the teeth). The “scabbard” style mount features 10GA steel with UHMW Polyethylene contact areas for added protection of the bar and chain.

  • Page 2: Features And Operation

    2 of 5 FEATURES AND OPERATION ATTACH TO MOUNTING BAR: Note: The Artillian ROPS Mounted Toolbar is designed to hold multiple accessories at one time. If placed appropriately, up to 3 separate accessories may be possible. For example, the Chainsaw Mount, Fuel Can Holder, and Beverage Cooler Holder were designed to fit on the toolbar simultaneously.
  • Page 3 3 of 5 FEATURES AND OPERATION FEATURES AND OPERATION (cont’d.) 4. Per fig. 6, rotate the cam lever up. Ensure the handle rotates beyond the quick release pin mounting holes. 5. Slide the quick release pin into its mounting holes per fig.
  • Page 4 4 of 5 CHAINSAW MOUNT SERVICE PARTS CAM LEVER LATCH TRIM LOK (10 feet long) SAFETY WALK ADHESIVE STRIPS P/N: 8SV-110-00071 (QTY.: ONE) P/N: 9SV-PRO1-10 P/N: 9SV-9PR62-375 (QTY.: 12) CHAINSAW CLAMP ASSY CHAINSAW MOUNTING PLATE W/ RUBBER PAD, CHAINSAW MOUNT P/N: 8SV-113-00212 RUBBER PAD;...

  • Page 5: Other Accessories

    5 of 5 OTHER ACCESSORIES: ROPS MOUNTED TOOLBOX, LARGE ROPS MOUNTED TOOL RACK ROPS MOUNTED TOOLBOX, X-LARGE P/N: 1RMTBXS P/N: 1RMTRK P/N: 1RMTBXL ROPS MOUNTED TOOL BASKET ROPS MOUNTED FUEL CAN HOLDER BEVERAGE COOLER HOLDER P/N: 1RMTBSK P/N: 1RMFCH P/N: 1RMBCH (fuel cans and accessories shown for illustration purposes) (cooler shown for illustration purposes) ROPS MOUNTED 5-GALLON BUCKET...
