ARTILLIAN ROPS MOUNTED TOOL BAR
WALL MOUNT - P/N: 1RMTBWM
The Artillian ROPS Mounted Tool Bar is an innovative system for attaching
accessories to your 2-Post tractor ROPS. The proprietary Cam Lever
Latching feature found on the many optional accessories allows for
installation and removal of a given accessory in seconds.
This Wall Mount kit has the same great features, apart from the mounting
brackets, which are designed to mount onto a flat wall, rather than a 2-Post
tractor ROPS. This allows the system to be mounted in a garage,
workshop, enclosed trailer, or other fixed location for storage of the various
ROPS Mounted Tool Bar Accessories.
Approximate Installation Time
Experienced Dealer Technician – 15 Minutes
Average Dealer Technician – 25 Minutes
Do-It-Yourself – 45 Minutes
CAUTION
The contents of this envelope are the property of the owner. Leave with the owner when installation is complete.
Approximate Product Specifications
Mounting Bar Width: 42 inches
Weight: 9.76 lbs. (not including accessories)
Capacity: 100 lbs. (including accessories)
Do not exceed the rated capacity for the Tool Bar or its accessories.
Doing so may result in damage to the Tool Bar and will void the warranty.
Rev. B, 08/10/2020
p/n: IM-1RMTBWM
1 of 6
Advertisement
Table of Contents
Related Manuals for Artillian 1RMTBWM
Summary of Contents for Artillian 1RMTBWM
- Page 1 ARTILLIAN ROPS MOUNTED TOOL BAR WALL MOUNT - P/N: 1RMTBWM The Artillian ROPS Mounted Tool Bar is an innovative system for attaching accessories to your 2-Post tractor ROPS. The proprietary Cam Lever Latching feature found on the many optional accessories allows for installation and removal of a given accessory in seconds.
- Page 2 2 of 6 KIT INSTALLATION This kit is designed to be mounted to flat finished or most unfinished types of walls, with adequate spacing to allow room for the Cam Lever Latches to operate. The illustrations to the right are for reference of various types of installations.
- Page 3 3 of 6 KIT INSTALLATION Attach the brackets to the wall per one of the 5/32” pilot following methods as appropriate for the type holes, 2-1/2” of wall construction: deep Wood frame construction (finished or unfinished): The provided screws will hold securely in wood studs.
- Page 4 FEATURES AND OPERATION FEATURES The Artillian ROPS Mounted Tool Bar Wall Mount allows for one or more Artillian ROPS Mounted Accessories to be attached to a flat wall. Additional Tool Bars allow for additional accessories. The innovation of the design is that any of the compatible accessories can be installed or removed from the Tool Bar in seconds, without the use of tools.
- Page 5 5 of 6 SERVICE PARTS: WALL BRACKET ASSEMBLY MOUNTING BAR ASSEMBLY TUBE CLAMP ASSEMBLY P/N: 8SV-113-00186 (QTY.: ONE) P/N: 8SV-110-00079 (QTY.: ONE) P/N: 8SV-110-00068 (QTY.: ONE) PLASTIC TREE CLIPS 1/2” V-GROOVE WEATHERSEAL P/N: 9SV-CP01 (QTY.: 12) P/N: 9SV-PR20-10 (QTY.: 10 FEET)
- Page 6 6 of 6 AVAILABLE ACCESSORIES: ROPS MOUNTED TOOLBOX, X-LARGE ROPS MOUNTED TOOLBOX, LARGE ROPS MOUNTED TOOL RACK P/N: 1RMTBXS P/N: 1RMTBXL P/N: 1RMTRK ROPS MOUNTED CHAINSAW MOUNT ROPS MOUNTED FUEL CAN HOLDER ROPS MOUNTED TOOL BASKET P/N: 1RMCSM P/N: 1RMFCH P/N: 1RMTBSK (chainsaw shown for illustration purposes) (Fuel cans, etc.
