Installing a Hard Drive
4. Connect the data cable to the SATA data connector on the
new drive as shown in the following illustration.
Five data cables are provided in the kit. Refer
to the "SATA Hard Drive Cables" card
included in the kit to determine which cable
is required for your system board.
Ä
CAUTION: The data cable end is keyed to
ensure proper alignment. To avoid damage
to the cable header pins, check the
header/connector alignment and push
gently when connecting the data cable
header to the SATA connector on the drive
and system board.
