Handleiding
GYS Inverter 30-12 HF acculader en BSU
GY 029224
MSH equipment
Appelmarkt 7
1681 PE Zwaagdijk-Oost
Tel: 0228-561100
Fax: 0228-561112
Mail:
info@msh-equipment.nl
Website: www.msh-equipment.nl

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GYSFLASH 30-12 HF and is the answer not in the manual?

Questions and answers

Related Manuals for GYS GYSFLASH 30-12 HF

Summary of Contents for GYS GYSFLASH 30-12 HF

  • Page 1 Taal: Engels Handleiding GYS Inverter 30-12 HF acculader en BSU GY 029224 MSH equipment Appelmarkt 7 1681 PE Zwaagdijk-Oost Tel: 0228-561100 Fax: 0228-561112 Mail: info@msh-equipment.nl Website: www.msh-equipment.nl...
  • Page 2 GYSFLASH 30-12 HF FR - 2-9 / 42-44 30-24 HF EN - 10-17 / 42-44 DE - 18-25 / 42-44 ES - 26-33 / 42-44 RU - 34-41 / 42-44 73502-V1-11/10/2013...

  • Page 3: General Description

    AGM…) starter batteries from 10 Ah to 400 Ah in 12V and from 10Ah to 200Ah in 24V (only for GYSFLASH 30-24HF). - Diag Mode and Diag + Mode: on a stationary vehicle GYSFLASH 30-12 HF and 30-24HF supply up to 30A to ensure compensation of the current used by high-energy consumers (engine fan, window regulator, electronic suspension, etc).

  • Page 4: Charge Mode

    CHARGE MODE This product will charge the battery safely even if the battery is still in the vehicle. Ensure that the correct sequences are followed. Charge configuration : Before starting to charge the battery, ensure that the charger has been correctly set (battery voltage, charging curve and battery capacity).

  • Page 5: Showroom Mode

    NB: When the charge ends (100%), if the battery remains connected the charger maintains the charge level of the battery by applying a floating voltage. Precaution: Check the electrolyte level and fill if necessary before charging. DIAG MODE AND DIAG+ MODE On a stationary vehicle, the GYSFLASH supplies up to 30A to ensure compensation of the current used by high-energy consumers (engine fan, window regulator, electronic suspension, etc…) by charging at a steady voltage:...
  • Page 6 Voltage adjustment: It is possible to adjust the voltage from 12 to 14.8V in increments of 0.1V according to the vehicle manufacturers’ specifications: SHOWROOM MODE CONFIGURATION SHOWROOM SHOWROOM Power Supply with battery: Connect the clamps: red (+) SHOWROOM MODE START UP and black (-) of the battery.

  • Page 7: Configuration Menu

    Instructions: • Connect : 1 : The black clamp to the vehicle chassis. 2 : The red clamp to the end of the lug connected to the "+" battery terminal, in such a way that the battery can be changed without disconnecting the clamp. ATTERY CHANGE MODE START UP •...

  • Page 8: Troubleshooting

    CONFIGURATION MODE ADJUSTMENT Anglais English Français French Allemand German SETTINGS Néerlandais Dutch English Espagnol Spanish Portugues Portugais Italien Italian Russian Russe SETTINGS Restart : SETTINGS Lock showroom : CABLES TESTING CABLES TESTING CABLES TESTING Push the START button Short-circuit Short-circuit the clamps and push the START button PROTECTION...
  • Page 9 Display flashing : Electrical consumption greater than Switch off electrical consumers (i.e Headlights) " " >30A the capacity of the charger before re-trying + warning sound Normal use of the Gysflash 75-12HF. Switch off Many electrical consumers in the all electrical consumers in your vehicle to check vehicle are active if your battery is not deeply discharged (see The GYSFLASH delivers a high...

  • Page 10: Declaration Of Compliance

    ▪ Do not short-circuit the clamps during use. DECLARATION OF COMPLIANCE The GYS Company testifies that the chargers described in this manual : GYSFLASH 30-12 HF / GYSFLASH 30-24 HF Are manufactured in compliance with the requirements of the following European directives : - Low Voltage Directive : 2006/95/CE du 12/12/06.
  • Page 11 COMBINAISON BATTERIES / BATTERIES COMBINATION / BATTERIEKOMBINATIONEN /COMBINACION BATERIAS/ КОМБИНАЦИЯ АККУМУЛЯТОРОВ PICTOGRAMMES / SYMBOLS / ZEICHENERKLÄRUNG /ICONOS/ СИМВОЛЫ Appareil conforme aux directives européennes Pour usage intérieur, ne pas exposer à la pluie The device complies with European Directive For interior use, do not expose to the rain Gerät entspricht europäischen Richtlinien Nur für den Gebrauch in geschlosssnen Räumen Aparato en conformidad a las directivas europeas...
  • Page 12 SPÉCIFICATIONS TECHNIQUES / TECHNICAL FEATURES/ TECHNISCHE EIGENSCHAFTEN/ ESPECIFICACIONES TECNICAS/… GYSFLASH 30-12HF GYSFLASH 30-24HF Tension d’alimentation / Power supply/ ~230 V AC ±15% ~230 V AC ±15% Netzanschluss/ Tensión de alimentación / 50 / 60 Hz 50 / 60 Hz Напряжение питания Puissance nominale max / Max nominal power / Max.
  • Page 13 Classe de protection / Protection index / Schutzklasse / Clase de protección / Степень IP21 IP21 защиты Poids, cables secteur et de charge compris / Weight, input cables and charge cables included / Gewicht, inkl. Netz-/ und Ladekabel / Peso, cables 3,8 Kg 3,8 Kg sector y de carga incluidos / Вес...
