- Page 1 Original Instructions Original Instructions CAUTION. Read instructions before using the machine. CAUTION. Read instructions before using the machine. HZC 390S-2 / HZC 390L-2 1000W (Kit AA16) (Australia) HZC 390S-2 HZC 390L-2...
- Page 2 Kit AA16 Assembly...
- Page 3 Air Diffuser Hose...
-
Page 4: Using Your Machine
Using your machine Start Netzschalter Démarrage Start Ligar Avvio Encender Otwarty Moving your Machine... -
Page 5: Replacing The Cartridge Filter
Replacing the Cartridge Filter Seal contaminated hose using bung supplied. 2/3. Remove the sealed H Class Filter Unit from the drum. Place the Filter Unit and Hose Assembly inside an impervious plastic bag and seal the bag. Dispose of the plastic bag, depending on contamination, in an appropriate manner. Note* Filter unit is sealed do not attempt to open and reuse. - Page 6 Low Flow Warning Light Lo - Flo Indicator. Slow Repeated Flash. The vacuum cleaner is fitted with a warning lamp that will illuminate and flash when the air speed in the suction hose falls below <20m/s. This indicates that the filter cartridge requires changing. Cause Solution Suction hose blocked or kinked.
- Page 7 Changing / Replacing Cable...
- Page 8 About your machine 24.3 Rating Label Company Name & Address Daily Model Keep the machine clean, Voltage / Alternating Current including hoses and tubes. Ensure the bag and fi lter are Frequency fi tted. Regularly examine the power Rated Input Power cord.
- Page 9 Information for DRY use Vacuum cleaners 24.3 WARNING Read the instruction manual before using the machine. Operators shall be adequately instructed on the use of these machines. As with all electrical equipment, care and attention must be exercised at all times during use, in addition to ensuring that routine and preventative maintenance is carried out periodically to ensure safe operation.
- Page 10 IMPORTANT USER INFORMATION 24.3 Before use operators shall be provided with information, instruction and training for the use of the machine and the substances for which it is to be used, including the safe method of disposing of material collected. The cartridge fi lter has to be replaced when necessary.
- Page 11 MAINTENANCE 24.3 All machine parts should be regarded as contaminated when removed from the hazardous area and appropriate action taken to prevent dust dispersal. Disconnect from the power supply during cleaning, maintenance or when replacing parts. Ensure the plug is removed from the socket outlet. Maintenance must be carried out in a suitable non hazardous area with facilities for cleaning the area after servicing, and with suitable ventilation.
-
Page 12: Replacement Parts
Replacement parts 909007 H Class Filter Unit (Sealed) 601101 Hose 909221 Sealing Bung 909244 Cable Tie Schematic Diagram Data HZC 390S-2 12.2 kg 450 mm x 400 mm x 600 mm 13 L 26.8 m LpA ≤ 70 dB (A) Class I HZC 390L-2 13.0 kg... - Page 13 Warranty Numatic I nternational L imited w arrant t o t he o riginal p urchaser t hat i ts p roducts a re f ree o f d efects i n b oth material ...
- Page 14 Notes ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 15 Notes ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 16 Distributed by:- Australian Importer Numatic International Limited. Chard, Somerset TA20 2GB ENGLAND Tel: 01460 68600 www.numatic.co.uk Specification subject to change without prior notice www.numatic.co.uk © Numatic International Limited 909985 10/21 (A04)
